Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
M-Alite
-
Model Number:
-
ASL27
-
Application:
-
Outdoor
-
IP Rating:
-
IP66/IP65
-
Beam Angle(°):
-
70/80/90/100/96/65
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC90-305V
-
Lamp Luminous Efficiency(lm/w):
-
210Lm/W
-
Working Temperature(℃):
-
-40- + 50
-
Color Rendering Index(Ra):
-
70/80/90
-
Main Material:
-
Die-casting Aluminum+Glass
-
Power:
-
40W/60W/80W/100W/120W/150W/180W/200W
-
LED Chip:
-
Bridgelux 5050/Lumileds 3030
-
Size:
-
522*197*136mm
-
IK:
-
IK08/09/10
-
IP:
-
IP65/IP66
-
PF:
-
≥0.98
-
Beam Angle:
-
80/90/100/96/60
-
SPD:
-
10KV/20KV
-
Keyword:
-
100w street light
Quick Details
-
Color Temperature(CCT):
-
2200k/6500k
-
Warranty(Year):
-
2 Years,3 years,5 years
-
Lighting solutions service:
-
Lighting and circuitry design, DIALux evo layout, LitePro DLX layout, Agi32 layout, auto CAD layout, Onsite metering, Project Installation
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
M-Alite
-
Model Number:
-
ASL27
-
Application:
-
Outdoor
-
IP Rating:
-
IP66/IP65
-
Beam Angle(°):
-
70/80/90/100/96/65
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC90-305V
-
Lamp Luminous Efficiency(lm/w):
-
210Lm/W
-
Working Temperature(℃):
-
-40- + 50
-
Color Rendering Index(Ra):
-
70/80/90
-
Main Material:
-
Die-casting Aluminum+Glass
-
Power:
-
40W/60W/80W/100W/120W/150W/180W/200W
-
LED Chip:
-
Bridgelux 5050/Lumileds 3030
-
Size:
-
522*197*136mm
-
IK:
-
IK08/09/10
-
IP:
-
IP65/IP66
-
PF:
-
≥0.98
-
Beam Angle:
-
80/90/100/96/60
-
SPD:
-
10KV/20KV
-
Keyword:
-
100w street light
Specification
|
Item Code
|
Power
|
Specifications
|
Product Size (mm)
|
Warranty
|
|
ASL-27
|
40W/60W
|
1.Voltage:AC85-265V 2.PF>0.9 3.Leds:Epistar/CREE Etc optional 4.Lumen:110-160lm/w 5.CRI:>70 or 80 6.CCT:3000K/4000K/6000K
7.Viewing angle:optional 8.Material：Aluminum die-casting 10.Waterproof::IP66 IK10 11.Lightning surge:6KV（with 10KV surge protection devices) |
522*197*136
|
2,3 or 5 Years
|
|
ASL27
|
40-80W
|
|
600*245*155
|
2,3 or 5 Years
|
|
ASL27
|
80-120W
|
|
636*290*155
|
2.33/2.90
|
|
ASL27
|
120-200W
|
|
686*290*155
|
2.72/3.40
|
|
ASL27
|
200W-240W
|
|
760*310*155
|
|
