Quick Details
-
Blade Length (mm):
-
3300 mm
-
Backgauge Travel (mm):
-
10 - 1000 mm
-
Throat Depth (mm):
-
100 mm
-
Brand Name:
-
HUNSONE
-
Power (kW):
-
22 kW
-
Weight (KG):
-
5800 KG
-
Place of Origin:
-
Jiangsu, China
-
Voltage:
-
220V/380V, 220V/380V
-
Dimension(L*W*H):
-
3800*2000*2400mm
-
Year:
-
2023
-
Keyword:
-
Hydraulic Shearing Machine
-
Application:
-
Industrial Metal Cutting
-
Type:
-
Hydraulic Cutting Tools
-
Cutting material:
-
Metal .alloy Metal .aluminum
-
Function:
-
Shear Steel Plate
-
Usage:
-
Pressing Metal Products
-
Machine type:
-
Hydraulic Cutting Machine Shearing Machine
-
Control system:
-
Estun E21 NC Control
-
Cutting mode:
-
Machenical
Quick Details
-
Max. Cutting Width (mm):
-
6000
-
Max. Cutting Thickness (mm):
-
25 mm
-
Shearing Angle:
-
0.5°-3°
-
Blade Length (mm):
-
3300 mm
-
Backgauge Travel (mm):
-
10 - 1000 mm
-
Throat Depth (mm):
-
100 mm
-
Brand Name:
-
HUNSONE
-
Power (kW):
-
22 kW
-
Weight (KG):
-
5800 KG
-
Place of Origin:
-
Jiangsu, China
-
Voltage:
-
220V/380V, 220V/380V
-
Dimension(L*W*H):
-
3800*2000*2400mm
-
Year:
-
2023
-
Keyword:
-
Hydraulic Shearing Machine
-
Application:
-
Industrial Metal Cutting
-
Type:
-
Hydraulic Cutting Tools
-
Cutting material:
-
Metal .alloy Metal .aluminum
-
Function:
-
Shear Steel Plate
-
Usage:
-
Pressing Metal Products
-
Machine type:
-
Hydraulic Cutting Machine Shearing Machine
-
Control system:
-
Estun E21 NC Control
-
Cutting mode:
-
Machenical
Products Description
Details Images
Technical parameter
|
model
|
Shear thickness
|
Can be cut width
|
Number of trips
|
Backgauge range
|
Shear angle
|
Throat depth
|
main motor power
|
Dimensions
|
|
|
mm
|
mm
|
min -1
|
mm
|
°
|
mm
|
kw
|
mm(L×W×H)
|
|
4×2500
|
4
|
2500
|
25-45
|
600
|
0.5-1.5
|
100
|
5.5
|
3000×2000×1850
|
|
6×2500
|
6
|
2500
|
20-45
|
600
|
0.5-1.5
|
125
|
7.5
|
3030×2075×1920
|
|
6×3200
|
6
|
3200
|
16-45
|
600
|
0.5-1.5
|
125
|
7.5
|
3730×2075×1970
|
|
6×4000
|
6
|
4000
|
14-45
|
600
|
0.5-1.5
|
125
|
7.5
|
4530×2075×2080
|
|
6×5000
|
6
|
5000
|
11-40
|
800
|
0.5-1.5
|
125
|
7.5
|
5530×2075×2210
|
|
6×6000
|
6
|
6000
|
9-36
|
800
|
0.5-1.5
|
125
|
11
|
6530×2075×2520
|
|
7×7000
|
7
|
7000
|
7-28
|
800
|
0.5-1.5
|
125
|
11
|
7530×2075×2830
|
|
8×2500
|
8
|
2500
|
20-45
|
600
|
0.5-1.5
|
125
|
11
|
3040×2075×1920
|
|
8×3200
|
8
|
3200
|
16-45
|
600
|
0.5-1.5
|
125
|
11
|
3740×2075×1920
|
|
12×2500
|
12
|
2500
|
12-35
|
800
|
0.5-2
|
125
|
15
|
3110×2575×2210
|
|
12×3200
|
12
|
3200
|
7-35
|
800
|
0.5-2
|
125
|
15
|
3810×2575×2420
|
|
12×4000
|
12
|
4000
|
8-35
|
800
|
0.5-2
|
125
|
15
|
4610×2575×2530
|
|
16×2500
|
16
|
2500
|
16-40
|
800
|
0.5-2.5
|
125
|
22
|
3130×2655×2200
|
|
16×3200
|
16
|
3200
|
12-40
|
800
|
0.5-2.5
|
125
|
22
|
3830×2655×2200
|
|
16×4000
|
16
|
4000
|
12-40
|
800
|
0.5-2.5
|
125
|
22
|
4630×2655×2570
|
|
20×2500
|
20
|
2500
|
16-40
|
800
|
0.5-2.5
|
125
|
30
|
3160×2855×2300
|
|
20×4000
|
20
|
4000
|
12-40
|
800
|
0.5-2.5
|
125
|
30
|
4660×2855×2720
|
|
25×2500
|
25
|
2500
|
8-15
|
800
|
0.5-3.5
|
120
|
37
|
3330×2000×2650
|
|
25×3200
|
25
|
3200
|
8-15
|
800
|
0.5-3.5
|
120
|
37
|
3970×2100×2865
|
|
25×4000
|
25
|
4000
|
6-12
|
1000
|
0.5-3.5
|
120
|
37
|
4780×2500×3150
|
|
32×2500
|
32
|
2500
|
6-12
|
1000
|
0.5-3.5
|
120
|
45
|
4100×2300×3200
|
|
32×3200
|
32
|
3200
|
8-12
|
1000
|
0.5-3.5
|
120
|
55
|
1900×2650×3450
|
|
40×2500
|
40
|
2500
|
4-10
|
1000
|
0.5-3.5
|
120
|
75
|
4100×2550×3500
|
|
40×3200
|
40
|
3200
|
4-10
|
1000
|
0.5-3.5
|
120
|
75
|
4900×2900×3700
|
|
Item
|
Value
|
Item
|
Value
|
|
Max. Cutting Width (mm)
|
4000mm
|
Warranty
|
1 Year
|
|
Max. Cutting Thickness (mm)
|
20mm
|
Key Selling Points
|
High-accuracy
|
|
Automatic Level
|
Semi-automatic
|
Machinery Test Report
|
Provided
|
|
Shearing Angle
|
1°30′
|
Video outgoing-inspection
|
Provided
|
|
Blade Length (mm)
|
4000mm
|
Machine Type
|
Shearing Machine
|
|
Throat Depth (mm)
|
100mm
|
Control System
|
E21S Control System
|
|
Power (kW)
|
30kW
|
Model
|
QC11K 20X4000mm
|
|
Weight (KG)
|
27000KG
|
Electrical components
|
Schneider Electrical
|
|
Voltage
|
Three-phase 380V/ 50HZ
|
After-sales Service Provided
|
Service Machinery Overseas
|
|
Dimension(L*W*H)
|
5100x3600x3200mm
|
After-sales Service Provided
|
Service Machinery Overseas
|
