Quick Details
-
Brand Name:
-
Skollsun
-
Model Number:
-
MD1250N05
-
Work Time (h):
-
24
-
Max PV Power:
-
5820w
-
Max PV Voltage:
-
250v
-
Certificate:
-
CE
-
Warranty:
-
1 year
-
Charge mode:
-
MPPT Maximum Power Point Tracking
-
Function:
-
Solar Charging
-
Communication:
-
RS485 (RJ45 Interface)
-
OEM:
-
Accepted
-
Working Temperature( C):
-
20 ~+50
-
Charge Method:
-
MPPT Tracks Maximum Power
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Solar System Controller
-
Place of Origin:
-
Guangdong
-
Brand Name:
-
Skollsun
-
Model Number:
-
MD1250N05
-
Work Time (h):
-
24
-
Max PV Power:
-
5820w
-
Max PV Voltage:
-
250v
-
Certificate:
-
CE
-
Warranty:
-
1 year
-
Charge mode:
-
MPPT Maximum Power Point Tracking
-
Function:
-
Solar Charging
-
Communication:
-
RS485 (RJ45 Interface)
-
OEM:
-
Accepted
-
Working Temperature( C):
-
20 ~+50
-
Charge Method:
-
MPPT Tracks Maximum Power
Products Description
Technical Specifications
◆ Sealed battery,gel battery, vented battery, lithium battery and user-defined battery can all be used as backup battery. ◆
Available forintelligent generator and conventional generator,automatic recognition of generator type through ignition signal.
Available forintelligent generator and conventional generator,automatic recognition of generator type through ignition signal.
◆The charging working modes divides into PV charges backup battery, generat or charges backup battery,PV and generator charge backup battery and PV charges starter battery.
◆ Backup battery charging voltage line loss compensation function makes the battery charging voltage control more accurate.
◆ Backup battery temperature sampling function and temperature compensation function of lead-acid battery can effectively extend the lifespan of battery.
◆ TTL communication, provide technical support for communication protocol to facilitate the secondary development of applications.
◆ Support external remote switch control charging.
◆Parameter scan be monitored and set by mobile phone APP and PC monitoring setting software
◆High quality aluminum radiator and high temperature derating process ensure reliable and efficient operation under various working conditions
Product Details Images
|
Model
|
MD1230N05
|
MD1250N05
|
|
Backup Battery System Voltage
|
12V
|
12V
|
|
Backup Battery Voltage Range
|
9~16V DC
|
9~16V DC
|
|
Rated Charging Current
|
30A
|
50A
|
|
Maximum PV Input Voltage
|
55V DC
|
55V DC
|
|
Max. power point voltage range
|
17~36V
|
17~36V
|
|
Maximum PV Input Current
|
27A
|
45A
|
|
Solar Panel Charging Mode
|
Buck MPPT
|
Buck MPPT
|
|
MPPT Efficiency
|
＞99%
|
＞99%
|
|
PV input power is recommended
|
400W
|
400W
|
|
Generator (Starter Battery) System Voltage
|
12/24V
|
12/24V
|
|
Starter Battery Type
|
Lead-acid Battery
|
Lead-acid Battery
|
|
Maximum Generator Input Voltage
|
32V DC
|
32V DC
|
|
Maximum Generator Input Current
|
35A
|
60A
|
|
Generator output poweris recommended
|
400W
|
700W
|
|
No-load loss
|
<0.6W
|
<0.6W
|
|
MaximumChargingConversionEfficiency
|
98%
|
98%
|
|
Operating temperature
|
－35℃～65℃
|
－35℃～65℃
|
|
Waterproof level
|
IP32
|
IP32
|
|
Product dimensions
|
221*175.8*82.4mm
|
221*175.8*82.4mm
|
