Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Baili
-
Model Number:
-
CF
-
Type:
-
Fittings
Quick Details
-
Technics:
-
Casting
-
Shape:
-
Equal
-
Head Code:
-
Square
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Baili
-
Model Number:
-
CF
-
Type:
-
Fittings
PE COMPRESSION PIPE FITTINGS
Specifications
PE COMPRESSION PIPE FITTINGS
ITEM NO: 7000 MODEL
MATERIAL: PP
SIZE: FROM 20MM TO 110MM
STYLE: COUPLING, ELBOW, TEE, ADAPTOR
PE compression PIPE FITTINGS
ITEM NO: 7000 MODELS
NAME: PE FITTINGS
KEY WORDS: PIPE FITTINGS, PVC FITTINGS
MATERIAL: PP
STYLE: COUPLING, ELBOW, TEE, ADAPTOR
SIZE: 20MM, 25MM,32MM,40MM,50MM,63MM,75MM,90MM,110MM
Technical Date:
The compression fittings line has been designed for the conveyance of fluids at high pressures, for water conveyance,for potable water distribution and applications in the thermo-hudraulic sector. This product line answer to the most severe international standards in terms of mechanical properties and alimentary compatibilities
Reference Standards:
Working pressure: UNI 9561-2, DIN 8076, ISO 14263, BRL-K03
Polyethylene (PE) Pipes: UNI 7611, UNI7990, DIN9072, DIN8074, UNI 10910, EN12201
Threads: ISO 7, ANSIASME B1-20
Flanges: ISO 2084, DIN 2501, UN 17442
Working Pressures:
Allows the maximum working pressure (PN-PFA*) OF 16 bar (UNI 9561-2) for diameters from 16 to 63 and PN 10 for diameters from 75 to 110, at the temperature of 20°C. Maximum allowable working pressures related to the duration of pressure and temperature.
