Quick Details
-
Brand Name:
-
Top Brand
-
Fork Length:
-
1220mm
-
Fork Width:
-
150 mm
-
Overall Dimensions:
-
3565*2010*4415mm
-
Weight (KG):
-
10350 kg
-
Rated Loading Capacity:
-
8000kg
-
Load center:
-
600mm
-
Fork Size:
-
1220*150*70mm
-
Maximum Speed (Full/Empty):
-
30km/h
-
Rated output/r.p.m:
-
82.4/2000kw
-
Rated torque/r.p.m.:
-
416/1600N.m
-
No.of Cylinder:
-
6
-
Displacement:
-
6494cc
-
Fuel Tank Capacity:
-
125L
-
Certification:
-
CE/ISO9001
Quick Details
-
Min. Lifting Height:
-
2500mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Top Brand
-
Fork Length:
-
1220mm
-
Fork Width:
-
150 mm
-
Overall Dimensions:
-
3565*2010*4415mm
-
Weight (KG):
-
10350 kg
-
Rated Loading Capacity:
-
8000kg
-
Load center:
-
600mm
-
Fork Size:
-
1220*150*70mm
-
Maximum Speed (Full/Empty):
-
30km/h
-
Rated output/r.p.m:
-
82.4/2000kw
-
Rated torque/r.p.m.:
-
416/1600N.m
-
No.of Cylinder:
-
6
-
Displacement:
-
6494cc
-
Fuel Tank Capacity:
-
125L
-
Certification:
-
CE/ISO9001
Contact Way
Alune Xie —— Sales Manager
Mobile/Wechat/WhatsApp: +86 193-1332-9653
Email: alune@richmchn.com
Email: alune@richmchn.com
Products Description
8 Ton Forklift
CPCD80-G
Details Images
Product Paramenters
|
Model
|
|
|
CPCD50
|
CPCD60
|
CPCD70
|
CPCD80
|
||||
|
Power Type
|
|
|
Diesel
|
Diesel
|
Diesel
|
Diesel
|
||||
|
Rated Capacity
|
|
kg
|
5000
|
6000
|
7000
|
8000
|
||||
|
Load Centre
|
|
mm
|
600
|
600
|
600
|
600
|
||||
|
Lift Height
|
|
mm
|
3000
|
3000
|
3000
|
3000
|
||||
|
Fork Size
|
L x W x T
|
mm
|
1220x150x60
|
|
1220x150x70
|
|
||||
|
Mast Tilt Angle
|
F/R
|
mm
|
6/12
|
6/12
|
6/12
|
6/12
|
||||
|
Front Overhang(wheel centre to fork face)
|
|
mm
|
590
|
590
|
595
|
595
|
||||
|
Ground Clearance(bottom of mast)
|
|
mm
|
200
|
200
|
200
|
200
|
||||
|
Overall Dimension
|
Forklift length(without fork)
|
mm
|
3440
|
3440
|
3565
|
3565
|
||||
|
|
Overall width
|
mm
|
2010
|
2010
|
2010
|
2010
|
||||
|
|
Mast Lowered height
|
mm
|
2500
|
2500
|
2500
|
2500
|
||||
|
|
Mast Extended Height(with backrest)
|
mm
|
4415
|
4415
|
4415
|
4415
|
||||
|
|
Overhead Guard Height
|
mm
|
2430
|
2430
|
2430
|
2430
|
||||
|
Turning Radius(outside)
|
|
mm
|
3250
|
3250
|
3350
|
3350
|
||||
|
Min intersecting aisle
|
|
mm
|
2960
|
2960
|
3040
|
3040
|
||||
|
Speed
|
Travel(empty load)
|
km/h
|
30
|
30
|
30
|
30
|
||||
|
|
Lifting(full load)
|
mm/s
|
500
|
500
|
460
|
430
|
||||
|
Max Gradeability
|
|
%
|
20
|
20
|
20
|
20
|
||||
|
Tire
|
Front
|
mm
|
8.25-15-14PR
|
|
|
|
||||
|
|
Rear
|
mm
|
8.25-15-14PR
|
|
|
|
||||
|
Wheelbase
|
|
mm
|
2250
|
|
|
|
||||
|
Service Weight
|
|
kg
|
8150
|
8750
|
9750
|
10350
|
||||
|
Battery
|
Voltage/Capacity
|
V/Ah
|
(12/80)X2
|
|
|
|
||||
|
Engine
|
Model
|
|
6BG1-02
|
|
|
|
||||
|
|
Manufacture
|
|
ISUZU
|
|
|
|
||||
|
|
Rated output/r.p.m.
|
kw
|
82.4/2000
|
|
|
|
||||
|
|
Rated torque/r.p.m.
|
N.m
|
416/1600
|
|
|
|
||||
|
|
No.of Cylinder
|
|
6
|
|
|
|
||||
|
|
Bore x Store
|
mm
|
105x125
|
|
|
|
||||
|
|
Displacement
|
cc
|
6494
|
|
|
|
||||
|
|
Fuel Tank Capacity
|
L
|
125
|
|
|
|
||||
|
Transmission
|
Type
|
|
Hydraulic
|
|
|
|
||||
|
|
Stage FWD/RVS
|
|
2/2
|
|
|
|
||||
|
Operating Pressure for Attachment
|
|
Mpa
|
19
|
|
|
|
||||
