Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
MY6000
-
Input Voltage:
-
100/110/120Vac;220/230/240Vac, 100/110/120VAC;220/230/240VAC
-
Output Voltage:
-
100/110/120Vac(±5V);220/230/240Vac(±10V), 220/230/240VAC (±10V)
-
Output Current:
-
75A/50A
-
Output Frequency:
-
50Hz/60Hz, 50Hz/60Hz
-
Size:
-
607*345*198mm, 607*345*198mm
-
Warranty:
-
1 year, 1 Year
-
Weight:
-
42kg
-
Product name:
-
Power Frequency Solar Inverter
-
Application:
-
Solar Power System Home
-
Display:
-
LCD
-
Inverter type:
-
off grid solar power inverter
-
Keyword:
-
off grid solar power inverter
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
91%
-
Place of Origin:
-
China
-
Model Number:
-
MY6000
-
Input Voltage:
-
100/110/120Vac;220/230/240Vac, 100/110/120VAC;220/230/240VAC
-
Output Voltage:
-
100/110/120Vac(±5V);220/230/240Vac(±10V), 220/230/240VAC (±10V)
-
Output Current:
-
75A/50A
-
Output Frequency:
-
50Hz/60Hz, 50Hz/60Hz
-
Size:
-
607*345*198mm, 607*345*198mm
-
Warranty:
-
1 year, 1 Year
-
Weight:
-
42kg
-
Product name:
-
Power Frequency Solar Inverter
-
Application:
-
Solar Power System Home
-
Display:
-
LCD
-
Inverter type:
-
off grid solar power inverter
-
Keyword:
-
off grid solar power inverter
Product Details
hybrid solar inverter 6kw 6000 watt inverter 6000W pure sine wave power inverter
Features:
Pure sine wave inverter
Output power factor 1
Selectable high power charging current
Selectable input voltage range for home appliances and personal computers
Configurable AC/battery input priority via LCD setting
Compatible with generator power
Auto restart while AC is recovering
Overload and short circuit protection
Smart battery charger design for optimized battery performance
Cold start function
Color LCD display
Supports the use lithium batteries
Smart fan running control to extend service life and reduce noise
Supports the use lithium batteries
Wave by wave phase detection,more stable and reliable
RS232 communicate port and remote control panel optional
Specification
|
Rated Power
|
1000W
|
2000W
|
3000W
|
4000W
|
5000W
|
6000W
|
||||||
|
INPUT
|
|
|
|
|
|
|
||||||
|
Voltage
|
100/110/120Vac;220/230/240Vac
|
|
|
|
|
|
||||||
|
Selectable Voltage Range
|
Wide Range :75vac~138Vac;155Vac~275Vac(for home appliances)
Narrow Range:82Vac~138Vac;165Vac~275Vac(for personal computer) |
|
|
|
|
|
||||||
|
Frequency
|
40-70Hz(50Hz/60Hz)
|
|
100/110/120Vac(±5V);220/230/240Vac(±10V)
|
|
|
|
||||||
|
OUTPUT
|
|
|
|
|
|
|
||||||
|
AC Voltage Regulation(Batt Mode)
|
100/110/120Vac(±5V);220/230/240Vac(±10V)
|
|
|
|
|
|
||||||
|
Surge Power
|
2000VA
|
4000VA
|
9000VA
|
12000VA
|
15000VA
|
18000VA
|
||||||
|
Efficiency(Peak)
|
88%
|
|
91%
|
|
|
|
||||||
|
Transfer Time
|
<20ms
|
|
<10ms
|
|
|
|
||||||
|
Wavefrom
|
Pure sine wave
|
|
|
|
|
|
||||||
|
BATTERY
|
|
|
|
|
|
|
||||||
|
Battery Voltage
|
12V
|
24V
|
12V/24V/48V
|
24V/48V
|
24V/48V
|
24V/48V
|
||||||
|
Charge Current
|
35A
|
35A
|
75A/50A/25A
|
70A/35A
|
75A/45A
|
75A/50A
|
||||||
|
Fast Charge Voltage
|
14.3VDCfor 12V(*2 for 24V,*4 for 48V)
|
|
|
|
|
|
||||||
|
Float Charge Voltage
|
13.7VDC for 12V(*2 for 24V,*4 for 48V)
|
|
|
|
|
|
||||||
|
Battery Low Voltage Alarm
|
16.5VDCfor 12V(*2 for 24V,*4 for 48V)
|
|
|
|
|
|
||||||
|
Over Voltage Protect
|
10.5VDCfor 12V(*2 for 24V,*4 for 48V)
|
|
|
|
|
|
||||||
|
Battery Low Voltage Shutdown
|
10.0VDCfor 12V(*2 for 24V,*4 for 48V)
|
|
|
|
|
|
||||||
|
Protection
|
Over charging,over temp,over battery voltage,over load,short-circuit
|
|
|
|
|
|
||||||
|
Operating Enviroment Temperature
|
55℃
|
|
|
|
|
|
||||||
|
Cooling
|
Intelligent Fan
|
|
|
|
|
|
||||||
|
Display
|
LCD
|
|
|
|
|
|
||||||
|
Specification Setting
|
By LCD or position machine:
Charging current,battery type,input voltage,output frequency,wide and narrow of AC input voltage,power-saver model,AC priority or battery priorty |
|
|
|
|
|
||||||
|
PHYSICAL
|
|
|
|
|
|
|
||||||
|
Dimension,(D*W*H)mm
|
390*221.6*178.5
|
|
495*257*192
|
607*345*198
|
|
|
||||||
|
Net Weight (kgs)
|
11.4
|
15
|
25.2/24.6
|
34.4/33.8
|
37.9/38.2
|
41.6/40.5
|
||||||
|
ENVIROMENT
|
|
|
|
|
|
|
||||||
|
Humidity
|
5~95%Relative humidity(No-condensing)
|
|
|
|
|
|
||||||
|
Operating Temperature
|
-10～50℃
|
|
|
|
|
|
||||||
|
Storage Temperature
|
-10~60℃
|
|
|
|
|
|
||||||
