Quick Details
-
Output Frequency:
-
50/60hz
-
Output Current:
-
2A
-
Place of Origin:
-
China
-
Brand Name:
-
MYAMI
-
Model Number:
-
MY-K1502F
-
Product Name:
-
Variable dc Power Supply
-
Application:
-
Testing Repairing
-
Warranty:
-
1 Year
-
Protections:
-
Over voltage, current, power, temperature, short circuit
-
Type:
-
15V DC Regulated Power Supply
-
Color:
-
White
-
Display Type:
-
Digital Display
-
Name:
-
Lab Bench Power Supply
-
Cooling:
-
fan-cooling
-
Quality:
-
High-quality
Quick Details
-
Input Voltage:
-
AC110V/220V±10%
-
Output Voltage:
-
15V
-
Output Power:
-
30W
-
Output Frequency:
-
50/60hz
-
Output Current:
-
2A
-
Place of Origin:
-
China
-
Brand Name:
-
MYAMI
-
Model Number:
-
MY-K1502F
-
Product Name:
-
Variable dc Power Supply
-
Application:
-
Testing Repairing
-
Warranty:
-
1 Year
-
Protections:
-
Over voltage, current, power, temperature, short circuit
-
Type:
-
15V DC Regulated Power Supply
-
Color:
-
White
-
Display Type:
-
Digital Display
-
Name:
-
Lab Bench Power Supply
-
Cooling:
-
fan-cooling
-
Quality:
-
High-quality
Product Details
MYAMI-K1505 15V 30V 60V 100V 150V 2A 3A 5A 10A 20A 4 bit display Linear stabilized high precision bench power supply
0-15V/0-2A variable/30W
LED digital
LED digital
Features :
(1) Low noise and low ripple;
(2) Power display;
(3) ON/OFF unique switch;
(4) Automatic carry of the decimal point;
(5) Rear RS232/485/USB, upper computer software control (optional);
(6) Voltage, current and maximum power can be preset;
(7) over voltage, over current, over power, over temperature, short circuit five powerful protection function;
(8) long-term full load, short circuit ignition arc drawing machine;
(9) Dual frequency technology, energy saving and environmental protection (switching power supply);
(10) Intelligent temperature control fan. bench power supply,lab bench power supply,power supply 30v 5a
Specification
|
Product Name
|
Switching Power Supply
|
|
|
Model Number
|
MY-K1502
|
|
|
Place of Origin
|
Guangdong China
|
|
|
Output Type
|
Single
|
|
|
Output Power
|
0-30W
|
|
|
Output Votage
|
0-15V
|
|
|
Output Current
|
0-2A
|
|
|
Input Votage
|
AC110V/220V±10%,50/60Hz
|
|
|
Voltage Regulation
|
|
|
|
Voltage Display Accuracy
|
10mV
|
|
|
Load Regulation
|
≤0.1%+5mV
|
|
|
Line Regulation
|
≤0.1%+5mV
|
|
|
Ripple & Noise(P-P)
|
≤20mVrms
|
|
|
Current Regulation
|
|
|
|
Current Display Accuracy
|
10mA
|
|
|
Load Regulation
|
≤0.01%+10mA
|
|
|
Line Regulation
|
≤0.01%+3mA
|
|
|
Ripple & Noise(P-P)
|
≤10mArms
|
|
|
Other
|
|
|
|
Display
|
LED Digit Display
|
|
|
Operating Ambient
|
-10℃～-40℃ / <=80% RH
|
|
|
Dimension
|
280(D)×130(W)×165(H)mm
|
|
|
Weight
|
2kg
|
|
|
Model
|
Voltage
|
Current
|
Display
|
|
MY-K1502
|
0-15V
|
0-2A
|
3Led Digits
|
|
MY-K1505
|
0-15V
|
0-5A
|
3Led Digits
|
|
MY-K3005
|
0-30V
|
0-5A
|
3Led Digits
|
|
MY-K3010
|
0-30V
|
0-10A
|
3Led Digits
|
|
MY-K6005
|
0-60V
|
0-5A
|
3Led Digits
|
|
MY-K10003
|
0-100V
|
0-3A
|
3Led Digits
|
|
MY-K15002
|
0-150V
|
0-2A
|
3Led Digits
|
