Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment
Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment

Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment

FOB Reference Price: Get Latest Price
≥1 Sets
US $1000
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Dimension(L*W*H):
1.4*0.9*0.6
Name:
,Charcoal Sticks Extruder Forming Equipment
Mold:
by customers requirements
Raw Material:
Sawdust
Keyword:
Charcoal Briquette Machine
Diameter of briquettes:
50~80mm Customized
Briquette Shape:
e round, hexagon, cinquefoil or others
Moisture of raw material:
8%-12%
Finished Products:
charcoal briquettes
MOQ:
1 set
packing:
wooden case

Quick Details

Weight (KG):
3000
Place of Origin:
Henan, China
Brand Name:
MIKIM
Dimension(L*W*H):
1.4*0.9*0.6
Name:
,Charcoal Sticks Extruder Forming Equipment
Mold:
by customers requirements
Raw Material:
Sawdust
Keyword:
Charcoal Briquette Machine
Diameter of briquettes:
50~80mm Customized
Briquette Shape:
e round, hexagon, cinquefoil or others
Moisture of raw material:
8%-12%
Finished Products:
charcoal briquettes
MOQ:
1 set
packing:
wooden case

Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment

The Honey Comb Charcoal Briquettes Machine structure and principle is simple, divided into the body, rotation, feeding, punching, conveying five parts. All parts cooperate with each other, and the operation is coordinated and smooth.

We have two types briquettes machine for making coal/charcoal briquettes.

  • Extruding Type

this briquette machine capacity is smaller, but the working condition is stale. It could make different shape briquettes by changing mould, we also could match automatic cutter and conveyor for this machine, so it could work continuously, by adjusting cutter, it also could make different length briquettes.

  • Pressing Type
This briquette machine capacity is higher than pressing working type. Normally, this machine could make maximum briquettes length is 13cm, common length is 8-10cm. It also could make different shape briquettes by changing mould, the most popular shape is hexagon, round, square, honeycomb and etc.

Specification

Charcoal Machine Charcoal Powder Briquette Extruder Making Machine Charcoal Sticks Extruder Forming Equipment

Working type

Model

Capacity for coal

Capacity for charcoal

Power

Extruding Type

ET-1

200-250kg/h

500kg/h

11+0.55kw

ET-2

250-500kg/h

500-1000kg/h

18.5+1.1kw

ET-3

1500kg/h

not suitable for charcoal

22+3kw

Pressing Type

YM-140

1.86-2tons/h

0.93-1ton/h

7.5kw

YM-160

1.86-2tons/h

0.93-1ton/h

11kw

YM-220

1.25tons/h

2.5tons/h

15kw

Raw Material Requirements:

(1) Raw material: All kinds of coal powder,charcoal powder,biomass materials.
It can be coal powder, charcoal powder, coke powder, carbon black powder, brown coal, many mineral powder, etc. It also can be biomass materials and agricultural materials like all kinds of straw, sawdust, wood, branches, shells, husks, biogases etc as raw materials to produce charcoal briquettes.
(2) Raw material diameter: Less than 3 mm.
(3) Raw material moisture: 8-15%.
(4)Add different binder according to your raw material and final briquettes requirements.(liquid and dry powder binder).

Finished Product

(1) Shapes of final briquettes: such as cylindrical,round, square, flower shapes
and fan-shaped, hexagonal shape,etc. Or we can custom moulds as your requirements.
(2) Honeycomb diameter: 120mm; 140mm; 160mm; 180mm; 220mm or custom-made diameter.
(3) Honeycomb height: 80±5.0mm;90±5.0mm
(4) Inside hole diameter is:14-16mm or 25mm.
(5) Hole number:16PCS ; 19PCS or required hole number.
(6) Binder formula: we have 6 kinds binder formula, we also can offer water-proof formula and instant ignite(combustion-improver) to our customers free of charge.

Accept Customized Shape ,Mold ,Size ,Color in Machine ,welcome send us your inquiry
