Quick Details
-
Rated Lifting Moment:
-
630KN.m
-
Span:
-
0-80m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
HUGO
-
Capacity:
-
5ton
-
Lifting speed:
-
2.2 m/min
-
motor power:
-
3.0kw
-
Rotation speed:
-
1440 r/min
-
Insulation grade:
-
F level
-
Travelling speed:
-
11 m/min & 21 m /min
-
Power Supply:
-
380 V, 3 Phase, 50 HZ or customized
-
Control voltage:
-
24. 36 . 48 V
-
No. of Chain:
-
2
-
Dia. of Load chain:
-
7.1
-
Certification:
-
CE ISO
Quick Details
-
Rated Loading Capacity:
-
5TON
-
Max. Lifting Height:
-
12M
-
Application:
-
Construction
-
Rated Lifting Moment:
-
630KN.m
-
Span:
-
0-80m
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
HUGO
-
Capacity:
-
5ton
-
Lifting speed:
-
2.2 m/min
-
motor power:
-
3.0kw
-
Rotation speed:
-
1440 r/min
-
Insulation grade:
-
F level
-
Travelling speed:
-
11 m/min & 21 m /min
-
Power Supply:
-
380 V, 3 Phase, 50 HZ or customized
-
Control voltage:
-
24. 36 . 48 V
-
No. of Chain:
-
2
-
Dia. of Load chain:
-
7.1
-
Certification:
-
CE ISO
Low clearance 5 ton 3 phase electric chain hoist crane with trolley
Construction Electric Chain Hoist
|
|
Using the most advanced square air connector
More beautiful
|
|
Using aluminum body
|
|
|
High safely and reliability
The machine set limited protection device, to avoid overloading caused harmful consequences;Motor thermal protection device, it can protect the motor;The upper and lower limit device, when the hook up or down to extremely limit, the opportunity to automatically cut off power supply, hook immediately stop action |
|
|
Strong import load chain
Used in Japanese FEC chain and made it strong of the antifatigue and antifraying |
||
|
It have the emergence stop button of lose voltage protection.
Press the emergency stop button, it can immediately cut off the motor circuits
|
| Parameters of PDH Electric Chain Block | ||||||||
| Model | PDH-A-0.5 | PDH-A-1 | PDH-A-2 | PDH-A-2.5 | PDH-A-3 | PDH-A-5 | ||
| Capacity ( t) | 0.5 | 1 | 2 | 2.5 | 3 | 5 | ||
| Standard lifting height ( m) | 3 | |||||||
| Lifting Speed ( m/min) | 7.2 | 5.8 | 3.0 | 5.0 | 5.0 | 2.6 | ||
| Lifting Motor | Power (kw) | 8 | 8 | 14 | 7 | 10 | 5 | |
| Volt (V) | ||||||||
| Frequency (Hz) | 50 | |||||||
| Chain Turns | 1 | 1 | 2 | 1 | 1 | 2 | ||
| Chain specification ( mm) | Ø 6.3×19 | Ø8×24 | Ø8×24 | Ø11.2×34 | Ø11.2×34 | Ø11.2×34 | ||
| Test load (t) | 0.625 | 1.25 | 2.5 | 3.125 | 3.75 | 6.25 | ||
| Net Weight (kw) | 41 | 45 | 53 | 108 | 110 | 130 | ||
| Weight added with 1m higher (kg) | 1.1 | 1.4 | 2.8 | 2.8 | 2.8 | 5.6 | ||
| PDH Model Construction Used Electric Chain Hoist |
|
1. Electric motor partial outer cover: They are made of high strength aluminum system through compression casting formation. Features: Solid and light, Fast release heat, Continuous use, Enclosed structure. Can be used in the chemical plants, electroplating factories, and other places. |
| 2. Side kind braking: This masterly structure ensure the hoist absolutly safty when the power off. And ensures it is safe when has excess load. Also it combine to the motor braking as the double brake system to strengthen security and durability. |
| 3. Gear: The gear made of alloy steel and through the heat treatment |
| 4. Antiphase protector :When power-supply wiring mistake, the control circuit is unable to move. |
| 5. Hooks: They are made by hot forging and heat treatment. |
|
6. Chain:
It is made of FEC80 ultra strong heat treatment alloy steel.
Advatages: It is safely approximately when used in the rain water, the sea water, under the chemical and other bad conditions. |
| 7. ISO: M5 /FEM: 2AM Insulation grade: F |
| 8. Protection class (hosit and push button): IP55 |
| 9. Powder supply: 3 phase, 200-600v, 50HZ |
Detailed Pictures of PDH Electric Chain Hoist
