Quick Details
-
Voltage (V):
-
220
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
manling
-
Model Number:
-
ML-A TYPE
-
Energy:
-
Economic system for saving gas
-
Gas type::
-
LPG / N.G
-
Function::
-
Heating and Bathing
-
Rated heat input:
-
24kw
-
Minimum heat input:
-
7.2
-
Rated heating output:
-
20.5kw
-
Heating water cycle way:
-
Configuration water tank inside
-
Hot water temperature adjust:
-
40~80 Heating water(°C)
-
Exhaust type:
-
Forced Exhaust
-
Certification:
-
ISO9001
Quick Details
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Household
-
Power (W):
-
20
-
Voltage (V):
-
220
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
manling
-
Model Number:
-
ML-A TYPE
-
Energy:
-
Economic system for saving gas
-
Gas type::
-
LPG / N.G
-
Function::
-
Heating and Bathing
-
Rated heat input:
-
24kw
-
Minimum heat input:
-
7.2
-
Rated heating output:
-
20.5kw
-
Heating water cycle way:
-
Configuration water tank inside
-
Hot water temperature adjust:
-
40~80 Heating water(°C)
-
Exhaust type:
-
Forced Exhaust
-
Certification:
-
ISO9001
Products Description
|
Rated heat input
|
KW
|
24
|
|
|
|||
|
Minimum heat input
|
KW
|
7.2
|
|
|
|||
|
Rated heating output
|
KW
|
20.5
|
|
|
|||
|
Min heating heat output
|
KW
|
5.8
|
|
|
|||
|
Rated Production hot water energy(30 K hot temperature rise out of water)
|
Kg/min
|
9.4
|
|
|
|||
|
Rated gas pressure (N.G)
|
Pa
|
(12T)2000Pa
|
|
|
|||
|
Heating system applies to the pressure
|
Mpa
|
0.05-0.3
|
|
|
|||
|
Shower hot water system applies to the pressure
|
Mpa
|
0.05-0.6
|
|
|
|||
|
Heating water cycle way
|
Configuration water tank inside
|
|
|
|
|||
|
Hot water temperature adjust
|
Heating water(°C)
|
|
40~80
|
|
|||
|
|
Bath water (°C)
|
|
30~60
|
|
|||
|
Thermal efficiency(Ideal working conditions)
|
>88~95%
|
|
|
|
|||
|
Electrical parameters(Electrical rating108W)
|
AC220V/50Hz
|
|
|
|
|||
|
Exhaust pipe
|
Outside diameter(mm)
|
|
|
90
|
|||
|
|
Inner diameter(mm)
|
|
|
60
|
|||
|
Piping specifications
|
Shower nozzle inlet and outlet water
|
|
|
G1/2''
|
|||
|
|
Intake pipe
|
|
|
G3/4''
|
|||
|
|
Heating conduit for back
|
|
|
G3/4''
|
|||
|
Reference heating area
|
<160m2
|
|
|
|
|||
|
Product Weight
|
40Kg
|
|
|
|
|||
|
Product size(mm)
|
750×440×330
|
|
|
|
|||
