Quick Details
-
Thickness:
-
0.1 - 0.8 mm, 0.27 - 0.5 mm, 0.27mm, 0.30mm, 0.35mm, 0.50mm
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
36F320M
-
Product Name:
-
Electrical Steel, Lamination Steel, Silicon Steel
-
Port:
-
Tianjin\Qingdao\Shanghai
-
Width:
-
900-1230 mm
-
Payment term:
-
TT
-
Package:
-
Standard Seaworth Packing
Quick Details
-
Type:
-
Oriented Silicon Steel
-
Tolerance:
-
±1%
-
Grade:
-
silicon steel
-
Thickness:
-
0.1 - 0.8 mm, 0.27 - 0.5 mm, 0.27mm, 0.30mm, 0.35mm, 0.50mm
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
36F320M
-
Product Name:
-
Electrical Steel, Lamination Steel, Silicon Steel
-
Port:
-
Tianjin\Qingdao\Shanghai
-
Width:
-
900-1230 mm
-
Payment term:
-
TT
-
Package:
-
Standard Seaworth Packing
Product Description
|
Product Name
|
Electrical Steel, Lamination Steel, Silicon Electrical Steel, Silicon Steel, Relay Steel, Transformer Steel
|
|
|
|
|||
|
Category
|
Grain-Oriented Electrical Steel; Non-oriented electrical steel
|
|
|
|
|||
|
Standard
|
AISI, ASTM, BS, DIN, GB, JIS, EN
|
|
|
|
|||
|
Thickness
|
0.2- 0.8 mm
|
|
|
|
|||
|
Width
|
900-1230 mm
|
|
|
|
|||
|
Brand
|
JIABORUI
|
|
|
|
|||
|
Origin
|
China
|
|
|
|
|||
|
Packing
|
Export standard package (as per requirements)
|
|
|
|
|||
|
Payment Terms
|
30% T/T in advance as deposit,70% balance against the B/L copy or 100% irrevocable L/C at sight
|
|
|
|
|||
|
MOQ
|
3 tons per size
|
|
|
|
|||
|
Delivery time
|
15-40 days after receiving L/C or deposit
|
|
|
|
|||
|
Loading Port
|
Shanghai , China (any port in China )
|
|
|
|
|||
|
Remark
|
Specific requirement of alloy grade,temper or specification can be discussed at your request
|
|
|
|
|||
Product advantages:
1.Stable performance
2.Excellent processing performance:
High precision dimension and excellent mechanical properties make it easy to be sheared, punched and stacked by high speed punch machine. It also have good welding performance.
3.Excellent performance of Insulating coating:
Uniform color, good insulation, high adhesion, excellent heat resistance and excellent processing performance
Specification
|
Mechanical Property
|
|
|
|
|
||||
|
Grade
|
Yeild Strength
(N/mm2) |
Ultra-Tension
Strength(N/mm2)
|
Ductility
(%) |
Hardness
(HV1 |
||||
|
M35W230
|
430
|
560
|
20.0
|
225
|
||||
|
M35W250
|
415
|
550
|
20.5
|
220
|
||||
|
M35W270
|
400
|
515
|
20.5
|
215
|
||||
|
M35W300
|
360
|
480
|
21.5
|
195
|
||||
|
M35W360
|
350
|
480
|
23.5
|
190
|
||||
|
M35W440
|
275
|
420
|
27.5
|
165
|
||||
|
M35W550
|
265
|
415
|
33.5
|
160
|
||||
|
M50W250
|
430
|
560
|
19.0
|
230
|
||||
|
M50W270
|
410
|
550
|
21.5
|
225
|
||||
|
M50W290
|
395
|
545
|
22.5
|
220
|
||||
|
M50W310
|
385
|
510
|
24.5
|
210
|
||||
|
M50W350
|
350
|
475
|
26.5
|
190
|
||||
|
M50W400
|
320
|
460
|
36.0
|
170
|
||||
|
M50W470
|
295
|
425
|
35.0
|
160
|
||||
|
M50W600
|
280
|
410
|
37.0
|
140
|
||||
|
M50W800
|
285
|
405
|
38.5
|
135
|
||||
|
M50W1300(D)
|
250
|
360
|
40.0
|
115
|
||||
|
Insulating Coating
|
|
|
||
|
Coating types
|
M11
|
M21
|
||
|
Component
|
Chromium containing , semi organic coating
|
Chromium free, semi organic coating
|
||
|
Coating thickness(μm)
|
0.7~1.5
|
0.8~5.0
|
||
|
Interlayer resistance
(Ω•mm2 /slice) |
≥100
|
≥100
|
||
|
Adhesive property
|
Class A or class B
|
Class A or class B
|
||
|
Punching property
|
Excellent
|
Excellent
|
||
|
Antirust property
|
Excellent
|
Excellent
|
||
|
Heat resisting property
|
Resistant annealing at 750 C, N2 protection, for 2h
|
Annealing resistance in general
|
||
Applications
Electrical steel (silicon steel sheet) is mainly divided into two categories: grain-oriented electrical steel and grain non-oriented electrical steel.
The direction of easy magnetization grains of oriented electrical steel is distributed along the rolling direction. The rolling direction has excellent characteristics such as high magnetic induction, low iron loss and low magnetostriction. At the same time, it can also be processed by magnetic domain refinement technology to obtain lower iron Loss of performance, widely used in the field of transformer industry.
The grain direction of non-oriented electrical steel is randomly distributed, and the electromagnetic properties are uniform in all directions. It is widely used in the motor industry.
|
Field
|
Purpose
|
|
|
|
|||
|
Rotary machine
|
Large motor
Medium motor Compressor motor General Motors Small precision motor Motor for electric vehicle |
|
|
|
|||
|
The Immobilizer
|
High frequency working motor
Miniature power supply transformer Instrument use transformer Reactor Welding machine use transformer Power switch Manostat Magnetic sealing unit Electromagnet for accelerator |
|
|
|
|||
