Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Lebeisenf
-
Model Number:
-
S-400-36
-
Output Frequency:
-
50-60Hz
-
Output Current:
-
11A
-
Product Name:
-
Swtiching Power
-
Application:
-
LED Light
-
Warranty:
-
2 Years
-
Certification:
-
CE ROHS
-
Type:
-
AC DC Power Module Converter
-
Efficiency:
-
82%
-
Weight:
-
798g
-
Protections:
-
OCP OVP SCP OPP
-
Color:
-
Silver
-
Material:
-
Aluminum
Quick Details
-
Output Power:
-
400W
-
Input Voltage:
-
AC110/220V±15%
-
Output Voltage:
-
24V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Lebeisenf
-
Model Number:
-
S-400-36
-
Output Frequency:
-
50-60Hz
-
Output Current:
-
11A
-
Product Name:
-
Swtiching Power
-
Application:
-
LED Light
-
Warranty:
-
2 Years
-
Certification:
-
CE ROHS
-
Type:
-
AC DC Power Module Converter
-
Efficiency:
-
82%
-
Weight:
-
798g
-
Protections:
-
OCP OVP SCP OPP
-
Color:
-
Silver
-
Material:
-
Aluminum
DC 36V 400W 11A AC to DC Indoor LED Lighting Switching Power Supply Transformer Drive Adapter
◆Safety features: Automatic overload cut-off, over Voltage cut-off, automatic thermal cut-off, short circuit protection.
◆Voltage consistency: There is no voltage fluctuations to speak of at power on, during transmit, receive, or at power off.
Thickened metal shell
◆The shell is made of high-quality metal material, which has good
◆It comes with built-in cooling fan and many holes on the metal case, which makes heat dissipation more efficient.
Featured Components
High-quality raw materials - pure copper inductors, high-performance transformers, and high-capacity electrolytic capacitors are the guarantee of high-quality power supplies;
Suitable for a variety of electronic devices
Products are widely used in industrial automation control, LED lighting, industrial control equipment, communication power equipment, instrumentation, medical equipment, liquid crystal displays, digital products and instruments and other fields
|
Model
|
S-400-36
|
|
AC input voltage range(V)
|
AC 110/220V±15%
|
|
Frequency (Hz)
|
50/60Hz
|
|
Efficiency
|
82% Typ(230VACFull Load)
|
|
Inrush current(A)
|
Cold-start 20A/230V
|
|
Leakage current(mA)
|
<3mA/240VAC
|
|
Output Voltage(V)
|
36VDC
|
|
Voltage Regulation
|
+10%,-10%
|
|
Output Current(A)
|
11A
|
|
Current Range (A)
|
0-11A
|
|
Rated Power(W)
|
360W
|
|
Start time,hold-up time(ms)
|
Ton≤1000ms,Td≥20ms @230Vac Full Load
|
|
Rise time(ms)
|
Typ:20ms @230Vac Full Load
|
|
Ripple/Noise(mVp-p)
|
120mVp-p
|
|
working Temperature (°C)
|
-40°C - +65°C(refer derating curve)
|
|
Storage Temperature(°C)
|
-20°C - +60°C
|
|
Humidity
|
20% - 90% RH non condensing
|
|
Over voltage Protection
|
>115%-135% Rated output voltage
|
|
Over load Protection
|
>105%-150% Auto recovery
|
|
Short circuit Protection
|
Latched
|
|
Size L*W*H(mm)
|
215*113*50
|
|
Weight
|
798g
|
Easy to install and easy to use
