Quick Details
-
Color:
-
Clear
-
Continuous operating temperature:
-
-60℃-200℃
-
Application:
-
Pharmaceutical, Biotechnology, Food and Beverage
-
Sample:
-
Free
-
Delivery:
-
Fast Express with competitive price
-
Certification:
-
RoHS
-
Min. shrink temperature:
-
90℃
-
Min. full recovery temperature:
-
170℃
-
Tensile strength:
-
6.9 MPa
-
Breakdown voltage:
-
25kv/mm
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
VOLSUN
-
Model Number:
-
Silicone rubber
-
Color:
-
Clear
-
Continuous operating temperature:
-
-60℃-200℃
-
Application:
-
Pharmaceutical, Biotechnology, Food and Beverage
-
Sample:
-
Free
-
Delivery:
-
Fast Express with competitive price
-
Certification:
-
RoHS
-
Min. shrink temperature:
-
90℃
-
Min. full recovery temperature:
-
170℃
-
Tensile strength:
-
6.9 MPa
-
Breakdown voltage:
-
25kv/mm
0.4mm-80mm Transparent silicone soft rubber tubing
Description
0.4mm-80mm Transparent silicone soft rubber tubing
is made of superior quality silicone rubber through scientific formula of the raw materials and special advanced processing technology. With its stable property, good flexibility and high temperature resistance, it ’ s ideally used where high temperature resistance, insulation, arc resistance, or corona resistance are important.
Features
High temperature resistant,voltage resistant,flame retardant,flexible,SGS certified,ROHS compliant Continuous operating temperature:-50°C~200°C
Min. shrink temperature: 90°C
Min. full recovery temperature: 170°C
Shrink ratio:1.7:1
Markets:electronic components ,resistor, capacitor or condenser,aerospace,medical apparatus and instruments
Technical performence
|
Property |
Typical Data |
Test method |
|
Density( g/cm 3 ) |
1.16±0.05 |
ISO 2781 |
|
Shore A Hardness |
65±5 |
ISO 868 |
|
Tensile strength( MPa ) |
≥4.0 |
ISO 37 ISO 1817 B |
|
Tensile strength after being immersed in solvent( MPa ) |
≥3.0 |
|
|
Elongation( % ) |
≥210 |
|
|
Elongation after immersion in solvent( % ) |
≥100 |
|
|
Tear resistance( MPa ) |
≥3.5 |
ASTM D 624 |
Dimension
ID: 0.4mm ~ 80mm
ID tolerances: standard: ± 0.1mm, also available: ± 0.05mm
Characters and Logos screen printed on the surface upon request
