Quick Details
-
Controller Type:
-
PWM
-
Mounting Type:
-
Roof Mounting
-
Place of Origin:
-
GUANGDONG
-
Brand Name:
-
KTAC
-
Model Number:
-
UPS-500SL
-
Load Power (W):
-
500W, 300W
-
Output Voltage (V):
-
220V/110V Factory preset
-
Output Frequency:
-
50/60Hz factory preset
-
Work Time (h):
-
2-10 hours
-
Product name:
-
300W solar power station
-
Capacity:
-
500VA/300w
-
Wave Form:
-
Pure Sine Wave
-
Display:
-
LED
-
Technology:
-
standby
-
internal battery:
-
12.8V 60AH
-
Ac charge current:
-
5A
-
USB charger:
-
2x5V/1A
-
solar panel:
-
18V 50W Poly
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Polycrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion
-
Controller Type:
-
PWM
-
Mounting Type:
-
Roof Mounting
-
Place of Origin:
-
GUANGDONG
-
Brand Name:
-
KTAC
-
Model Number:
-
UPS-500SL
-
Load Power (W):
-
500W, 300W
-
Output Voltage (V):
-
220V/110V Factory preset
-
Output Frequency:
-
50/60Hz factory preset
-
Work Time (h):
-
2-10 hours
-
Product name:
-
300W solar power station
-
Capacity:
-
500VA/300w
-
Wave Form:
-
Pure Sine Wave
-
Display:
-
LED
-
Technology:
-
standby
-
internal battery:
-
12.8V 60AH
-
Ac charge current:
-
5A
-
USB charger:
-
2x5V/1A
-
solar panel:
-
18V 50W Poly
Portable 300W solar lithium battery solar energy system solar station solar generator
PRODUCT INTRODUCTION
This 3 00W solar portable generator solar energy system is featured with long time autonomy, unlike tradidtional UPS which only power the load for a few minutes, this solar power station is aimed to backup the load for hours, built in 5A AC charger and solar charger makes this system easy to be charged with both grid power or only solar power. It has 2 AC power sockets makes it fit most small electronics power senarios. 2 Nos of 5V USB chargers allow the user’s to charge their smart phones for hundreds times, 2 Nos of 12V DC charge ports can power lamps in power outage dark nights. 12.8V/24Ah battery is capable to power computer set for up to 10hours. a 100W mono solar panel can charge the system fully in approximately 7 hours. This 500W solar portable generator solar energy system is ideal to power the PC, cash terminal, cooker, heaters, small refridgerators.
| Model | UPS-500SL | PBS-600 |
| Power capacity | 500VA/300W | 600VA/500W |
| AC Input | ||
| Input voltage | 110V/220VAC | 110V/220VAC |
| Input voltage range | 90V-135V/145-270VAC | 90V-135V/145-270VAC |
| Input Frequency | 50Hz or 60Hz (auto-sensing) | 50Hz or 60Hz (auto-sensing) |
| Input connector | Power plug | Power plug |
| AC Output | ||
| Output voltage | 110VAC or 220VAC±10% | 110VAC or 220VAC±10% |
| Output frequency range | 50Hz or 60Hz ±5% | 50Hz or 60Hz ±5% |
| Transfer time | Typical 10-15ms | Typical 10-15ms |
| Waveform(battery mode) | Modified sine wave | Pure sine wave |
| DC Input | ||
| Input voltage | 18-30VDC | 18-30VDC |
| Input connector | DC022B terminal | DC022B terminal |
| DC Output | ||
| 12V DC charge ports | 2 Nos, with charge current 10A max | 2 Nos, with charge current 10A max |
| 5V USB ports | 2 Nos, with charge current 1A max | 2 Nos, with charge current 1A max |
| Battery | ||
| Battery type x qty | 12V/24AHx1 Lead acid battery | 12.8V/60AH LiFePo4 battery pack |
| Charge current | 5A(max) | 5A(max) |
| Typical recharge time | 6 hours recover to 90% capacity | 6 hours recover to 90% capacity |
| Protection | ||
| Full protection | Automatic detection, discharge,short circuit and overload protection | Automatic detection, discharge,short circuit and overload protection |
| Overload capability | Overload 110%~130%: Shutdown after 60s;Overload above 130%: Shutdown after 300ms. | Overload 110%~130%: Shutdown after 60s;Overload above 130%: Shutdown after 300ms. |
| Display & Indicators | ||
| Status display | LED indicators: AC & charge, solar charge, battery capacity level.(10%,25%,50%,75%,100%) | LED indicators: AC & charge, solar charge, battery capacity level.(10%,25%,50%,75%,100%) |
| Remote controller | Wireless remote controller, operation range: 80 meters | Wireless remote controller, operation range: 80 meters |
| Solar panel | 18V/50W(Subject to extra charge) | 18V/100W(Subject to extra charge) |
| Physical | ||
| Operation Temperature | -15~50 ℃ | -15~50 ℃ |
| Operation Humidity | Relative humiditiy 20-90%,Non condensing | Relative humiditiy 20-90%,Non condensing |
| Noise | ≤40dB | ≤40dB |
| Net Weight | 10.6kgs | 8.2kgs |
| Dimensions(LXWXH)mm | 265x215x145mm | 265x215x145mm |
