Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Original
-
D/C:
-
New
-
Supplier Type:
-
Standard
-
Tolerance:
-
±20%
-
Operating Temperature:
-
-40°C ~ 150°C
-
Rated Power:
-
Standard
-
Package Type:
-
Surface Mount
-
Resistance Tolerance:
-
Standard
-
Temperature Coefficient:
-
Standard
-
Resistance:
-
53mOhm Max
-
Height - Seated (Max):
-
0.118" (3.00mm)
-
Package / Case:
-
Nonstandard
Quick Details
-
Type:
-
Inductor Surface Mount
-
Application:
-
Integrated Circuits
-
Model Number:
-
SRP5030TA-4R7M
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Original
-
D/C:
-
New
-
Supplier Type:
-
Standard
-
Tolerance:
-
±20%
-
Operating Temperature:
-
-40°C ~ 150°C
-
Rated Power:
-
Standard
-
Package Type:
-
Surface Mount
-
Resistance Tolerance:
-
Standard
-
Temperature Coefficient:
-
Standard
-
Resistance:
-
53mOhm Max
-
Height - Seated (Max):
-
0.118" (3.00mm)
-
Package / Case:
-
Nonstandard
Products Description
100% Original & New IC Chip SRP5030TA-4R7M 4.7uH Shielded Drum Core Wirewound Power Fixed Inductor 4.6A 53mOhm Max
Electronic Component
|
Product Model
|
SRP5030TA-4R7M
|
|
Type
|
Drum Core, Wirewound
|
|
Material - Core
|
Carbonyl Powder
|
|
Inductance
|
4.7 µH
|
|
Tolerance
|
±20%
|
|
Current Rating (Amps)
|
4.6A
|
|
Current - Saturation (Isat)
|
6A
|
|
Shielding
|
Shielded
|
|
DC Resistance (DCR)
|
53mOhm Max
|
|
Q @ Freq
|
15 @ 100kHz
|
|
Frequency - Self Resonant
|
23MHz
|
|
Ratings
|
AEC-Q200
|
|
Inductance Frequency - Test
|
100 kHz
|
|
Size / Dimension
|
0.224" L x 0.205" W (5.70mm x 5.20mm)
|
