Fresh Juice Mango Processing Plant Peeler Pulping Making Machine

Fresh Juice Mango Processing Plant Peeler Pulping Making Machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $180000

≥2 Sets

US $170000

≥3 Sets

US $160000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Dimension(L*W*H):: 20000*15000*6000

Weight:: 50000 KG

Place of Origin:: Jiangsu, China

Voltage:: 380V/415V/440V/460V Customer Design, 380V/415V/440V Customer Design

Power:: 150

Applicable Industries:: Fruit Deep Processing

After-sales Service Provided:: Overseas Service Provided

Function:: Mango pulp processing plant

Advantage:: Automatic

Core Components:: Tubular Sterilizer

Final product:: Mango Pulp

Warranty:: 1-2 Year

Certificate:: ISO 9001

Material:: 304 Stainless Steel

Quick Details

Machinery Capacity:: 3-8T/H

Brand Name:: QIANWEI

Year:: 2023

Dimension(L*W*H):: 20000*15000*6000

Weight:: 50000 KG

Place of Origin:: Jiangsu, China

Voltage:: 380V/415V/440V/460V Customer Design, 380V/415V/440V Customer Design

Power:: 150

Applicable Industries:: Fruit Deep Processing

After-sales Service Provided:: Overseas Service Provided

Function:: Mango pulp processing plant

Advantage:: Automatic

Core Components:: Tubular Sterilizer

Final product:: Mango Pulp

Warranty:: 1-2 Year

Certificate:: ISO 9001

Material:: 304 Stainless Steel

Product Overview

Mango Pulp/Juice PRODUCTION LINE

Processing flow：Mango receive -bubble washer-brush washer-sort- elevate-destoning-preheating-pulp -blending-sterilize-aseptic fill-store with normal temperature for 1 to 2 years

FEATURES AT A GLANCE

1、bubble washing machine：

2、brush washing machine

3、sorting machine

4、destoner machine

5、pre heating

6、pulping machine

7、blending system

8 、tube in tube sterilization machine

9 、aseptic filling machine

10 、store with normal temperature for 1 to 2 years

destoner

tubular sterilizer

aseptic filling

PRODUCT SPECIFICATIONS

No	Item	Data
1	Capacity	1-10 T/H
2	Mango Pulp Kind	Raw pulp，add concentration machine can do concentration jam，add blending tank can do mango juice
3	Package Style	Aseptic barrel
4	Need Steam Or Not	Yes
5	Need Compressed Air Or Not	Yes
6	Need Cooling Water Or Not	Yes
7	Shelf Time	1-2 Years
8	Machines Material	Contact Part 304

Main Machine-destoner

This Machine is specially used for mango pulp processing ，it is used for auto destone and depeel ，it is the most important machine is mango processing

Main Machine-Tubular Sterilization Machine

Used for tomato paste 、apple jam 、mango puree、chilli jam and other high viscosity and low
liquidity fruit & vegetables jam sterilization；the prouduct use tubular sterilizer work with aseptic filling machine together
can be stored for 1-2 years in room temperature.

Full Automatic Configuration: It adopts the advanced computer program controlling the PLC technology.

Main Machine- Aseptic Filling Machine

Online control with sterilizer, realize CIP and SIP. This aseptic filling machine mainly
consist by the aseptic filling head (one or two ), operating system, man-machine control system, flowmeter etc. the whole process
in a sterile environment.
The man-machine interface control, flow meter, Equipped with both manual and automatic two control system
Filling rooms unique design, avoid the condensed water dripping
