- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
WB-100S6
-
Certification:
-
CE
-
Output Voltage:
-
12V/24V
-
rotor diameter:
-
1.09m
-
Start wind speed:
-
2.0m/s
-
Model:
-
WB-100S6
-
Maximum Power:
-
130W
-
Rated Voltage:
-
12V/24V
-
Start-up Wind Speed:
-
2.0m/s
-
Rated Wind Speed:
-
10m/s
-
Safety Wind Speed:
-
55m/s
-
Net Weight of the Main Unit:
-
7kg
-
Rotor Diameter:
-
1.09m
-
Number of Blades:
-
3/5/6 Blades
Quick Details
-
Rated Power:
-
100W, 100W
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
WOBO
-
Model Number:
-
WB-100S6
-
Certification:
-
CE
-
Output Voltage:
-
12V/24V
-
rotor diameter:
-
1.09m
-
Start wind speed:
-
2.0m/s
-
Model:
-
WB-100S6
-
Maximum Power:
-
130W
-
Rated Voltage:
-
12V/24V
-
Start-up Wind Speed:
-
2.0m/s
-
Rated Wind Speed:
-
10m/s
-
Safety Wind Speed:
-
55m/s
-
Net Weight of the Main Unit:
-
7kg
-
Rotor Diameter:
-
1.09m
-
Number of Blades:
-
3/5/6 Blades
Brushless Excitation Hydro Turbine Generator Unit
Fast Delivery Ridge blade Wind Turbine 12V Permanent Magnet Engine 1 MW Wind Turbine for Offshore
Products Description
Product Paramenters
|
Model
|
WB-100S6
|
WB-200S6
|
WB-300S6
|
|||
|
Rated Power
|
100W
|
200W
|
300W
|
|||
|
Maximum Power
|
130W
|
220W
|
310W
|
|||
|
Rated Voltage
|
12V/24V
|
12V/24V
|
12V/24V
|
|||
|
Start-up Wind Speed
|
2.0m/s
|
2.0m/s
|
2.0m/s
|
|||
|
Rated Wind Speed
|
10m/s
|
11.5m/s
|
13m/s
|
|||
|
Safety Wind Speed
|
55m/s
|
55m/s
|
50m/s
|
|||
|
Net Weight of the Main Unit
|
7kg
|
7.3kg
|
7.5kg
|
|||
|
Rotor Diameter
|
1.09m
|
1.19m
|
1.29m
|
|||
|
Number of Blades
|
3/5/6 Blades
|
|
|
|||
|
Blade Material
|
Nylon Fiber
|
|
|
|||
|
Generator Type
|
Three-Phase AC Permanent Magnet Generator
|
|
|
|||
|
Magnetic Steel Material
|
NdFeB (Neodymium Iron Boron)
|
|
|
|||
|
Generator Casing Material
|
Die-Cast Aluminum
|
|
|
|||
|
Braking Method
|
Electromagnetic
|
|
|
|||
|
Wind Direction Adjustment
|
Automatic Wind-Facing Adjustment
|
|
|
|||
|
Operating Temperature
|
-40℃~80℃
|
|
|
|||
|
Note: For other power requirements, please contact us.
|
|
|
|
|||
