Hot Dipped Galvanized 1.8m High Security Fencing 358 Welded Wire Mesh Fencing Anti-Cut Anti Climb Fence with Razor Barbed Wire

Hot Dipped Galvanized 1.8m High Security Fencing 358 Welded Wire Mesh Fencing Anti-Cut Anti Climb Fence with Razor Barbed Wire

FOB Reference Price: Get Latest Price

≥100 Sets

US $89

≥1000 Sets

US $49

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: DD FENCE

Model Number:: DD-HF035

Product:: 358 Anti Climb Mesh Security Fence Price Per Meter

Fence height:: 1830mm,2130mm,2440mm,2740mm

Fence Width:: 2130mm,2440,2740mm,2900mm

Mesh size:: 76.2x12.7mm,75x12.5mm

Post:: C post, UC post,H post

Fence fitting:: Flat bar,top and bottom rail, shear off nut,washer,post cap

Fence Extension:: razor wire, barbed wire,Y arm,wall spikes,electric fencing

Fence standard:: BS1722-14

Surface treatment:: Galvanized+Powder Coated;hot dipped galvanized; HDG+powder coated

Quick Details

Frame Material:: Metal

Feature:: Easily Assembled, Sustainable, ECO FRIENDLY, Rodent Proof, Rot Proof, TFT, Waterproof

Place of Origin:: Hebei, China

Brand Name:: DD FENCE

Model Number:: DD-HF035

Product:: 358 Anti Climb Mesh Security Fence Price Per Meter

Fence height:: 1830mm,2130mm,2440mm,2740mm

Fence Width:: 2130mm,2440,2740mm,2900mm

Mesh size:: 76.2x12.7mm,75x12.5mm

Post:: C post, UC post,H post

Fence fitting:: Flat bar,top and bottom rail, shear off nut,washer,post cap

Fence Extension:: razor wire, barbed wire,Y arm,wall spikes,electric fencing

Fence standard:: BS1722-14

Surface treatment:: Galvanized+Powder Coated;hot dipped galvanized; HDG+powder coated

Product Description

358 Anti Climb Mesh Security Fence Price for Prison Airport Border Factory Railway Gas Pipelines Substation

Anti Climb Fence

Anti climb fence is a simple but strong enough and high security Panel fence system.

It including panel mesh ,post and accessories ,the panel mesh is welded with galvanized wire as per EN10244 or low carbon steel wire in high tensile strength, and the post variety is C post, UC post,H post,T post,square post,round post,rectangular post.

The bolts and nuts are stainless steel 304 , panel and post are powder coated with Akzo Nobel- Interpon 600 series powder and pass 500H-1000H salty spray followed by ISO9227.

Feature:
1, Attractive appearance or see through view

2, Rigid enough with perfect steel structure

3, Simple and easy installation

4, Alternative for both ground bury or flange installation
5, Suitable for flat ground and slope ground installation
6, High security protection and anti climb
7, Anti cutting and durable

8, Reference standard:BS1722-14,ISO1461,EN13438,EN10436

Application:

Secure wall is suitable for:

* Prison
* Power stations
* Government infrastructure projects
* Parks
* Factories
* Warehouses
* Sports facilities
* Commercial and industrial applications

* Airport

* oil-gas pipeline infrastructure

* Railway

* Harbor

Specification:

-- 2D Anti Climb Fence,3D Anti Climb Fence,2D plus with Double Horizontal/Vertical Wire Anti Climb Fence

Code	Style	Panel Size	Mesh	Wire	Post1	Post2	Post3
1111830	3D	1830*2740	76.212.7 7512.5	3+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1112130	3D	2130*2740	76.212.7 7512.5	3+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1112440	3D	2440*2130	76.212.7 7512.5	3+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1112740	3D	2740*2130	76.212.7 7512.5	3+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1121830	2D	1830*2440	76.212.7 7512.5	4+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1122130	2D	2130*2440	76.212.7 7512.5	4+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1122440	2D	2440*2130	76.212.7 7512.5	4+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post
1122740	2D	2740*2130	76.212.7 7512.5	4+4mm	76*64 C post	1001006*8 UC/H post	80*80 square post 76.2OD round post

Product Detail

Fence panel:

The fence panel is welded by our advanced automatic machine to give the fence high welded shear strength and more rigid after installation. wire diameter comes with 3mm,4mm,5mm, mesh size in 76.2*12.7mm or 75x12.5mm.

The surface treatment in hot dipped galvanized only; hot dipped gavanized+ polyester powder coating, pre galvanized+polyester powder coating as per EN13438, standard colors: RAL6005 Green,RAL9005 Black,RAL7040 Grey,RAL7016 Grey,RAL5002 Blue,other colors on request.

2D Anti Climb Fence with C Post

3D Anti Climb Fence with C Post

Anti Climb Fence with Wall Spike

UC/H Post 2D 358 Fence

UC Post with Angle Rail 358 Fence

UC Post with Razor Wire 358 Fence

T Post 358 Fence

I Post 358 Fence

Round Post 358 Fence

Post:

The C post is our unique design on fence market,it's shaped from galvanized coils as per EN10346.the post is rigid structure and attractive appearance. The post also comes in UC/H post,T post,I post,IPE post,round post and square post.

The surface treatment in hot dipped galvanized only; hot dipped galvanized+polyester powder coating;

pre galvanized+polyester powder coating as per EN13438, standard colors: RAL6005 Green,RAL9005 Black, RAL7040 Grey,RAL7016 Grey,RAL5002 Blue,other colors on request.

Accessories:

1. Installation Fittings: flat bar-H1 or steel clamp,top tail, bottom tail, bolt,shear off nut,washer,rain-hat. 2. Extension Fittings:razor wire, barbed wire,extension arm(single or double arm),wall spike.

3. Security Enhence Fittings: electric fencing system

Gate:

The gates for secure wall system variety:

1. Manual gate. single swing gate, double swing gate,sliding gate. 2. Automatic gate: single swing gate,double swing gate,sliding gate, cantilever gate.

Security Enhence Solution:

Electric fencing system can be supplied where the enhenced security required.

Product Manufacture

Production Flow:

1. Drawing wire

2. Test the wire strength,zinc coating,enlongation.

3. Cut and straighten wire to length

4. welded fence panel

5. Pre-treatment for powder coating or hot dipped galvanized
6. Powder coating as per EN13438 or hot dipped galvanized as per ISO1461

7. Quality checking

8. Packing

Quality Control

DD-FENCE

As a ISO9001 & ISO14001 certified company, DD-FENCE always supply high quality products to end users, and to ensure the consistency of the quality, we have spent a lot of efforts on selection and optimization of our raw material & fittings supply chain. In addition, we have also take more care of QC on each production procedure. Now the qualified rate of DD-FENCE products reached 99.5%. And products quality warranty ranged from 10-20 Years.

Product Packaging and Shipping

* Panel-Metal Pallet wrapped with cardboard plate and then wrapped with plastic film
* Post- Wrapped with PP bags,then put on pallet ,wrapped with plastic film
* Accessories- Carton
* Customized packing is available

Company Introduction

DD-FENCE

As one of the leading manufacturers on perimeter fencing products, DD-FENCE has more than Ten years running experience, and enjoy a high reputation in China fencing industry. Now our business covers: Steel or Aluminum Fencing, Cast Aluminum or Cast Iron fencing, as wells as kinds of swing or sliding gates.

Also as a ISO9001 & ISO14001 certified company, DD-FENCE always supply high quality products to end users, and to ensure the consistency of the quality, we have spent a lot of efforts on selection and optimization of our raw material & fittings supply chain. In addition, we have also take more care of QC on each production procedure. Now the qualified rate of DD-FENCE products reached 99.5%. And products quality warranty ranged from 10-20 Years.

Our main products : Iron wire welding type fence; Steel wire woven type fences; Tubular welding metal fence; Iron/steel/ Aluminum Tubular assembly type metal fences; Steel razor wire and steel barbed wire protective products ;metal gate and accessories.

Our main market at the moment : South Africa,Qatar, Iraq, Australia, United Arab Emirates,United States, Brazil, Turkey, Nigeria and so on.

Certificates: ISO9001,ISO14001,OHSAS18001,sgs cerificate,tuv certificate.

FAQ

Q1: DD-Fence are manufacturer of trading company?
A1: We are produce metal fencing products ourself.

Q2: Where is DD-Fence’s factory?
A2: Raoyang County ,Hebei Province,China.

Q3: How many years manufacturing experience DD-Fence have ?
A3: 10 years.

Q4: How many staff working in DD-Fence?
A4: DD-Fence have 126 staff.

Q5: How many square meters of you factory?
A5:DD-Fence plant area: 32000 square meters.

Q6:What’s DD-Fence’s main products?
A6:Main products are:
Mesh wire welding type panel fences;
Chain Link Fence;
Tubular Fences;
Razor wire and barbed wire protective products,
Gate System and gate accessories.

Q7:DD-Fence have technique support on installation ?
A7: Yes ,we have professional engineer for installation guide service.

Q8: Which countries have you exported your products to ?
A8: : South Africa, Qatar, Iraq, Australia, the united Arab emirates, the United States, Brazil, Turkey, Nigeria, Benin, Sudan, B
ahrain, Saudi Arabia, Mozambique, Singapore, Britain, Russia, Turkmenistan, Lithuania, Romania, Colombia, Cyprus, Kenya,
Zambia,Uganda, Algeria, equatorial guinea, Mauritius, Angola and so on.

Q9: What’s your payment term for new client?
A9: Option one: Payment through Alibaba Trade assurance.
Option two: 30% Deposit in advance ,the balance against copy of LC.
Option three:100% L/C at sight .
Option four: Negotiable of usance LC at 60 days,90 days or 120 days.

If you have any interest or questions, pls feel free to contact me.
Your detailed inquiry to Bruce, will get reply within 24Hours!
