Weight: ≤450g
Body size: 85mm*56mm*93mm (max)
- Product Details
- {{item.text}}
Quick Details
-
contact material:
-
AgCuO/AgCdO
-
structure:
-
Single Coil
-
coil voltage:
-
12-120V
-
Certifications:
-
TUV CCC CE RoHS
Quick Details
-
Contact Load:
-
Low Power
-
Place of Origin:
-
Zhejiang, China
-
rated current:
-
200A
-
contact material:
-
AgCuO/AgCdO
-
structure:
-
Single Coil
-
coil voltage:
-
12-120V
-
Certifications:
-
TUV CCC CE RoHS
Product Description
ODOELEC MZJ-200A 12v 24v 48 volt dc solenoid forklift contactor relay manufacturer
The product have one normally open contact, for electric vehicles, telecommunication equipment, engineering machinery, car batteries, electric forklift trucks, trains, ships, electronic control systems such as uninterruptible power supply.
Detailed Images
ODOELEC MZJ-200A 12v 24v 48 volt dc solenoid forklift contactor relay manufacturer
Circuit Diagram
Technical Parameters
|
Rated Voltage
|
12V, 24V, 36V, 48V, 60V, 72V, 84V, 120V, etc.
|
|
|
||
|
Contact circuit rated load current (A)
|
200A
|
|
|
||
|
Typical voltage drop across contacts per 100A
|
≤80mV
|
|
|
||
|
Under (20±5℃), Cooling Pull-in Voltage
|
≤70%
|
|
|
||
|
Under (20±5℃), Cooling Release Voltage
|
≤40%, ≥5%
|
|
|
||
|
Acceptable Fluctuation Range of Coil Voltage
|
±20%
|
|
|
||
|
Electrify Time
|
≤30ms
|
|
|
||
|
Disconnecting Release Time
|
≤20ms
|
|
|
||
|
The Max Disconnecting Time of Contacts
|
≤5ms
|
|
|
||
|
Insulation Resistance
|
≥50MΩ
|
|
|
||
|
Dielectric Strength
|
50Hz/60Hz 1000VAC/1min
|
|
|
||
|
Overload Current
|
≤7Ie, ≤1s
|
|
|
||
|
Coil Consumption (W)
|
≤6.5W
|
|
|
||
|
Electrical Life
|
20000 times
|
|
|
||
|
Mechenical Life
|
300,000 Times
|
|
|
||
|
Working Mode
|
Continuous
|
|
|
||
|
Contacts Type
|
1 NO
|
|
|
||
|
Contact Material
|
AgCdO / AgCuO
|
|
|
||
|
Auxiliary Contact Rated Load
|
2A/48VDC, 5A/24VDC
|
|
|
||
|
Technical Standard
|
GB14048.4-2010
|
|
|
||
Application
Installation Diagram
