- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
KHT
-
Model Number:
-
KHT-SO-50A, KHT-SO-50A
-
Work Time (h):
-
300000
-
Max PV Power:
-
150w
-
Max PV Voltage:
-
18v
-
Certificate:
-
ce
-
Warranty:
-
3, 2 Years
-
Voltage:
-
DC12V -24V
-
Product Name:
-
solar charger controller
-
Control Mode:
-
Intelligent Control
-
Charge mode:
-
3-Stage PWM Charge
-
System voltage:
-
12v/24v Automatic Recognition
-
Certification:
-
CE RoHS ISO9001
-
Battery type:
-
Lithium Battery
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KHT
-
Model Number:
-
KHT-SO-50A, KHT-SO-50A
-
Work Time (h):
-
300000
-
Max PV Power:
-
150w
-
Max PV Voltage:
-
18v
-
Certificate:
-
ce
-
Warranty:
-
3, 2 Years
-
Voltage:
-
DC12V -24V
-
Product Name:
-
solar charger controller
-
Control Mode:
-
Intelligent Control
-
Charge mode:
-
3-Stage PWM Charge
-
System voltage:
-
12v/24v Automatic Recognition
-
Certification:
-
CE RoHS ISO9001
-
Battery type:
-
Lithium Battery
For floodlight street light12V- 24V 3A 7A 10A 15A 50A light control waterproof cheap price PWM solar charge controller
Solar controller for 50W street light
Solar panel ( 6v monocrystalline ) Connetted to 3.2v Iron phosphate-lithium battery
1. Forcely switch (this function just show to customer . or working on the forcely needs)
1.1 pressed the on button, and then pressed the off button (on daytime, it will delay 30s after you switch on/off button)
1.2 After pressing the on/off . then pressed. 2H (hours) ,4H, 6H .8H with 30s. then the starting time is 2H .4H. 6H .8H
1.3 With the forcely mode on daytime , the next time will on Auto mode.
2, A uto Mode ( flashing 3 times after pressing on/off)
2.1 The light will turn on by auto after 10s daytime to dark time
2.2 The light will turn off by auto after 30s dark time to daytime (to avoid the flashing by the critical point dark time and daytime
2.3 lighting time when you set up 2H,4H,6H,8H ,after reaching the setting time, light will turn off by auto, if you do not set up ,the lighting time is 8 hours, the set up time is recorded or you set up again
3. Brightness dimming
3.1 up button, increasing 10% , flashing 3 times when on the max brightness
3.2,down button, reducing 10%, flashing 3 times when on the min brightness
In order to keep on lighting time ,it will reduce 1% in every 10 mintues , util to reduce 40% to stop ,after a daytime ,it will be automatic reset,
4. Check the setting hours
Pressing the middle button, flashing time is 1 time as 2H, flashing 2 times as 4H, flashing 3 times as 6H, flashing 4 times as 8H.
5. the left and right button ,without any function
6. this program with watchdog program ,if program is abnormity ,it will be automatic reset.
Solar controller for floodlight
| item | paratner | power | solar panel | battery | smd chip | housing | solar panel | working area |
| 1 | T-2w | 3W | 10W | 6000MAH | 25pcs | AL | 6V/10W | 40 m2 |
| 2 | T-4W | 4W | 40W | 8000mAH | 40pcs | AL | 6V/10W | 60 m2 |
| 3 | T-6W | 6W | 60W | 10000mAH | 60pcs | AL | 6V/15W | 80 m2 |
| 4 | T-8W | 8W | 80W | 12000mAH | 80pcs | AL | 6V/18W | 100 m2 |
| 5 | T-12W | 12W | 120W | 15000mAH | 120pcs | AL | 12V/20W | 200 m2 |
other related product
1. We can according to your requirement to design
2. we can with SKD serivce
3 .for solar light ,the most imformation ,it is the improve the effiency the solar efficiency and the Li battery store capactior ,for our solar street ,we use our solar controller ,it can improve 30% solar charging efficiency for current other solar light ,aslo we use the original Ternary18650 Li battery ,about the solar panel ,we can customized for you by monocrystal or polycrystal .polycrystal with high efficiency charging .
solar controller -----------------------our egnineer design and with high efficiency translation (can show you the solar vedio )
18650 Li battery. -----------------------Original Ternary 18650 Li battery
solar panel ----------------------monocrystal or polycystal (can be choose)
street body---------------------------------ABS plastic or die casting
Radar sensor-------------------------------the detect diatance can 5-10M ,and when detected human,the light turn 100%,after human leave ,the light turn 30%,
The most important thing is the choose the right 18650 li battery and solar panel ,
Q1: What products you main business?
A1: We are led driver and driveless manufacutre ,we can supply the PCBA ,aslo can supply SKD for led tube light, led flood light, etc.
Q2: How about your quality?
A2: Our company is manufacture , use top quality material to make sure stable quality and enough brightness, we supply high cost performance products. Every product passed aging test well then delivery to every client.
Q3: How long the wattanty?
A3: We supply 2-5 years warranty. Once you find quality problem from our company during warranty period, please supply us pictures or video to confirm, if it's our quality problem, we will send you relacement, don't undertake shipping cost.
We are looking for worldwide distributors and cooperation companies, if any questions or interest, please don't heasitate to contact us now!
