Quick Details
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
4000-4500k, 2800-6500K
-
Color Rendering Index(Ra):
-
80,90
-
Input Voltage(V):
-
AC100-240V
-
Lamp Luminous Flux(lm):
-
4500lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
80000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CART
-
Model Number:
-
YLL-PF06
-
Product name:
-
RGBCCT led panel light
-
Shape:
-
Square Shape
-
Power:
-
36W
-
Keyword:
-
rgb+cct led panel light
-
LED Chip:
-
Taiwan Epistar
-
Beam angle:
-
120 Degree
Quick Details
-
Lamp Luminous Efficiency(lm/w):
-
80lm/w,90lm/w, 85
-
Application:
-
Bedroom
-
Lamp Body Material:
-
Aluminum Alloy
-
Warranty(Year):
-
5-Year
-
Color Temperature(CCT):
-
4000-4500k, 2800-6500K
-
Color Rendering Index(Ra):
-
80,90
-
Input Voltage(V):
-
AC100-240V
-
Lamp Luminous Flux(lm):
-
4500lm
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 50
-
Working Lifetime(Hour):
-
80000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CART
-
Model Number:
-
YLL-PF06
-
Product name:
-
RGBCCT led panel light
-
Shape:
-
Square Shape
-
Power:
-
36W
-
Keyword:
-
rgb+cct led panel light
-
LED Chip:
-
Taiwan Epistar
-
Beam angle:
-
120 Degree
Products Description
|
R
G
B/RGBW/RGBCCT Led Panel Light Dimmension
|
|
|
|
|
|
|||||
|
Type
|
Size
|
Power
|
Voltage
|
CCT
|
CRI
|
|||||
|
EU SIZE
|
295*295mm
|
18W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
|
295*595mm
|
18W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
|
595*595mm
|
36W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
|
295*1195mm
|
36W
|
24V
|
RGB/RGBWRGB+CCT
|
>80
|
|||||
|
|
595*1195mm
|
60W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
US SIZE
|
301*1213mm
|
36W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
|
603*603mm
|
36W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
|
603*1213mm
|
60W
|
24V
|
RGB/RGBW/RGB+CCT
|
>80
|
|||||
|
R
G
B/RGBW/RGBCCT Led Panel Light Product Parameters
|
|
|
|
Input Voltage:
|
AC100-240V/AC85-265V
|
|
|
Light Efficiency:
|
80lm/w,90lm/w
|
|
|
PF/CRI:
|
PF>0.6/0.9, CRI>80,90
|
|
|
Lighting Design:
|
Side Emitting
|
|
|
Beam Angle:
|
120Degree
|
|
|
Color Temperature(CCT):
|
RGB
RGB+W 3000-3500k/4000-4500k/6000-6500k
RGB+CCT(2700-6500k)
|
|
|
Working Temp.:
|
-20-+45C
|
|
|
Driver Type:
|
Isolated power driver
|
|
|
IP Rating:
|
IP40 Grade
|
|
|
Lamp Installation:
|
Recessed Ceiling, Surface Mounting, Wire Suspending
|
|
|
Product Material:
|
Aluminum Alloy Frame + PMMA LGP + PS diffuser
|
|
|
Dimming Controller
|
IR remote,2.4g RF remote, WIFI, Bluetooth and DMX control
|
|
|
Lamp Life Span:
|
Over 50000hours, 3 years warranty
|
|
|
Frame Color:
|
White,Black and Sliver
|
|
|
Certificate:
|
CE,ROHS,ETL
|
|
Y L L rgbcct led panel light advantage:
1.Instant on/off, no noise, no UV, no light leak, no shadow
2.PMMA GLP+PC diffuser + 6063 aluminum frame, silver/white color available
3.Non-dimming, 0~10v dimming, cct dimming, DALI, Meanwell, UGR<19
4.Support recessed, suspended, surface mounted installation
5.Good compatible driver,for the wide range of Voltage and Frequency, adaptable for public grid, apply to most countries and regions
6.The lamp in light-weight,easy installation and replacement,friendly-environment,safety,non-pollution,meet CE and ROHS standard
7.It can compitable with wifi/zigbee/bluetooth/dmx512 .
2.PMMA GLP+PC diffuser + 6063 aluminum frame, silver/white color available
3.Non-dimming, 0~10v dimming, cct dimming, DALI, Meanwell, UGR<19
4.Support recessed, suspended, surface mounted installation
5.Good compatible driver,for the wide range of Voltage and Frequency, adaptable for public grid, apply to most countries and regions
6.The lamp in light-weight,easy installation and replacement,friendly-environment,safety,non-pollution,meet CE and ROHS standard
7.It can compitable with wifi/zigbee/bluetooth/dmx512 .
Product Detail
Connection
Installation
Y L L wholesale price square led panel light Installation:
1. This product should be installed by trained electricians
2. Check integrality of the products when unpack the packing
3.The distance between the light and any flammable materials must not be lessthan 0.2m.
4. The ceiling must not be less than 2cm.The light must not be installed into ceilings or walls that contain heat-insulating material.
5. The main cable must not connect with the low voltage cable or the surface- mounted lights.
6. Guide the lights’connecting cables through the drilled-out hole, and fix the surface mounted lights with the pre fitted clips.Make sure that these are securely connected to the base material
2. Check integrality of the products when unpack the packing
3.The distance between the light and any flammable materials must not be lessthan 0.2m.
4. The ceiling must not be less than 2cm.The light must not be installed into ceilings or walls that contain heat-insulating material.
5. The main cable must not connect with the low voltage cable or the surface- mounted lights.
6. Guide the lights’connecting cables through the drilled-out hole, and fix the surface mounted lights with the pre fitted clips.Make sure that these are securely connected to the base material
