Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LUNA
-
Input Voltage:
-
90V-280V
-
Output Voltage:
-
220V/230V /240V
-
Output Current:
-
60A
-
Output Frequency:
-
50/60Hz
-
Size:
-
512*320*136MM, 512*320*136MM
-
Certificate:
-
CE TUV
-
Warranty:
-
5 Years
-
Weight:
-
11.5kg/12kg
-
Output Type::
-
Single
-
Output Frequency::
-
18.2A
-
MPPT Efficiency::
-
98-99%
-
Apllication:
-
Energy Storage System
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
-
Display::
-
LCD Display
-
Protection:
-
Short Circuit Protection Overload
-
Certification:
-
CE/ROHS/MSDS
-
MOQ:
-
1 Pc
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
99.5%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LUNA
-
Input Voltage:
-
90V-280V
-
Output Voltage:
-
220V/230V /240V
-
Output Current:
-
60A
-
Output Frequency:
-
50/60Hz
-
Size:
-
512*320*136MM, 512*320*136MM
-
Certificate:
-
CE TUV
-
Warranty:
-
5 Years
-
Weight:
-
11.5kg/12kg
-
Output Type::
-
Single
-
Output Frequency::
-
18.2A
-
MPPT Efficiency::
-
98-99%
-
Apllication:
-
Energy Storage System
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
-
Display::
-
LCD Display
-
Protection:
-
Short Circuit Protection Overload
-
Certification:
-
CE/ROHS/MSDS
-
MOQ:
-
1 Pc
Specification
|
Model
|
VC1000VA
|
VC1500VA
|
VC2000VA
|
VC3000VA
|
VC5000VA
|
VC6000VA
|
|||||
|
Input Voltage(DC)
|
12V/24V
|
|
24V/48V
|
24V/48V
|
|
48V
|
|||||
|
Nominal Voltage
|
220VAC(Standard)
|
|
|
|
|
|
|||||
|
Rated Power
|
800W
|
1200W
|
1600W
|
2400W
|
4000W
|
4800W
|
|||||
|
Battery Type
|
VRLA / GEL /GEL DEEP CYCLE/LITHIUM
|
|
|
|
|
|
|||||
|
Maximum pv array power
|
720W
|
|
1400W/2800W
|
|
|
3400W
|
|||||
|
Waveform
|
Pure Sine Wave
|
|
|
|
|
|
|||||
|
PV Input Voltage Range (PWM Controller)
|
15VDC-33VDC
|
|
30VDC-66VDC
|
|
|
60VDC-150VDC
|
|||||
|
Transfer Time
|
<8ms(UPS mode)/<20ms (INV mode)
|
|
|
|
|
|
|||||
|
Max PV charging current
|
60A
|
|
|
|
|
|
|||||
|
Max AC charging current
|
20A
|
30A
|
20A/10A
|
30A/15A
|
55A/28A
|
30A
|
|||||
|
MPPT control voltage range
|
18V-150V
|
|
34V-150V/68V-150V
|
|
|
60V-150V
|
|||||
|
Static power(W)
|
5W
|
11.5W
|
13W
|
15W
|
20W
|
TBA
|
|||||
|
Protections
|
Power supply: Input overcurrent protector
|
|
|
|
|
|
|||||
Packing information
|
Inverter
|
pcs/carton
|
UPS size
(mm)
|
packing size
(mm)
|
Net
Weight(kg)
|
Gross
Weight(kg)
|
20GP 40GP
(28CBM) 68CBM
|
|
LNGA2024
|
1
|
470*335*210
|
|
12.4
|
14.6
|
530pcs 1300pcs
|
|
LNGA3024M
|
1
|
|
|
13.5
|
14.6
|
|
|
LNGA1012M
|
1
|
|
|
15
|
16
|
|
|
LAGA1512M
|
1
|
|
|
18
|
20
|
|
|
LNGA5048M
|
1
|
|
|
21.5
|
22.3
|
|
