Quick Details
-
Injection Rate (g/s):
-
140 g/s
-
Injection Weight (g):
-
187 g
-
Screw Speed (rpm):
-
0 - 300 rpm
-
Screw diameter (mm):
-
36 mm
-
Weight (KG):
-
5500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
280 mm
-
Model Number:
-
V120
-
Brand Name:
-
Lichuang
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
Thermoplastic
-
Machine Color:
-
White and Green
-
Motor:
-
Servo Energy Saving Motor
-
Language:
-
According to customer's country
-
Transport Package:
-
Customized
-
Nozzle Projecting Template Size:
-
≥45mm
-
Machine Height:
-
2000mm
-
Max. Injection Pressure:
-
180(1838)Mpa(kgf/ cm2 )
-
Oil tank capacity:
-
340L
-
After-sales Service Provided1:
-
Spare Parts Online Support
Quick Details
-
Ejector Stroke(mm):
-
45 mm
-
Ejector Force(kN):
-
13.7 kN
-
Theoretical Shot Volume(cm³):
-
201 cm³
-
Injection Rate (g/s):
-
140 g/s
-
Injection Weight (g):
-
187 g
-
Screw Speed (rpm):
-
0 - 300 rpm
-
Screw diameter (mm):
-
36 mm
-
Weight (KG):
-
5500 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
280 mm
-
Model Number:
-
V120
-
Brand Name:
-
Lichuang
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
Thermoplastic
-
Machine Color:
-
White and Green
-
Motor:
-
Servo Energy Saving Motor
-
Language:
-
According to customer's country
-
Transport Package:
-
Customized
-
Nozzle Projecting Template Size:
-
≥45mm
-
Machine Height:
-
2000mm
-
Max. Injection Pressure:
-
180(1838)Mpa(kgf/ cm2 )
-
Oil tank capacity:
-
340L
-
After-sales Service Provided1:
-
Spare Parts Online Support
Product Description
Specification
|
item
|
value
|
|
Plastic Processed
|
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid
|
|
Condition
|
New
|
|
Ejector Stroke(mm)
|
45mm
|
|
Ejector Force(kN)
|
13.7kN
|
|
Theoretical Shot Volume(cm³)
|
201cm³
|
|
Injection Rate (g/s)
|
140g/s
|
|
Machine Type
|
Hydraulic
|
|
Injection Weight (g)
|
187g
|
|
Screw Speed (rpm)
|
0rpm - 300rpm
|
|
Screw diameter (mm)
|
36mm
|
|
Weight (KG)
|
5500kg
|
|
Type
|
Preform Injection
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Open Stroke(mm)
|
280mm
|
|
Model Number
|
V120
|
|
Brand Name
|
Lichuang
|
|
Power (kW)
|
18.5kW
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
Easy to Operate
|
|
Applicable Industries
|
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company
|
|
Showroom Location
|
Viet Nam
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Warranty of core components
|
1 Year
|
|
Core Components
|
Bearing, Motor, Pump, Gear
|
|
Plastic Type
|
Thermoplastic
|
|
Machine Color
|
White and Green
|
|
Motor
|
Servo Energy Saving Motor
|
Packing & Delivery
Packing:
Machine packing inside is plastic films and outside is fumigation wooden case.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine
corrosion.
Delivery:
For machines are big and heavy parcel, and different country with different delivery cost,so we suggest below delivery solution:
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
For machines are big and heavy parcel, and different country with different delivery cost,so we suggest below delivery solution:
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
Our Advantages
Dongguan Strong Machine Co., LTD is a modern enterprise with integration of researching, developing, manufacturing and selling for vertical injection molding machine.
The machine is widely used in electronics, daily products, household products, auto industry, lighting, entertainment and so on. The main varieties of ts making products includes plugs, cable injection, LED inserting,phone frame, dental floss picks, silicone nipples, golf balls, air filters, toothbrush handle, shoe insole, puller, eyeglasses frame, hanger and other plastic molding products.
Equipped with enthusiasm sales team, professional technician team as well as 24 hours pre-sale and after-sale services team for customers, we have the honor to establish cooperation with many countries such as Singapore, Malaysia, Indonesia, Vietnam, India, Pakistan, Algeria, South Korea, Japan, Argentina, Colombia, Ukraine, Russia.
Quality is our culture. We are confident that we can make improving development in the future and we can offer you better service for you.
Since its inception, STRONG MACHINE has been devoted to optimization and integration of developing, producing, sealing, and application of technology of ultrasonic and injection molding machinery. After almost twenty years of unremitting efforts, STRONG MACHINE with high quality products, excellent technical support and perfect after-sales service has established a good reputation among the customers, and also gains a number of provincial and national honors.
FAQ
Q: What is the warranty of the machine ?
A: The whole machine' s warranty period is 24 months and key parts will be depended.
Q: Are you an integrated supplier for injection molding machine, mold, robot and auxiliary?
A: Yes, we can provide the complete solution line to customer according to customer' s requirement.
Q: Will you offer the pre-sales service?
A: Yes, we have an experienced pre-sales team to support customers not only including machine, mold and auxiliary selection but also water electrical, machine layout in factory, etc.
Q: What is the delivery time of the machine?
A: Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery time of standard machine could be within 1-2 month
Q:What should I do if we are not able to operate the machine when we receive it?
A:Operation manual and video demonstration sent along with the machine to give instructions. Besides, we have professional after-sale group to customer's site to solve any problems.
\n
Pre-sale services:
1. Providing professional technical support.
2. Send the product catalog and instruction manual.
3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!
4. Personal call or visit are warmly welcome
1. Providing professional technical support.
2. Send the product catalog and instruction manual.
3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!
4. Personal call or visit are warmly welcome
Sale of services:
1. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.
2. We guarantee punctuality, quality and quantities strictly implement the terms of contract.
1. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.
2. We guarantee punctuality, quality and quantities strictly implement the terms of contract.
After-sales service
:
1. Where to buy our products for 1 years warranty and life long maintenance.
2. 24-hours telephone service.
3. A large stock of components and parts, easily-worn parts
1. Where to buy our products for 1 years warranty and life long maintenance.
2. 24-hours telephone service.
3. A large stock of components and parts, easily-worn parts
