Quick Details
-
Brand Name:
-
SUNBOND
-
Model Number:
-
25.6V18Ah460.8WH, 12.8V 50Ah lithium ion li ion lifepo4 battery
-
Place of Origin:
-
GUANGDONG
-
Weight:
-
6KG, 6.3KG
-
The charging ratio:
-
1C
-
The discharge rate:
-
1-10C
-
Electric Energy:
-
460.8 Wh
-
Certification:
-
ISO9001,CNAS,CE,ROHS,FCC,MSDS,UN38.3,IEC,BIS,CB
-
Size:
-
L229*W138*H208(mm)
-
Communication Protocol:
-
RS485/RS232/CAN(Customized)
-
Charging current:
-
25A(0.5c)(customized available)
-
Discharge current:
-
50A(1c)(customized available)
-
Terminal:
-
M6
-
Discharge cut-off voltage:
-
10V
-
Max.Pulse Current:
-
150A
Quick Details
-
Storage Type:
-
0-45
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, Consumer Electronics, BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
SUNBOND
-
Model Number:
-
25.6V18Ah460.8WH, 12.8V 50Ah lithium ion li ion lifepo4 battery
-
Place of Origin:
-
GUANGDONG
-
Weight:
-
6KG, 6.3KG
-
The charging ratio:
-
1C
-
The discharge rate:
-
1-10C
-
Electric Energy:
-
460.8 Wh
-
Certification:
-
ISO9001,CNAS,CE,ROHS,FCC,MSDS,UN38.3,IEC,BIS,CB
-
Size:
-
L229*W138*H208(mm)
-
Communication Protocol:
-
RS485/RS232/CAN(Customized)
-
Charging current:
-
25A(0.5c)(customized available)
-
Discharge current:
-
50A(1c)(customized available)
-
Terminal:
-
M6
-
Discharge cut-off voltage:
-
10V
-
Max.Pulse Current:
-
150A
12V 50Ah Product Paramenters
|
Item
|
Parameter
|
|
Nominal Voltage
|
12.8V
|
|
Nominal Capacity
|
50Ah
|
|
Cell
|
3.2V 50Ah Prismatic Cell with UL
|
|
Configuration
|
4S1P
|
|
Maximum Continuous Discharge Current
|
50A
|
|
Maximum Continuous Charging Current
|
50A
|
|
Recommed Charging Current
|
25A
|
|
Discharge Cut-off Voltage
|
10V
|
|
Charge Cut-off Voltage
|
14.6V
|
|
BMS
|
Built-in 50A BMS
|
|
Cycle Life
|
6000 Times
|
|
Housing
|
ABS(Metal Optional)
|
|
Net Weight
|
6KG
|
|
Gross Weight
|
7KG
|
|
Dimension
|
229*138*208mm(can customized)
|
|
IP rate
|
IP65(IP66/IP67/IP68 Optional)
|
|
Communication method
|
RS485*1(RS232/CAN /BUS optional)
|
|
Indicator
|
Optional(Touch Screen Display/Button Display Optional)
|
|
Bluetooth
|
Optional
|
|
Equalization function
|
Yes,passive equalization(external equalizer can be added)
|
|
Operating temperature
|
-20℃-60℃
|
|
Charging Temperature
|
0℃-45℃
|
|
Parallel Conntectable
|
Yes(UP TO 32 Optional)
|
|
Series Connectable
|
Optional
|
Product Details Show
brand new,A grade.3.2V 50Ah Cell
High Quality Smart BMS
Waterproof glue,
IP67 can be achieved
12V 50Ah
Finished Battery with RS485(RS232/CAN/BUS Optional)
12V 50Ah Finished Battery with Bluetooth,
Mobile APP to check battery status
Our Advantages
High Quality Smart BMS
Prevent battery overcharge, overdischarge, overcurrent, short circuit, balance cells and
High and low temperature protection
other functions, greatly extending the battery life.
Laser Spot Welding
cells has passed UL1642 certification, and the process adopts laser spot welding, which effectively reduces the internal resistance of the finished battery.
Real-time Monitoring
RS485/RS232/CAN/BUS,
multiple communication methods are optional, Bluetooth APP, real-time monitoring of battery status
Super long service life
Over 5000-6000 cycles, ten years of service, no maintenance, friendly environment.
Lithium Battery Manufacturer
We have a lithium battery factory, a strong R&D team,
factory direct sales,battery support OEM/ODM service.
Applications
Support 12V 24V 48V Solar Energy System(ESS)
Home Solar Energy System
12 Volts home solar energy system,the
battery supports series connection to form 24V/48V solar energy system, and parallel connection to form 100Ah/200Ah/300Ah capacity.
Solar CCTV Camera
The battery can be used for outdoor and indoor CCTV Camera, which can reach IP65/IP66/IP67 dustproof and waterproof level, providing 24 hours a day for the monitor.
Solar Mobile Base Station
SUNBOND can provide 12V 24V 48V 50Ah 100Ah 200Ah 300Ah lifepo4 battery for solar mobile base station, mobile base station...
Power supply for telecom base stations,
Uninterruptible Power Supply(UPS)
Solar Street Light
Provide different capacity 12V 2500mAh 5000mAh 10Ah 20Ah 30Ah 50Ah 60Ah 100Ah 200Ah 300Ah LiFePO4 Battery, which can be used for different types of solar street lights, solar signal lights, LED, stage lights...
Solar RVs/Motorhomes/Camping/Caravan
12V 50Ah LiFePO4 battery can be used for 12V 24V 48V solar RV system, custom series and parallel functions, lithium iron phosphate has high energy density, light weight, and can monitor battery status in real time through mobile phone.
Electric Boat/Marine/Yacht/Trolling Motor
Provide ample power supply for your electric boat, up to 32 12V 50Ah battery packs can be connected in parallel, providing 100Ah 200Ah 300Ah... capacity. The battery can achieve IP66/IP67/IP68 waterproof rating.
Related Products
|
|
SUNB-LF12100
|
SUNB-LF12200
|
||
|
Nominal Voltage
|
12.8V
|
|
||
|
Nominal Capacity
|
100Ah
|
200Ah
|
||
|
Eenergy
|
1280Wh
|
2560Wh
|
||
|
|
|
|
||
|
Self Discharge
|
3% per month
|
|
||
|
Max Continuous Discharge
|
100A(Optional)
|
150A(Optional)
|
||
|
Peak Current
|
300A
|
450A
|
||
|
Discharge Cut-off Voltage
|
10V
|
|
||
|
Discharge Temp Range
|
-10F to 140F(-20℃-60℃)
|
|
||
|
|
|
|
||
|
Recom. Charging Current
|
20A
|
40A
|
||
|
Max Charging Current
|
50A
|
100A
|
||
|
Charge Cut-off Voltage
|
14.6V
|
|
||
|
Charging Temp. Range
|
34F to 130F(0℃-55℃)
|
|
||
|
|
|
|
||
|
Cell Chemistry
|
Lithium Iron Phosphate(LiFePO4)
|
|
||
|
Cell Type
|
3.2V 100Ah Prismatic Cell
|
3.2V 100Ah Prismatic Cell
|
||
|
Cell Configuration
|
4S1P
|
4S2P
|
||
|
Series Connectable
|
Optional
|
|
||
|
Parallel Connectable
|
Yes(Up to 32 optional)
|
|
||
|
Protocol
|
RS4850(RS232/CAN/BUS Optional)
|
|
||
|
Bluetooth
|
Optional
|
|
||
|
Heating function
|
Optional
|
|
||
|
LCD
|
Yes(Optinal touch screen indicator)
|
|
||
|
Weight
|
12KG
|
25KG
|
||
|
Dimensions LxWxH
|
330*173*216mm
|
521*238*218mm
|
||
|
Terminal Type
|
M8
|
|
||
|
Shell Type
|
ABS
|
|
||
About Us
Guangdong Sunbang Technology Co.,Ltd.
Guangdong Sunbang Technology Co., Ltd.is focused on manufacturing, R&D and selling high quality lithium iron phosphate(LiFePO4)battery, lithium polymer battery, NCM lithium battery and power solutions, striving to grow into a global leading lithium battery supplier.
With the registration and certification of CE,UL, MSDS, UN38.8, the company has been working hard on researching and developing new process technology to make our lithium battery more affordable and able to meet the rapidly growing market demands.
With the registration and certification of CE,UL, MSDS, UN38.8, the company has been working hard on researching and developing new process technology to make our lithium battery more affordable and able to meet the rapidly growing market demands.
Production Projects
12V 50Ah and 100Ah Lithium Battery
12V 100Ah Lithium Battery
12V 200Ah Lithium Battery
12V 200Ah Lithium Battery
12V 200Ah Lithium Battery
12V 300Ah Lithium Battery
FAQ
1.Can your battery be customized?
Yes. We are a lithium battery factory in China, support OEM/ODM service.
2.How long will it take me to receive the goods?
2.How long will it take me to receive the goods?
If the battery you want needs to be customized, the production time is 15 days. If it is in stock, we will ship it to you within three days. The transportation time by air and express is 10-15 days,and the shipping time is 30 days.
3.Can your batteries be connected in series and parallel?
3.Can your batteries be connected in series and parallel?
Our company’s batteries can be connected in parallel. it is not recommended to connect batteries in parallel with other manufacturers’ batteries.
4.My previous battery was a lead-acid battery. Can I continue to use the previous charger after replacing it with a lithium-ion battery?
8.How long is your warranty?
5 Years
9.The quality of the battery cell you use?
We are using brand new grade A battery cell.
4.My previous battery was a lead-acid battery. Can I continue to use the previous charger after replacing it with a lithium-ion battery?
No. Need to buy a lithium-ion battery charger.
5.How do I know the battery voltage I need?
You can look at the manual of your golf cart, which describes the voltage and capacity of your battery.
6.How to determine the capacity I need?
5.How do I know the battery voltage I need?
You can look at the manual of your golf cart, which describes the voltage and capacity of your battery.
6.How to determine the capacity I need?
1. Give me the power of your motor and the voltage of the controller.
2. Give me space for
you to store the battery.
you to store the battery.
3. Give me your budget. We will give you the most suitable plan based on your above information.
7.How should I handle or protect my battery?
7.How should I handle or protect my battery?
Before use, please check the product data sheet we sent you. Although the lifepo4
material is relatively stable and not much dangerous, for the life of your battery, please follow the precautions in the data
sheet.
8.How long is your warranty?
5 Years
9.The quality of the battery cell you use?
We are using brand new grade A battery cell.
