Quick Details
-
Brand Name:
-
JIAKE
-
Model Number:
-
Z94-1C/2C/3C/4C/5.5C/6.5C
-
Weight (KG):
-
2500
-
Power (kW):
-
1.5-11
-
Warranty:
-
1 Year
-
Product name:
-
nail making machine
-
Control system:
-
PLC
Quick Details
-
Wire Diameter (mm):
-
1.6 - 6.5 mm
-
Warranty of core components:
-
2 Years
-
Place of Origin:
-
HEB
-
Brand Name:
-
JIAKE
-
Model Number:
-
Z94-1C/2C/3C/4C/5.5C/6.5C
-
Weight (KG):
-
2500
-
Power (kW):
-
1.5-11
-
Warranty:
-
1 Year
-
Product name:
-
nail making machine
-
Control system:
-
PLC
|
Type |
DPX90 |
DPX130 |
DPX150 |
|
Nail diameter |
2-3.5mm
|
Steel wire 2.5-4.5mm Iron wire 2.5-5.2mm |
Steel wire 2.5-4.5mm Iron wire 2.5-5.5mm |
|
Nail length |
45-90mm |
50-130mm |
70-150mm |
|
Speed |
≤760pcs/min |
500-650pcs/min |
≤500pcs/min |
|
Total power |
5.5kw+1.5kw |
7.5kw+2.2kw |
11kw+2.2kw |
|
Dimension |
1500×1180×1100mm |
1540×1160×1300mm |
1650×1200×1300mm |
|
Weight |
2800kg |
4200kg |
4500kg |
|
Model |
Z94-1C |
Z94-2C |
Z94-3C |
Z94-4C |
Z94-5C |
|
Wire diameter |
0.9-1.6mm |
1.2-2.8mm |
1.8-3.4mm |
2.8-4.5mm |
3.7-5.5mm |
|
Nail length |
9-25mm |
16-50mm |
30-75mm |
50-100mm |
80-150mm |
|
Capacity |
450 pcs/min |
350 pcs/min |
320 pcs/min |
280 pcs/min |
200 pcs/min |
|
Max.20 kgs/h |
Max.60 kgs/h |
Max.100 kgs/h |
Max.200 kgs/h |
Max. 330 kgs/h |
|
|
Motor |
1.5 KW |
2.2 KW |
3 KW |
4 KW |
5.5 KW |
|
Dimension |
1440*1040 *1270mm |
1670*1240 *1380mm |
1830*1300 *1470mm |
2130*1560 *1580mm |
2500*1600 *1700mm |
|
Weight |
1200Kgs |
1400 Kgs |
1100 Kgs |
2000 Kgs |
2500 Kgs |
We are known as one of the most professional and reliable Metal Mesh Making Machine manufacturers and suppliers in China. If you are looking for expanded metal mesh machine,
please feel free to buy the quality automatic machine with competitive price from our factory. Excellent service is available in 24 hours.
