Quick Details
-
Weight:
-
according to models
-
Thermal efficiency:
-
≥98%
-
Steam capacity:
-
0.1-2.0t/h
-
Steam pressure:
-
0.4-1.0Mpa
-
Steam temperature:
-
151-184 degree celsius
-
Color:
-
as required
-
Design fuel:
-
Electricity
-
Keywords:
-
electric boiler
-
Rated evaporation:
-
100-2000kg
-
Installation:
-
Package Boiler
-
Voltage:
-
380V
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Taiguo
-
Dimension(L*W*H):
-
according to models
-
Weight:
-
according to models
-
Thermal efficiency:
-
≥98%
-
Steam capacity:
-
0.1-2.0t/h
-
Steam pressure:
-
0.4-1.0Mpa
-
Steam temperature:
-
151-184 degree celsius
-
Color:
-
as required
-
Design fuel:
-
Electricity
-
Keywords:
-
electric boiler
-
Rated evaporation:
-
100-2000kg
-
Installation:
-
Package Boiler
-
Voltage:
-
380V
Product Description
Technical Paramet
|
Model
|
WDR0.5
|
WDR1
|
WDR1.5
|
WDR2
|
WDR3
|
WDR4
|
WDR6
|
||||||
|
Rated steam
(t/h)
|
0.5 |
1 |
1.5 |
2 |
3 |
4 |
6 |
||||||
|
Electric power
(KW)
|
375 |
750 |
1050 |
1500 |
2250 |
3000 |
4500 |
||||||
|
Rated pressure
(Mpa)
|
0.7/1.0/1.25 |
0.7/1.0/1.25 |
0.7/1.0/1.25 |
0.7/1.0/1.25 |
0.7/1.0/1.25 |
0.7/1.0/1.25 |
0.7/1.0/1.25 |
||||||
|
Rated steam
Temperature（℃）
|
170/184/194 |
170/184/194 |
170/184/194 |
170/184/194 |
170/184/194 |
170/184/194 |
170/184/194 |
||||||
|
Heat Efficiency
(%)
|
99
|
|
|
|
|
|
|
||||||
|
Size(mm)
|
2666*1536*1566
|
3000*1400*1650
|
3500*1600*1750
|
4000*1700*1950
|
4312*2124*2242
|
4380*2400*2662
|
4908*2671*3390
|
||||||
|
Reference weight
(kg)
|
1263 |
2100 |
2600 |
3100 |
5450 |
5203 |
6600 |
||||||
Applications:
Chemical, light industry, textile, building material,cultivation, food and beverage, plastic foam,printing, dyeing and washing, rubber processing,paper products, wood processing,hotel, clothing and leather manufacture etc.
Q1:How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you
need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2：Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
1.Electric control cabinet adopts PLC touch screen, display in English.
2. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc.
3. the cabinet is used for set up the parameter, record and analyze the operation data, etc.
