Quick Details
-
Brand Name:
-
HNJS
-
Dimension(L*W*H):
-
4812*1916*2160mm
-
Weight:
-
4020
-
Product name:
-
16bar Liquid O2 storage vessel used in hospital LO2 tank
-
Application:
-
filling station / fish farm / hospital
-
Material:
-
stainless steel
-
Color:
-
White / customzied
-
Type:
-
Vertical or Horizontal
-
Medium:
-
LNG/O2/N2/Ar2/CO2
-
Standard:
-
GB150-2011
-
Keywords:
-
Liquid oxygen storage tank
-
Design pressure:
-
14.4bar
-
Certification:
-
ISO9001
Quick Details
-
Capacity:
-
5000 Liter
-
Max Working Pressure(MPa):
-
1.44 MPa
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HNJS
-
Dimension(L*W*H):
-
4812*1916*2160mm
-
Weight:
-
4020
-
Product name:
-
16bar Liquid O2 storage vessel used in hospital LO2 tank
-
Application:
-
filling station / fish farm / hospital
-
Material:
-
stainless steel
-
Color:
-
White / customzied
-
Type:
-
Vertical or Horizontal
-
Medium:
-
LNG/O2/N2/Ar2/CO2
-
Standard:
-
GB150-2011
-
Keywords:
-
Liquid oxygen storage tank
-
Design pressure:
-
14.4bar
-
Certification:
-
ISO9001
16bar low temperature Liquid O2 storage vessel used in hospital LO2 tank
Product Show of Liquid oxygen storage tank
With rapid scientfic and technological development, the material-stored technology by use of Liquid oxygen storage tank under normal temperature gets mature day by day. Compared with other storage methods, stainless steel storage tank built in a small area, thus reducing storage tank cost. It is simple in structure and easy in construction, thus reducing construction cost.
Certification of Liquid oxygen storage tank
We can guarantee the safety of our products
. We've got all the
certification to meet the high standard. And we have professional and strict quality control. Each step in the manufacturing process has been strictly monitored to
Liquid oxygen storage tank
in high quality.
|
Parameter of
Liquid oxygen storage tank
We can supply tank from 5m3 to 150m3, both vertical and horizontal tank
|
|
|
|
|
|
|
||||||
|
Model
|
Volume
(cbm)
|
Working Pressure (Mpa)
|
Empty container
(kg)
|
Type
|
The rate of evaporation (%)
|
Outline Size
(Dia * height)
mm
|
||||||
|
JSSM5-L0.8
|
5
|
0.8
|
3825
|
Vertical
|
0.29
|
1916*5260
|
||||||
|
JSSM5-W0.8
|
5
|
0.8
|
3950
|
Horizontal
|
0.29
|
1916*5260
|
||||||
|
JSSM10-L0.8
|
10
|
0.6/0.8
|
6450/6675
|
Vertical
|
0.25
|
2316*6000
|
||||||
|
JSSM10-W0.8
|
10
|
0.6/0.8
|
6450/6675
|
Horizontal
|
0.25
|
2316*6000
|
||||||
|
JSSM15-L0.8
|
15
|
0.6/0.8
|
8145/8415
|
Vertical
|
0.22
|
2516*6760
|
||||||
|
JSSM15-W0.8
|
15
|
0.6/0.8
|
8145/8415
|
Horizontal
|
0.22
|
2516*6760
|
||||||
|
JSSM20-L0.8
|
20
|
0.6/0.8
|
9700/9940
|
Vertical
|
0.22
|
2516*8430
|
||||||
|
JSSM20-W0.8
|
30
|
0.6/0.8
|
15240/15540
|
Horizontal
|
0.21
|
2516*8430
|
||||||
|
JSSM40-L0.8
|
40
|
0.6/0.8
|
17905/18005
|
Vertical
|
0.18
|
3120*9725
|
||||||
|
JSSM50-W0.8
|
50
|
0.6/0.8
|
22310/22715
|
Horizontal
|
0.16
|
3120*11917
|
||||||
|
JSSM100-L0.8
|
100
|
0.6/0.8
|
42179/44020
|
Vertical
|
0.12
|
3524*17110
|
||||||
|
JSSM150-W0.8
|
150
|
0.6/0.8
|
64755/66750
|
Horizontal
|
0.12
|
3824*21950
|
||||||
Henan Jian Shen Metal Metenrial Co.Ltd has now become a high-tech enterprise integrating research, production, sales and services after years of steady development. Our vision - TO be a supplier of choice in the Pressure Vessels as well as OEM manufacturing with the emphasis of being being lowest in cost and highest in customer satisfaction and quality.
Transportation
Sea transportation. Seaworthy packing or according to customers requirements
Under 10ton(10000liters) tank can be put into container during shipping.
