- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Diesel Concrete Mortar Stucco Sprayer
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HS
-
Dimension(L*W*H):
-
1700*650*1000mm
-
Weight:
-
100 kg
-
Power:
-
4kw
-
Type:
-
Diesel Concrete Mortar Stucco Sprayer
-
Usage:
-
Wall Cement Sprayer
-
Hopper Volume:
-
50-130L
-
Keyword:
-
Cement Mortar Spraying Machine
Quick Details
-
Max. vertical conveying distance:
-
20M
-
Max. horizontal conveying distance:
-
20M
-
Hopper Capacity:
-
100L
-
Application:
-
Diesel Concrete Mortar Stucco Sprayer
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HS
-
Dimension(L*W*H):
-
1700*650*1000mm
-
Weight:
-
100 kg
-
Power:
-
4kw
-
Type:
-
Diesel Concrete Mortar Stucco Sprayer
-
Usage:
-
Wall Cement Sprayer
-
Hopper Volume:
-
50-130L
-
Keyword:
-
Cement Mortar Spraying Machine
Product Overview
1. Suitable for spraying materials: thermal insulation mortar, perlite, real stone paint, putty, cement mortar, fireproof materials, coating materials and other spraying, grouting and conveying applications.
2, The construction efficiency is high, the quality adopts foreign technology, and the application life is long.
3. The machine is small and exquisite, easy to carry on site, and the cost of accessories is low.
4. Effectively reduce manual transportation, reduce labor intensity of workers and improve construction quality, and it is convenient to apply.
5. The machine standard batching pipe, air pipe, spray gun, stator, spray head, air compressor.
6. It can be matched with mortar mixer.
|
Model
|
HS-311
|
HS-511
|
HS-711
|
|
Conveying Pipe Diameter
|
32mm
|
38mm
|
38mm
|
|
Air Pump Power
|
2.2kw
|
2.2kw
|
2.2kw
|
|
Motor Power
|
4kw
|
7.5kw
|
7.5kw
|
|
Spraying Area
|
150-170m²/h
|
180-200m²/h
|
220m²/h
|
|
Working Pressure
|
5-8mpa
|
5-8mpa
|
5-8mpa
|
|
Conveying Flow
|
3m³/h
|
3m³/h
|
4m³/h
|
|
Water:Cement:Sand
|
1:1:3
|
1:1:3
|
1:1:3
|
|
The Maximum Passing Particle
|
4mm
|
4mm
|
4mm
|
|
Maximum Vertical Distance
|
10-15m
|
15-20m
|
20-25m
|
|
Maximum Horizontal Distance
|
25-35m
|
30-40m
|
40-50m
|
|
Dimensions
|
1600*450*900mm
|
1700*600*1100mm
|
1800*650*1000mm
|
|
Total Weight
|
150kg
|
300kg
|
360kg
|
