Quick Details
-
Brand Name:
-
Amber
-
Model Number:
-
ABOR-02
-
Product Name::
-
laminar flow surgical theater operation room
-
Cleanliness::
-
class100-100000
-
Feature::
-
Quick Assembly
-
Style::
-
Laminar flow operation room
-
Color::
-
customized
-
Standard::
-
Europe, England, America , China standard
-
Screen::
-
LCD or normal
-
Material::
-
Metal, Steel, electrolytic plate with PVC treatment
-
Quality Certification::
-
CE
-
Application::
-
hospital Clean Room
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
China
-
Brand Name:
-
Amber
-
Model Number:
-
ABOR-02
-
Product Name::
-
laminar flow surgical theater operation room
-
Cleanliness::
-
class100-100000
-
Feature::
-
Quick Assembly
-
Style::
-
Laminar flow operation room
-
Color::
-
customized
-
Standard::
-
Europe, England, America , China standard
-
Screen::
-
LCD or normal
-
Material::
-
Metal, Steel, electrolytic plate with PVC treatment
-
Quality Certification::
-
CE
-
Application::
-
hospital Clean Room
Product Description
MOT ISO5-8 Airkey Turnkey Project Clean Engineering for Hospital Operation Room and ICU
The laminar flow operating room adopts air cleaning technology to control microbial pollution sources to different degrees to achieve the requirements of air cleanliness in the controlled space environment suitable for various operations; and provide suitable temperature and humidity to create a fresh, clean, A comfortable operating environment with a low bacterial count allows patients to suffer as little damage as possible during surgery, and greatly reduces the rate of secondary infections of patients and medical staff, especially intracranial surgery and burn surgery, to ensure the patient's postoperative performance Faster and better recovery, etc.
Operation room classification
(
1) Class I operating room: the sterile clean operating room, which mainly accepts operations such as brain, heart, and organ transplants.
(2) Class II operating room: the sterile operating room, which mainly accepts aseptic operations such as splenectomy,
open reduction of closed fractures, intraocular surgery, and thyroidectomy.
open reduction of closed fractures, intraocular surgery, and thyroidectomy.
(3) Class III operating room: that is, the operating room with bacteria, which accepts operations on stomach, gallbladder, liver, appendix, kidney, lung and other parts.
(4) Category IV operating room: the infection operating room, which mainly accepts surgery for appendix perforation, peritonitis, tuberculous abscess, abscess incision and drainage.
(5) Category V operating room: the special infection operating room, which mainly accepts the operation of Pseudomonas aeruginosa, gangrene bacillus, tetanus and other infections. According to different specialties, the operating rooms can be divided into general surgery, orthopedics, obstetrics and gynecology, brain surgery, cardiothoracic surgery, urology, burns, and ENT surgery.
Specification
Cleanliness
The cleanliness grade of hospital clean room is generally divided into class100, class1000, class10000, class100000 etc.
|
Cleanliness grade
|
Maximum particles/m3
|
|
|
|
|
|
FED STD 209E
|
Application of surgery
|
|||||
|
|
≥0.1 μm
|
≥0.2 μm
|
≥0.3 μm
|
≥0.5 μm
|
≥1 μm
|
≥5 μm
|
~
|
~
|
|||||
|
ISO 5
|
100,000
|
23,700
|
10,200
|
3,520
|
832
|
def
|
class 100
|
Joint replacement, neurosurgery, heart surgery
|
|||||
|
ISO 6
|
1,000,000
|
237,000
|
102,000
|
35,200
|
8,320
|
293
|
class 1,000
|
|
|||||
|
ISO 7
|
c
|
c
|
c
|
352,000
|
83,200
|
2,930
|
class 10,000
|
Thoracic surgery, ENT, urological surgery and general surgery
|
|||||
Details Images
Operation room panels
* 1.2mm electrolytic plate with PVC on treatment* anti-scratched, dust-proof
* anti-bacterial, fast assembly
* long worklife, easy to install
* anti-bacterial, fast assembly
* long worklife, easy to install
We adopt new type of laminated board, which we get patent in China, compared with old spraying board material,the laminated board
with advantage of:
with advantage of:
|
|
|
New Environmental Laminated board
|
Traditional Spraying board
|
|
|
Feature
|
1. can't be scratched by cart or sharp items
2. dust-proof and Antibacterial3. quick assemble and can be move to different place to reassemble 4. easy to disassembly 5. easy to clean 6. no fingerprint |
|
1.easy to scratch
2.easy to discolor(yellowing after 1.5 years) 3.disposable 4. difficult to clean and maintain |
|
|
Production time
|
7 days
|
|
10 days
|
|
|
Installation time
|
3-5 days
|
|
15-20 days
|
|
|
Work life
|
10 years
|
|
2 years
|
|
|
Others
|
we got patent in 2018
|
|
normal material
|
|
Operation room equipment
Surgical light, ceiling pendent, operating room table
Clean room accessories
* Anesthesia cabinet, instrument cabinet, medicine cabinet
* Gas terminal, electrical terminal, control panel
* hermetic operation room sliding door
* Gas terminal, electrical terminal, control panel
* hermetic operation room sliding door
PVC floor
South Korea famous brand LG PVC
HVAC system
Operation room HVAC designs involve knowledge of regulations, a general term for indoor environmental comfort, which creates cleaness level guidelines, airflow, room pressurization, indoor air quality (air change per hour, CFM, temperature control, humidity control etc), and add Ozone disinfection, and ultraviolet sterilization to make sure the air is sterile.
