Quick Details
-
Brand Name:
-
E/V/E CATL
-
Model Number:
-
CL320
-
Battery Size:
-
72173205
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.6kg, 72(thickness) x173(width) x203(length)mm
-
The charging ratio:
-
0.5C(160A)
-
The discharge rate:
-
1C(320A)
-
Electric Energy:
-
1024 Wh
-
Battery type:
-
Rechargeable Lifepo4 Battery Cell
-
charging voltage/Discharge voltage:
-
3.65V/2.5V
-
Nominal Voltage:
-
3.2V
-
Nominal Capacity:
-
320AH/1024wh
-
Internal Resistance:
-
≤0.2mΩ
-
Terminal:
-
Laser Welding M6 Studs or customized
-
Cycle life:
-
8000+ times
-
Apllication:
-
Solar Home Energy Storage Systems
-
Certification:
-
CE/UN38.3/MSDS
Quick Details
-
Storage Type:
-
Lifepo4
-
Anode Material:
-
LFP
-
Application:
-
Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
E/V/E CATL
-
Model Number:
-
CL320
-
Battery Size:
-
72173205
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.6kg, 72(thickness) x173(width) x203(length)mm
-
The charging ratio:
-
0.5C(160A)
-
The discharge rate:
-
1C(320A)
-
Electric Energy:
-
1024 Wh
-
Battery type:
-
Rechargeable Lifepo4 Battery Cell
-
charging voltage/Discharge voltage:
-
3.65V/2.5V
-
Nominal Voltage:
-
3.2V
-
Nominal Capacity:
-
320AH/1024wh
-
Internal Resistance:
-
≤0.2mΩ
-
Terminal:
-
Laser Welding M6 Studs or customized
-
Cycle life:
-
8000+ times
-
Apllication:
-
Solar Home Energy Storage Systems
-
Certification:
-
CE/UN38.3/MSDS
Specification
|
item
|
Rechargeable Lifepo4 battery cell
|
|
Warranty
|
5 years
|
|
Chargeable
|
Yes
|
|
Battery Type
|
3.2V 320Ah Lifepo4 battery
|
|
Brand Name
|
E/V/E CATL
|
|
Certification
|
CE,MSDS,UN38.3
|
|
Charge working temp.
|
0ºC~50ºC
|
|
Discharge working temp.
|
-20ºC~55ºC
|
|
The Continuous charge current
|
0.5C
|
|
Continuous discharge current
|
1C(320A)
|
|
Weight
|
5.6KG
|
|
Size
|
72 (thick) x 173 (width) x205(length)mm
|
|
Maximum charging voltage
|
3.65V
|
|
Discharge voltage
|
2.5V
|
|
Internal Resistance
|
≤0.2mΩ
|
|
Terminal
|
M6 Studs
|
|
Cycle life
|
8000 times
|
|
Apllication
|
Solar Energy Storage Systems/UPS/RV/Golf cart
|
