Quick Details
-
Warranty:
-
25 years, 25 Years
-
Brand Name:
-
Amso solar
-
Model Number:
-
AS650S9-120
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2196*1303*40mm
-
weight:
-
31kg
-
frame:
-
Anodized Aluminium Alloy
-
junction box:
-
IP67 Rated Waterproof
-
Connector:
-
mc 4 Compatible Connector
-
Front Cover:
-
3.2mm Tempered Glass
-
Max. Power:
-
710 watt
-
Keyword:
-
120 cell solar panel
-
Keywords:
-
mono solar panel
-
Certificate:
-
CE, TUV, IEC, IOS
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
605w
-
Warranty:
-
25 years, 25 Years
-
Brand Name:
-
Amso solar
-
Model Number:
-
AS650S9-120
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2196*1303*40mm
-
weight:
-
31kg
-
frame:
-
Anodized Aluminium Alloy
-
junction box:
-
IP67 Rated Waterproof
-
Connector:
-
mc 4 Compatible Connector
-
Front Cover:
-
3.2mm Tempered Glass
-
Max. Power:
-
710 watt
-
Keyword:
-
120 cell solar panel
-
Keywords:
-
mono solar panel
-
Certificate:
-
CE, TUV, IEC, IOS
AMSO SOLAR is professional manufacture with 12 years experience for solar panels, half cell solar panels and solar system etc., which is popular in Europe, Asia, Africa, etc.. AMSO SOLAR get TUV, CE and ISO9001, ensure quality of products. AMSO is your good partner!
| Model Type | Power(W) | Number of Cells | Dimensions(MM) | Weight(KG) | Vmp(V) | Imp(A) | Voc(V) | Isc(A) |
| AS580S9-120 | 580 | 120 | 2196*1303*40 | 31 | 33.76 | 17.18 | 40.70 | 18.21 |
| AS585S9-120 | 585 | 1 20 | 2196*1303*40 | 31 | 33.95 | 17.23 | 40.90 | 18.26 |
| AS590S9-120 | 590 | 1 20 | 2196*1303*40 | 31 | 34.14 | 17.28 | 41.10 | 18.31 |
| AS595S9-120 | 595 | 1 20 | 2196*1303*40 | 31 | 34.35 | 17.32 | 41.30 | 18.36 |
| AS600S9-120 | 600 | 1 20 | 2196*1303*40 | 31 | 34.54 | 17.37 | 41.50 | 18.41 |
| AS605S9-120 | 605 | 1 20 | 2196*1303*40 | 31 | 34.75 | 17.41 | 41.70 | 18.46 |
| Standard test conditions:measured values(atmosphiric mass AM.5,irradiance 1000W/m2,battery temperature 25℃) | ||||||||
| Temperature rating | ||||||||
| Rated battery operating temperature | 45±2℃ | |||||||
| Maximum power temperature coefficient | -0.4%/℃ | |||||||
| Open circuit voltage temperature coefficient | -0.29%/℃ | |||||||
| Short circuit current temperature coefficient | -0.05%/℃ | |||||||
| Limit parameter | ||||||||
| Operating temperature | -40-+85℃ | |||||||
| Maximum system voltage | 1000/1500VDC | |||||||
| Maximum fuse rated current | 25A | |||||||
| Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment | ||
| FOB | |||||
| CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||||
| CIF | |||||
| L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
| West Union | Amount lower than 5000usd | ||||
| Delivery Time | 7-10 working days after receiving payment (should be decided according to quantity) | ||||
