Clear acrylic sheet is colorless and transparent, its transparency is the topmost one in all plastic, its transmittance is more
than >92% for 100% virgin raw material
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
Mokelon-pmma-t
-
Thickness:
-
1-30mm
-
Size:
-
1220X2440mm(4*8'')
-
Product name:
-
acrylic sheet
-
Feature:
-
high transparency
-
Density:
-
1.2g/cm³
-
Raw material:
-
PMMA
-
Length:
-
2440mm
-
Sample:
-
Free samples
-
Colour:
-
transparent or customize
-
MOQ:
-
1000kg
-
Light Transmittance:
-
95%-98%
-
Width:
-
1220mm
Quick Details
-
Processing Service:
-
Cutting, Moulding
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Mokelon
-
Model Number:
-
Mokelon-pmma-t
-
Thickness:
-
1-30mm
-
Size:
-
1220X2440mm(4*8'')
-
Product name:
-
acrylic sheet
-
Feature:
-
high transparency
-
Density:
-
1.2g/cm³
-
Raw material:
-
PMMA
-
Length:
-
2440mm
-
Sample:
-
Free samples
-
Colour:
-
transparent or customize
-
MOQ:
-
1000kg
-
Light Transmittance:
-
95%-98%
-
Width:
-
1220mm
Product Paramenters
Product I
nformation
|
Product Name
|
Pouring acrylic sheet
|
|
|
|
|||
|
Material
|
Pure original PMM particles, absolutely no recycled raw materials
|
|
|
|
|||
|
Color
|
clear, transparent, frosted,mirror ,red,blue,white,black ,Custom produced any color you want
more than 100 kinds of colors. No fading colour in outdoor at least 8-10 years. |
|
|
|
|||
|
Thickness
|
2mm to 50mm or customized
|
|
|
|
|||
|
Density
|
1.19 g/cm3
|
|
|
|
|||
|
Production Process
|
Cast acrylic sheet production process
|
|
|
|
|||
|
Package
|
Both sides covered by pe film + pallet; both sides covered by kraft paper + pallet
Use a transparent film for PE film, or a protective film that contains your company information.
|
|
|
|
|||
|
MOQ
|
50 pcs
|
|
|
|
|||
|
payment
|
L/C, T/T, Western Union, MoneyGram, Paypal
|
|
|
|
|||
|
Delivery
|
3-5days after confirm your order
|
|
|
|
|||
|
Special Process
|
Hardening treatment, anti-static, anti-ultraviolet, anti-corrosion, anti-infrared, anti-radiation, anti-fog,
ps: If you need the above functions, please contact customer service, the conventional sheet does not include the above processes.
|
|
|
|
|||
|
Characteristics
|
1) 92.7% optical transparency
|
|
2) Low water absorption
|
|
|||
|
|
3) High impact resistance
|
|
4) Easy to handle
|
|
|||
|
|
5) Lighter weight than glass
|
|
6) Perfect transparency for display
|
|
|||
|
|
7) UV-resistant
|
|
8) Wide thickness range（2mm-50mm）
|
|
|||
|
|
9) Good thermal stability
|
|
10) Wide range of colors
|
|
|||
|
Applications
|
Construction---Windows, light shade, telephone booth, etc.
|
|
|
|
|||
|
|
Advertising---Light boxes, signs, exhibition, etc.
|
|
|
|
|||
|
|
Traffic---Trains, cars and other vehicles doors and windows, etc.
|
|
|
|
|||
|
|
Medical---Infant incubator, all kinds of surgery medical equipment, etc.
|
|
|
|
|||
|
|
Supplies---Bath facilities, handicrafts, cosmetics, etc.
|
|
|
|
|||
|
|
Industrial---Instrument surface plate and the cover, etc.
|
|
|
|
|||
|
|
Lighting----Fluorescent lamp, LED, street lamps, etc.
|
|
|
|
|||
|
Physical properties of acrylic sheet
|
|
|
||
|
PROPERTIES
|
VALUES
|
RULES
|
||
|
Density
|
1.19 g/cm3
|
ISO 1183-1:2012 Method A
|
||
|
Rockwell Hardness
|
112L
|
ISO 2039-2:1999
|
||
|
Tensile Modulus
|
3150MPa
|
EN ISO 527:2012
|
||
|
Tensile Strength
|
80.0MPa
|
EN ISO 527:2012
|
||
|
Tensile Strain at Break
|
3.2%
|
EN ISO 527-1:2012
|
||
|
Water Absorption
|
0.20%
|
ISO 62:2008 Method 1
|
||
|
Total Luminous Transmittance
|
93.4%
|
ISO 13468-1:1996
|
||
|
Vicat Softening Temperature
|
105℃
|
ISO 306:2013 Method B50
|
||
|
Light Ageing Test- UV Exposure
|
Grey scale: 5
|
ISO 4892-3:2016 Cycle 1
|
||
|
Mean Coefficient of Linear Thermal Expansion
|
72×10-6 K-1
|
ISO 11359-1:2014
|
||
|
Compressive Stress at Yield
|
129MPa
|
EN ISO 604:2003
|
||
|
Flexural Strength
|
120MPa
|
ISO 178:2013
|
||
|
Compressive Yield Strength
|
111MPa
|
ASTM D695-15
|
||
|
Compressive Modulus
|
3450MPa
|
ASTM D695-15
|
||
|
Shear Strength
|
59.7MPa
|
ASTM D732-17
|
||
|
Deflection Temperature under Load
|
100.2℃
|
ASTM D648-18 Method B
|
||
|
Modulus Elasticity
|
2810MPa
|
ASTM D695-15
|
||
In order to offer a good price, we need your kindly help to confirm us about the following details as the reference
1. color (transparent, semitransparent, white, black, red, blue, green and as per customer's requirement)
2. thickness (2mm~30mm)
3. size (1220x2440mm standard)
4. Quantity to check the delivery time
1. color (transparent, semitransparent, white, black, red, blue, green and as per customer's requirement)
2. thickness (2mm~30mm)
3. size (1220x2440mm standard)
4. Quantity to check the delivery time
Details Images
A variety of colors are available, and customization is also acceptable.
The following is a partial color display, please contact customer service for more color options.
Product Advantages
Good adaptability to natural environment, long time under sunlight, wind and rain, its property will not change, Good aging
resistance, it can be used safely outdoors.
resistance, it can be used safely outdoors.
Good dimension stability, the product will be beautiful and smooth after formation processing or fitting processing.
It won`t do harm to users, even for long time use, Gases emitted during burning are not poisonous.
Application
Mold accessories
transparent shell
Luminous words
display rack
lighting
advertising sign
Product packaging
stock warehouse
The containment film is made of kraft paper or transparent PE film. A protective film for company information can also be customized.
Loading and delivery
Wooden frame + paper skin + PE film winding to protect the board from scratches and losses to the greatest extent.
Loading and delivery
Rich stacking and customized production experience, reasonable loading of more goods, saving freight costs.
Certifications
Certificates and Test Reports
We have complete production process management and quality management software patents, ISO9001 certificate, Rhine factory audit report, ROSH report, etc.
Product testing reports include but are not limited to: anti-ultraviolet report, anti-static report, UL94V0 fire report, environmental protection report, etc.
For more information, please contact customer service.
