Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
LSKABEL
-
Model Number:
-
LST 80013601D
-
Application:
-
Industorial, Rugged environment
-
Sheath:
-
EPDM
-
Standard:
-
High Flexible
-
Certification:
-
VDE/CCC/CE
-
Workmanship:
-
Half-extrusion
-
Color:
-
Requirement
-
Voltage:
-
Low Voltage
-
property:
-
Abrasion- resistance
-
Conductor:
-
Bare copper
-
Insulation:
-
NBR/ PVC
Quick Details
-
Conductor Material:
-
Copper
-
Insulation Material:
-
NBR/PVC
-
Number of Conductors:
-
custom
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
LSKABEL
-
Model Number:
-
LST 80013601D
-
Application:
-
Industorial, Rugged environment
-
Sheath:
-
EPDM
-
Standard:
-
High Flexible
-
Certification:
-
VDE/CCC/CE
-
Workmanship:
-
Half-extrusion
-
Color:
-
Requirement
-
Voltage:
-
Low Voltage
-
property:
-
Abrasion- resistance
-
Conductor:
-
Bare copper
-
Insulation:
-
NBR/ PVC
|
Material&Structure
|
|
|
Conductor:
|
Bare copper, VDE 0295/IEC60228 class 6
|
|
Insulation:
|
Rubber/TPE(optional)
|
|
Reinforce:
|
Kevlar braid(optional)
|
|
Sheath:
|
Rubber/PUR(optional)
|
|
Special Structure:
|
single shield/twin-shield/tinned copper braid,twisted
|
|
Technical data
|
|
|
Mini. bend radius:
|
6-10 x Diameter
|
|
Travel speed
|
2-5m/s
|
|
Voltage:
|
600/1000V
|
|
Test Voltage:
|
3.5KV/5min (AC)
|
|
Temperature range:
|
-30℃-90℃
|
|
Features
|
|
|
Core:
|
black with numerals plus green-yellow ground wire
|
|
Sheath Color:
|
black or gray or on request
|
|
Core Identification
|
Colored as request or continuous numbering
|
|
Applications
|
Reel/festoon/towline/Drag Chains/Track Cable/drag chain servo cable/BASKET SPREADER/chain cable/data communication cable/
crane/conveyor/EMC/Motor/equipment/Electric |
|
Others:
|
Flexible,Abrasion resistance,Tension resistance,Oil resistance,UV-resistance, Flame retardant, fire resistance, Acid
/Alkali/Alkalis/chemical resistance,Low Temperatures |
|
|
Seawater/Underwater/Safety High Bending
|
|
Properties
|
|
|
|
|||
|
Flexible
|
Yes
|
|
|
|||
|
Abrasion resistance
|
Yes
|
|
|
|||
|
Torsion resistance
|
Yes
|
|
|
|||
|
Oil resistance
|
Yes
|
|
|
|||
|
Notch resistance
|
Yes
|
|
|
|||
|
Tear resistance
|
Yes
|
|
|
|||
|
Resistant to Acids and Alkalis
|
Yes
|
|
|
|||
|
Chemical resistance
|
Yes
|
|
|
|||
|
UV-resistance
|
Yes
|
|
|
|||
|
Flame retardant
|
Optional
|
|
|
|||
Application
Flexible low voltage reeling cable for power supply, suitable for application under high and very high mechanical stresses. The main application is reeling operation on Electrified Rubber Tyred Gantry cranes.
Flexible low voltage reeling cable for power supply, suitable for application under high and very high mechanical stresses. The main application is reeling operation on Electrified Rubber Tyred Gantry cranes.
