Quick Details
-
Brand Name:
-
Wolck
-
Use:
-
CATV, FTTH
-
Warranty Time:
-
18 months
-
Network:
-
CATV
-
No. of Fiber:
-
1.
-
Input Optical Power:
-
0- -18dBm
-
Optical Fiber Type:
-
Single Mode
-
Optical Connector:
-
SC/APC(customized)
-
Flatness:
-
±0.5
-
Application:
-
Digital TV fiber to the home ,Triple play ,FTTH PON
-
Working bandwidth:
-
45~1000MHZ
-
Warranty:
-
1 year
Quick Details
-
Type:
-
FTTx Solutions
-
Model Number:
-
FT-1000MM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Wolck
-
Use:
-
CATV, FTTH
-
Warranty Time:
-
18 months
-
Network:
-
CATV
-
No. of Fiber:
-
1.
-
Input Optical Power:
-
0- -18dBm
-
Optical Fiber Type:
-
Single Mode
-
Optical Connector:
-
SC/APC(customized)
-
Flatness:
-
±0.5
-
Application:
-
Digital TV fiber to the home ,Triple play ,FTTH PON
-
Working bandwidth:
-
45~1000MHZ
-
Warranty:
-
1 year
Top selling FTTH CATV optical receiver without WDM 1550nm
1.Model Number: FT-1000MM
2. Designed For FTTH (Fiber To The Home Network)
3. No Power Required
4.Lensed protection and high responsivity PD for more performance
5. Exelent Linearity and Flatness
6. Frequency range 40-1000MHz For CATV End-users
7. Optical Connector: SC/APC
8. PVC Casing(Actractive customized case colours)
9.Small and Cute Design for Easy Handling 10. With RF Shielding Protection
|
|
UNIT
|
PARAMETER
|
||
|
Optical Parameters
|
|
|
||
|
Optical input power
|
dBm
|
-15～0
|
||
|
Loss
|
dB
|
＞45
|
||
|
Wavelength
|
nm
|
1310nm or 1550nm
|
||
|
Connector
|
|
SC/APC ONLLY
|
||
|
Link Path Performance
|
|
|
||
|
C/N
|
dB
|
≥51
|
||
|
C/CTB
|
dB
|
≥65
|
||
|
C/CSO
|
dB
|
≥62
|
||
|
RF parameter
|
|
|
||
|
Frequency Range
|
MHz
|
47～1000
|
||
|
In-band Flatness
|
dB
|
1.5
|
||
|
Output level
|
dBμV
|
46（-15dBm test)56（-10dBm test)66（-5dBm test)70（-3dBm test)76（0dBm test）
|
||
|
RF output reflection
|
dB
|
≥16
|
||
|
RF out resistance
|
Ω
|
75
|
||
|
Packaging
|
250pcs in one small box，1000pcs in one carton，GW: 13kgs
|
|
||
