Quick Details
-
Brand Name:
-
OPTEN
-
Model Number:
-
DSK-00D(KF20)
-
Power (W):
-
5000
-
Voltage (V):
-
220
-
Color:
-
White
-
Usage:
-
Shower Room
-
Material:
-
ABS
-
Working Pressure:
-
0.02-0.6 Mpa
-
Rated Voltage:
-
220-240VAC
-
Waterproof:
-
IPX4
Quick Details
-
Warranty:
-
1 Year
-
Application:
-
Hotel, Garage, Commercial, Household
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OPTEN
-
Model Number:
-
DSK-00D(KF20)
-
Power (W):
-
5000
-
Voltage (V):
-
220
-
Color:
-
White
-
Usage:
-
Shower Room
-
Material:
-
ABS
-
Working Pressure:
-
0.02-0.6 Mpa
-
Rated Voltage:
-
220-240VAC
-
Waterproof:
-
IPX4
Product Parameters
Functions
(1) Unique patent water and electricity Separation technology.
(2) Heat eficiency reach 98%.
(3) Three heating power settings.
(4) Digit display screen.
(5) No wait, no waste, and space save.
(6) Far less likely to leak or rupture.
(7) Error code display prompts
(8) CCC, CE approved.
(9) Less prone to hard water or mineral problems.
(10) Multi safety protection: build-in ELB checker, thermal cutout, external safe care, Water flow Control Valve.
Specification
1.power:3/4/5kw
2.voltage:220-240V
3.Max required circuit breaker:32A
4.Recommend wire:3x2.5mm²
5.work pressure:0.03Mpa
6.Maximum Set Temp:52degrees
Packing
1.Product size:280×200×62mm
2
.inside size:325*120*285mm
3.Carton size:640×300×360mm
4.N.W./PCS:3kg G/W:3.5KG
5.Carton Qty:5pcs/CTN
MARK
1.Display:LED digital display
2.Optional Color:white.siliver
Conveyance:
20FCL:1740pcs/348carton
40 FCL:3715pcs/743carton
|
Model
|
DSK-00D(KF20)
|
|
|
||
|
Power Rating
|
3KW
|
4KW
|
5KW
|
||
|
Rated Voltage
|
220VAC to 240VAC
|
|
|
||
|
Rated Current(for 220VAC)
|
32A
|
|
|
||
|
Recommend wire
|
3x2.5mm2
|
|
|
||
|
Rated pressure
|
0.02 to 0.6 MPa
|
|
|
||
|
Water connections
|
G1/2”
|
|
|
||
|
Protection class
|
IPX4
|
|
|
||
|
N.W
|
3kg
|
|
|
||
|
G.W
|
3.5kg
|
|
|
||
|
MAX TEMP
|
52degrees
|
|
|
||
|
Installation
|
Wall Mounted
|
|
|
||
|
Dimensions HxWxD(mm)
|
280×200×62mm
|
|
|
||
|
Box size(mm)
|
325*120*285mm
|
|
|
||
|
Mater carton size(mm)
|
640×300×360mm
|
|
|
||
|
Master carton quantity
|
5
|
|
|
||
|
Operate Way
|
Digital Screen/3gear control
|
|
|
||
|
Element type
|
Pantent Alunimum Plated heating Element
|
|
|
||
