Quick Details
-
Hardness:
-
Full Hard
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JUHE
-
Grade:
-
DX51D, DX52D, SGCC, etc, SGCC/CS-B/DX51D or equivalent
-
RAL Color:
-
All RAL Color
-
Zinc Coating:
-
Z40-Z275
-
Types:
-
Commercial/Drawing/Deep Drawing/Structural Quality
-
Surface Treatment:
-
Chromated/Skin-pass/Oiled/Slightly Oiled/Dry
-
Surface Finished:
-
Minimized Spangle/Regular Spangle/Big Spangle
-
Coil ID:
-
508mm/610mm
-
Coil Weight:
-
5-17 Ton per coil
-
Package:
-
Sea Worthy And Export Package
Quick Details
-
Type:
-
Steel Coil
-
Thickness:
-
0.13-3.0mm, 0.13-3.0mm(0.14-0.5mm is the most advantage thickness
-
Coating:
-
Z81-Z120
-
Hardness:
-
Full Hard
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JUHE
-
Grade:
-
DX51D, DX52D, SGCC, etc, SGCC/CS-B/DX51D or equivalent
-
RAL Color:
-
All RAL Color
-
Zinc Coating:
-
Z40-Z275
-
Types:
-
Commercial/Drawing/Deep Drawing/Structural Quality
-
Surface Treatment:
-
Chromated/Skin-pass/Oiled/Slightly Oiled/Dry
-
Surface Finished:
-
Minimized Spangle/Regular Spangle/Big Spangle
-
Coil ID:
-
508mm/610mm
-
Coil Weight:
-
5-17 Ton per coil
-
Package:
-
Sea Worthy And Export Package
Product Description
|
The production process
|
EN10147/EN10142/DIN 17162/JIS G3302/ASTM A653
|
|
|
|
|||
|
Steel Grade
|
DC51D+Z,DC52D+Z,DC53D+Z,S280GD+Z,S350GD+Z,S550GD+Z,DC51D+AZ,
DC52D+AZ,S250GD+AZ,S300GD+AZ,S350GD+AZ,S550GD+AZ
SECCSECE.BLCE+Z,BLDE+Z BUSDE+Z or Customer's Requirement
|
|
|
|
|||
|
Base Steel
|
Hot dip galvanized steel, Hot dip galvalume steel, Electro galvanized steel
|
|
|
|
|||
|
Thickness
|
0.12-6.0mm
|
|
|
|
|||
|
Width
|
600-1500mm
|
|
|
|
|||
|
Surface Color
|
RAL,wood grain pattern, camouflage pattern , stone pattern, matte pattern , high glosspattern . flower pattern, etc
|
|
|
|
|||
|
Quality
|
Approved by SGSISO
|
|
|
|
|||
|
Coil Weight
|
3-20metric ton per coil
|
|
|
|
|||
|
Package
|
Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing, side guard plate,then wrapped by seven steel belt.or according to customer's requirement
|
|
|
|
|||
|
Export market
|
Europe,Africa,Central Asia,Southeast Asia,Middle East,South America,North America, etc
|
|
|
|
|||
production process
Galvanized steel is to prevent the steel plate surface from corrosion to extend its service life, in the steel plate surface coated with a layer of metal zinc, the zinc coated steel plate are called galvanized sheet. According to the production and
processing methods can be divided into the.
processing methods can be divided into the.
1) hot dip galvanized steel. Thin plate in melting zinc bath, make its surface adhesion of a layer of zinc sheet. At present mainly adopts continuous galvanizing process, namely the continuous roll of steel plate in the melt zinc plating tank made of galvanized steel sheet;
(2) the alloying of galvanized steel.
This kind of steel plate is made by hot dip method, but after the slot, immediately heated to a temperature of about 500 ℃, it make the generation of zinc and iron alloy membrane. This kind of galvanized sheet with good coating of sex and weldability
Galvanized Steel 0.18mm-20mm thick galvanized steel sheet 2mm thick Hot dip galvanized steel sizes galvanized sheet metal roll.
Chemical Composition
|
bse metal type
|
Grade
|
CHEMICAL COMPOSITION %
|
|
|
|
|
||||
|
|
|
C
|
Si
|
Mn
|
P
|
S
|
||||
|
cold rolled steel sheet
|
DC51D+Z (St01Z, St02Z, St03Z) , DC51D+ZF
|
≤0.10
|
-
|
≤0.50
|
≤0.035
|
0.03
|
||||
|
|
DC52D+Z (St04Z), DC52D+ZF
|
≤0.08
|
-
|
≤0.45
|
≤0.030
|
0.03
|
||||
|
|
DC53D+Z (St05Z), DC53D+ZF
|
≤0.08
|
-
|
≤0.40
|
≤0.030
|
0.03
|
||||
|
|
DC54D+Z (St06Z), DC54D+ZF
|
≤0.01
|
≤0.10
|
≤0.30
|
≤0.025
|
0.03
|
||||
|
|
DC56D+Z (St07Z), DC56D+ZF
|
≤0.01
|
≤0.10
|
≤0.30
|
≤0.025
|
0.03
|
||||
|
hot rolled steel sheet
|
DD51D+Z (St01ZR, St02ZR)
|
≤0.10
|
-
|
≤0.50
|
≤0.035
|
0.03
|
||||
|
|
DD54D+Z (St06ZR)
|
≤0.01
|
≤0.10
|
≤0.30
|
≤0.025
|
0.03
|
||||
Substrate Type
1.Hot-dip galvanized color coated steel sheet(prepainted galvanized steel sheet)The product obtained by coating an organic coating on a hot-dip galvanized steel sheet is a hot-dip galvanized color-coated plate. In addition to the protective effect of zinc, the hot-dip galvanized color-coated sheet also protects against rust and has a longer service life than hot-dip galvanized sheet;
2.Hot-dip aluminum-zinc color coated sheet(prepainted galvalume steel sheet)Hot-dip aluminum-zinc steel sheets can also be used as color-coated substrates (55% AI-Zn and 5% AI-Zn);
3.Electroplated zinc color coated sheet The electro-galvanized sheet is used as the substrate, and the product obtained by baking with the organic coating is an electrogalvanized color-coated plate. It has a beautiful appearance and excellent processing properties, and therefore can be mainly used for home appliances, audio, steel furniture, interior decoration, and the like.
Types of colour-coating: standard polyester, matt polyester, decoprint.
Coating Type
Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost.
Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability andchalking resistance, gloss retention, general flexibility, and medium cost.
High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and highcost.
Quality Inspection
Packing & Shipping
Application areas
(1)In the construction industry: to manufacture exterior and Interior products such as metal shingles, corrugated sheeting, sandwich panels, profiles, metallic ceilings, skirting boards, decorative panels inside heated and non- heated rooms, elevators, doors window shutters, shelves etc.
(2)In the automotive industry: to manufacture external and internal car body parts (car doors, car boots, oil filters, dashboards, windscreen wipers etc.
(3)In manufacture of home appliances, furniture, and consumer goods: metallic furniture, lighting equipment, shelves, radiators, сar doors, car boots etc.
