Quick Details
-
Dimension(L*W*H):
-
9950*2600*3480mm
-
Weight:
-
52 KG
-
Marketing Type:
-
New Product 2021
-
Mobility:
-
Mobile
-
Engine type:
-
QSB 6.7
-
Engine Power/ revolution:
-
164kW/2200rpm
-
Deployment speed (margin):
-
4000mm
-
Track shoe width:
-
800mm
-
The maximum out torque:
-
160kN m
-
The maximum lifting speed:
-
59m/min
-
Keyword:
-
Rotary Drilling Rig
-
Color:
-
Optional
-
Model:
-
YCR160D
-
Total Working Weight:
-
52Ton
Quick Details
-
Place of Origin:
-
Guangxi, China
-
Brand Name:
-
YUCHAI
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
9950*2600*3480mm
-
Weight:
-
52 KG
-
Marketing Type:
-
New Product 2021
-
Mobility:
-
Mobile
-
Engine type:
-
QSB 6.7
-
Engine Power/ revolution:
-
164kW/2200rpm
-
Deployment speed (margin):
-
4000mm
-
Track shoe width:
-
800mm
-
The maximum out torque:
-
160kN m
-
The maximum lifting speed:
-
59m/min
-
Keyword:
-
Rotary Drilling Rig
-
Color:
-
Optional
-
Model:
-
YCR160D
-
Total Working Weight:
-
52Ton
Yuchai Drilling Rotary Rigs 164KW Drilling Machinery YCR160D 40-50m Rotary Pile Drilling Rigs
| item | Parameters | |||
| Chasis | Engine type | QSB 6.7 | ||
| Engine Power/ revolution | 164kW/2200rpm | |||
| Deployment speed (margin) | 4000mm | |||
| Track shoe width | 800mm | |||
| Traction | 300KN | |||
| Power head | The maximum out torque | 160kN·m | ||
| Power head revolution | 6~30rpm | |||
| The maximum pressure increased | 160kN | |||
| The maximum pullout force | 160kN | |||
| Pressurizing oil cylinder stroke | 4000mm | |||
| Winch | Main winch | |||
| Lifting force of the first layer | 70kN | |||
| The maximum lifting speed | 59m/min | |||
| Steel wire diameter | ∅18mm | |||
| Auxiliary winch | ||||
| Lifting force of the first layer | 160kN | |||
| The maximum lifting speed | 42m/min | |||
| Steel wire diameter | ∅14mm | |||
| Mast | Front inclination angle of mast | 5° | ||
| Left and right inclinations of mast | ±5° | |||
| Hydraulic pump | The maximum working pressure of system | 34MPa | ||
|
Hole depth
and diameter |
The maximum drilling diameter | 1.2m | ||
| The maximum drilling depth | 50m/40m | |||
| Weight at working state | 52 t | |||
| 43 t | ||||
| 50 t | ||||
| Drill pipe | (The standard configuration) |
∅377-5x11 m
|
||
| (optional configuration ) | ∅ 377-5x11 m | |||
