Prevent accidental injury, full width aluminum alloy structure, beautiful and comfortable;
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Fenghui
-
Model Number:
-
002
-
Lock:
-
Security
-
Drawers:
-
Customizable
-
Body Material:
-
Metal Frame
-
Weight:
-
Customizable
-
Tool cabinet:
-
Storage Garage Tool Cabinet
-
Function:
-
Storage Spare Tools Parts Box
-
Service:
-
Customized OEM
-
Certificate:
-
ISO9001
-
Packing:
-
1 Pc / Carton
Quick Details
-
Warranty:
-
3 years
-
Color:
-
blue
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Fenghui
-
Model Number:
-
002
-
Lock:
-
Security
-
Drawers:
-
Customizable
-
Body Material:
-
Metal Frame
-
Weight:
-
Customizable
-
Tool cabinet:
-
Storage Garage Tool Cabinet
-
Function:
-
Storage Spare Tools Parts Box
-
Service:
-
Customized OEM
-
Certificate:
-
ISO9001
-
Packing:
-
1 Pc / Carton
We can see our strength
Product parameters
|
Model
|
Specifications
H*W*D
|
Height
(optional)
|
Drawer size
|
|||
|
SL
|
411x572
|
550/650/700/850
|
360x459
|
|||
|
SD
|
411x725
|
550/650/700/850
|
306x612
|
|||
|
FL
|
564x572
|
550/650/700/850/1000
|
459x459
|
|||
|
FD
|
564x725
|
550/650/700/850/1000
|
459x612
|
|||
|
ML
|
717x572
|
550/650/700/850/1000/ 1150/1325/1450
|
612x459
|
|||
|
MD
|
717x725
|
650/700/850/1000/1150/ 1325/1450
|
612x612
|
|||
|
TL
|
870x527
|
700/850/1000/1150/1325/ 1450
|
765x459
|
|||
|
TD
|
870x725
|
700/850/1000/1150/1325/ 1450
|
765x612
|
|||
|
WL
|
1023x527
|
600/700/850/1000/1150/ 1325/1450
|
918x459
|
|||
|
WD
|
1023x725
|
700/850/1000/1150/1325/ 1450
|
918x612
|
|||
|
Note: dimensions are mm
|
|
|
|
|||
Optional Accessories
Top shelf
It has anti-skid rubber pad inside,
Oil proof and easy to place tools
Base
Suitable for use in humid environment,The base height is 50mm,Color black
Vertical hanging board
The square hole hanging plate can be used with various hooks, and the storage of tools is convenient
Drawer partition assembly
Partition board
Drawer partition assembly
Sorting box
Drawer partition assembly
Sorting tank
SPECIAL GUIDE RAIL DESIGN
—LIGHT AND SMOOTH ACCESS AFTER LOADING—
|
*The drawer configuration of the tool cabinet adopts the internationally popular 25 mm multiple configuration, from the minimum height of 50 mm to the maximum height of 400 mm, the distribution of drawer height is more detailed;
*The number of drawers in the tool cabinet can be randomly configured under the determined height of the tool cabinet, that is: the total height of the drawer =the height of the cabinet body - 100 mm;
*All drawers are equipped with safety buckle device to prevent the drawer from slippingout accidentally;
*The drawer can be divided at will, and can cooperate with a large number of drawer partition accessories to manage materials more effectively;
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
Detail display
Retractable handle
High quality locks
The safety lock mechanism can lock all drawers at the same time, which is safe and reliable;
Identification paper
The handle is attached with a replaceable transparent label and identification paper, and the contents stored in the drawer are clear at a glance;
Various collocations
The same tool cabinet can choose pure monorail configuration, pure double rail configuration or single double hybrid configuration;
