Quick Details
-
Brand Name:
-
JASSCOL
-
Place of Origin:
-
Zhejiang, China
-
Brake Control(Front/Rear):
-
Foot and Hand Brake/Foot and Hand Brake
-
Battery:
-
72V,92.4Ah
-
Controller:
-
72V,5KW
-
Motor Rated Power(W):
-
5KW
-
Load Capacity:
-
27 pcs/40'H
-
Keywords:
-
ELECTRIC ATV OFF ROAD QUAD ATV 4x4 5000W ADULT ATV
Quick Details
-
Power:
-
> 1000W
-
Tire Size:
-
25*8-12/25*10R12
-
Dimension:
-
2140*1205*1230
-
Brand Name:
-
JASSCOL
-
Place of Origin:
-
Zhejiang, China
-
Brake Control(Front/Rear):
-
Foot and Hand Brake/Foot and Hand Brake
-
Battery:
-
72V,92.4Ah
-
Controller:
-
72V,5KW
-
Motor Rated Power(W):
-
5KW
-
Load Capacity:
-
27 pcs/40'H
-
Keywords:
-
ELECTRIC ATV OFF ROAD QUAD ATV 4x4 5000W ADULT ATV
ELECTRIC ATV OFF ROAD QUAD ATV 4x4 5000W ADULT ATV
Product Description
| Overall Dimensions(Length×Width×Height)(mm) | 2140×1205×1230 |
| Wheelbase(mm) | 1280 |
| Wheel Tread(mm) | 1050/960 |
| Ground Clearance(mm) | 300 |
| Net Weight(kg) | 330 |
| Gross Weight(kg) | 382 |
| Front Axle Weight(kg) | 160 |
| Rear Axle Weight(kg) | 170 |
| Max Load(kg) | 80 |
| Max Speed(km/h) | 55 |
| Max Distance(km) | 60 |
| Brake Type(Front/Rear) | Hydraulic Disc / Hydraulic Disc |
| Brake Control(Front/Rear) | Foot and Hand Brake/Foot and Hand Brake |
| Tire Rim Type(Front/Rear) | Iron |
| Tire Size(Front/Rear) | 25×8-12/25×10R12 |
| Tire Pressure(Front/Rear)/(P.S.I) | 21P.S.I/16P.S.I |
| Drive Mode | Rear Wheel Drive, 2WD/4WD |
| Battery capacity | 72V,92.4Ah |
| Charger | 84VDC,15A |
| Controller | 72V,5KW |
| Motor Model | 155-5KW-2490/8 |
| Motor Rated Voltage(V) | 72V |
| Motor Rated Power(W) | 5KW |
| Rated speed(r/min) | 3000 |
| Rated Current(A) | 76A |
| Cooling System | Air-Cooling |
| Carton Size(mm) | 2110×1290×820 |
| Packing Quantity | 27 pcs/40'H |
