Quick Details
-
Connector Type:
-
XLR
-
Gender:
-
Male-Female
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
jingyi
-
Model Number:
-
JYCM02
-
Outer Diameter:
-
7.0mm
-
Product Name:
-
Microphone Cable
-
PART NO.:
-
JYCM628 + JYS03 + JYS04
-
Connector:
-
XLR female to mono JACK
-
Cable Color:
-
Black
-
oem and odm Service:
-
YES
-
Wire information:
-
(28/0.10 OFC+PE+C-PE)*2+SP84/0.10 OFC
-
SIZE:
-
0.23mm^2(24AWG)
-
Voltage Breakdown:
-
Must with stand at DC125V/15sec.
-
Capacitance:
-
98 pF/M
-
Package:
-
48cm*38cm*21cm/ctn
Quick Details
-
Type:
-
Audio Cables, Other
-
Application:
-
Camera, HOME THEATER, Microphone, Speaker
-
Packing:
-
Carton Box
-
Connector Type:
-
XLR
-
Gender:
-
Male-Female
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
jingyi
-
Model Number:
-
JYCM02
-
Outer Diameter:
-
7.0mm
-
Product Name:
-
Microphone Cable
-
PART NO.:
-
JYCM628 + JYS03 + JYS04
-
Connector:
-
XLR female to mono JACK
-
Cable Color:
-
Black
-
oem and odm Service:
-
YES
-
Wire information:
-
(28/0.10 OFC+PE+C-PE)*2+SP84/0.10 OFC
-
SIZE:
-
0.23mm^2(24AWG)
-
Voltage Breakdown:
-
Must with stand at DC125V/15sec.
-
Capacitance:
-
98 pF/M
-
Package:
-
48cm*38cm*21cm/ctn
Products Description
|
PART NO
|
CONDUCTOR
|
SHIELD
|
CONDUCTOR SIZE
|
JACKET OD
|
|
CM001
|
2*(20/0.12OFC)
|
≤27.8Ω/KM
|
0.23MM²(24AWG)
|
Φ6.0
|
|
CM004
|
2*(12/0.12OFC)
|
≤38.7Ω/KM
|
0.14MM²(25AWG)
|
Φ6.0
|
|
CM026
|
2*(28/0.12OFC)
|
≤25.25Ω/KM
|
0.32MM²(22AWG)
|
Φ6.0
|
|
CM029
|
2*(20/0.12OFC)
|
SP45/0.12OFC
|
0.23MM²(24AWG)
|
Φ6.0
|
|
CM030
|
2*(20/0.12OFC)
|
SP45/0.12OFC
|
0.23MM²(24AWG)
|
Φ6.5
|
|
CM031
|
2*(20/0.12OFC)
|
SP64/0.1OFC
|
0.23MM²(24AWG)
|
Φ6.0
|
|
CM032
|
2*(20/0.12OFC)
|
SP64/0.1OFC
|
0.23MM²(24AWG)
|
Φ6.5
|
|
CM033
|
2*(20/0.12OFC)
|
SP80/0.10FC
|
0.23MM²(24AWG)
|
Φ6.0
|
|
CM034
|
2*(20/0.12OFC)
|
SP96/0.1OFC
|
0.23MM²(24AWG)
|
Φ6.0
|
|
CM035
|
2*(20/0.12OFC)
|
SP96/0.1OFC
|
0.23MM²(24AWG)
|
Φ7.0
|
|
CM011
|
2*(20/0.12OFC)
|
≤32.1Ω/KM
|
0.22MM²(24AWG)
|
Φ6.5
|
|
CM013
|
2*(12/0.12OFC)
|
≤27.8Ω/KM
|
0.23MM²(24AWG)
|
Φ6.5
|
|
CM038
|
2*(55/0.1OFC)
|
≤20.3Ω/KM
|
0.44MM²(21AWG)
|
Φ7.0
|
|
CM039
|
2*(20/0.12OFC)
|
≤32.1Ω/KM
|
0.22MM²(24AWG)
|
Φ6.5
|
|
CM018
|
2*(28/0.12OFC)
|
≤15.3Ω/KM
|
0.32MM²(22AWG)
|
Φ6.0
|
