Quick Details
-
power:
-
9.6KW/7,500rpm
-
Max.torque::
-
12.7N.m/6,000rpm
-
Start mode::
-
electric
-
Power source::
-
12V,12AH
-
product size:
-
2680x1630x770mm
-
Brake:
-
disc/disc
-
Fuel tank capacity:
-
10L
-
Front wheels:
-
185/30-R14
-
Rear wheels:
-
295/30-R14
-
load capacity::
-
225KGS
Quick Details
-
Power:
-
> 1000W
-
Brand Name:
-
OEM
-
Place of Origin:
-
Shandong, China
-
power:
-
9.6KW/7,500rpm
-
Max.torque::
-
12.7N.m/6,000rpm
-
Start mode::
-
electric
-
Power source::
-
12V,12AH
-
product size:
-
2680x1630x770mm
-
Brake:
-
disc/disc
-
Fuel tank capacity:
-
10L
-
Front wheels:
-
185/30-R14
-
Rear wheels:
-
295/30-R14
-
load capacity::
-
225KGS
| 1.Type: | single cylinder, water-cooling,4-stroke,250CC 24HP4valve |
| 2.Transmission: | 4 gears with one reverse gear,manual cluth |
| 3.Ignition mode: | CDI |
| 4.Compression propor: | 10.5:1 |
| 5.Power: | 9.6KW/7,500rpm |
| 6.Max.torque: | 12.7N.m/6,000rpm |
| 7.Displacement: | 243ml |
| 8.Start mode: | electric |
| 9.Tranmission mode: | chain |
| 10.Min.ground clearance: | 100mm |
| 11.Max.speed: | >70km/h |
| 12.Power source: | 12V,12AH |
| 13.Fuel tank capacity: | 10L |
| Chassis | |
| 1.Front wheels: | 185/30-R14 |
| 2.Rear wheels: | 295/30-R14 |
| 3.Break type(F/R): | disc/disc |
| 4.Front hanging: | double arm-swing |
| 5.Rear hanging: | integral |
| 6.Dimensions | |
| 7.product dimensions: | 2680x1630x770mm |
| 8.carton dimensions: | 2665x1140x730mm |
| 9.wheelbase: | 1450mm |
| 10.height of seats: | 17mm |
| 11.dry weight: | 270kg |
| 12.load capacity: | 225KG |
| 13.climbing degree: | >20 |
| Other | |
| Conveyance: | |
| Qty/20 | 12 |
| Qty/40' | 24 |
| Atv and go kart HS code: | 8703101100 |
This mini jeep is our hot seller
Designed by Japtec
WIth high quality and high performance!
Thi ELECTRIC JEEP has been sold to many countries such as Russia ,UK ,AU ,Germany ,etc
ThisELECTRIC JEEP has 6 months warranty .
Any questions please contact us freely
