Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SUGON
-
Dimensions:
-
41*36*25
-
Usage:
-
Repair all kinds of components.
-
Weight (KG):
-
7.5 KG
-
Product name:
-
Sugon 8650
-
Power Consumption:
-
1300W
-
Power Supply:
-
AC 110V 50HZ/60HZ(AC 220V 50HZ/60HZ)
-
Air Volume Gear Range:
-
1-200
-
Temperature Range:
-
100℃-500℃ (212℉-932℉)
-
Application:
-
Suitable for SOIC, CHIP, QFP, PLCC,BGA and so on.
Quick Details
-
Applicable Industries:
-
mobile phone repair, soldering electronic components, CPU PCB Welding
-
Marketing Type:
-
Hot Product 2024
-
Core Components:
-
Air pump, linear circuit board, air flow stabilizer, housing and handle
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SUGON
-
Dimensions:
-
41*36*25
-
Usage:
-
Repair all kinds of components.
-
Weight (KG):
-
7.5 KG
-
Product name:
-
Sugon 8650
-
Power Consumption:
-
1300W
-
Power Supply:
-
AC 110V 50HZ/60HZ(AC 220V 50HZ/60HZ)
-
Air Volume Gear Range:
-
1-200
-
Temperature Range:
-
100℃-500℃ (212℉-932℉)
-
Application:
-
Suitable for SOIC, CHIP, QFP, PLCC,BGA and so on.
SUGON 8650 Desoldering Station Smd Rework Station
Power: 1300W
Temperature range: 100℃-500℃/212°F-932°F
Range of air volume gear: Grade 1~200
● 3 heating modes: precision mode, universal mode and high-speed mode, applicable to different use scenarios
● Innovative pluggable air gun handle is adopted to facilitate the replacement of air gun handle and spare parts in the later stage
● The handle of the air gun has four CH keys, which can synchronously call and set the four working storage memory channels of the storage host. At the same time, the handle of the air gun also has a one-button cold air function, which is simple and convenient for real-time operation,
● The innovative handle bracket and the built-in stainless steel nozzle storage and insertion box can neatly store the nozzle and quickly replace the nozzle in the process of use and under high temperature, without other auxiliary tools, and the front and rear directions of the sleeping seat can be adjusted to meet the selection requirements of more working positions.
● It is equipped with 8 air nozzles: straight air
5 #, 7 #, 10 #, 12 #
, spiral air
8 #, 10 #
, oblique air nozzle
7 #, 10 #
, suitable for different use needs.
● Digital display: set temperature, real-time temperature, air volume, and 4 groups of storage and memory parameters for more intuitive and accurate display; Precise adjustment of keys is more convenient.
● The host has 4 preset storage channels, which can preset 4 sets of temperature and air volume settings; At the same time, it has buzzer switch function, temperature conversion function, cold air setting function, and temperature calibration function, which can be set according to the actual situation.
● The handle of the air gun is controlled by a magnetic switch. When the handle is placed on the handle frame, it will immediately enter sleep. The host can set parameters when it is in hibernation.
● Automatic large air volume cooling function can prolong the service life of the heating body and protect the hot air handle.
● Pure copper transformer ensures stable output of 1300W high power; Brushless eddy current fan is quiet, durable and has large air.
