Quick Details
-
Brand Name:
-
OEM
-
Model Number:
-
PT-T5G
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
5G PCI-E Network Card NIC
-
Keywords:
-
5G PCI-E Network Card NIC
-
Chip:
-
RTL8126
-
Support system:
-
Windows 7/Windows 8/Windows 8.1/Windows 10 Linux
-
PXE/WOL:
-
Support
-
Dimension:
-
120(D)x67(W) x 44.5(H)mm
-
Weight:
-
0.15kg
-
Operating Temperature:
-
0~40℃
Quick Details
-
Type:
-
Wired
-
Transmission Rate:
-
5000Mbps
-
Interface Type:
-
Ethernet
-
Brand Name:
-
OEM
-
Model Number:
-
PT-T5G
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
5G PCI-E Network Card NIC
-
Keywords:
-
5G PCI-E Network Card NIC
-
Chip:
-
RTL8126
-
Support system:
-
Windows 7/Windows 8/Windows 8.1/Windows 10 Linux
-
PXE/WOL:
-
Support
-
Dimension:
-
120(D)x67(W) x 44.5(H)mm
-
Weight:
-
0.15kg
-
Operating Temperature:
-
0~40℃
PCIe In-PT-T5G Single 5GbE SFP Optical Fiber Network Card Adapter High-Speed Ethernet Card
Product Images
Products Datasheet
|
Product
|
Specifications
|
|
Physical
Specification |
Description
|
|
Interface
|
1-Port 10/100/1000/2500/5000 Base-T ( 10Mbps /100Mbps / 1Gbps / 2.5Gbps/5Gbps )
Support network adaptation
|
|
Led State
|
ACT Led : The indicator is blinking. Data is being transmitted or received over the port
LNK Led : When the indicator is steady on, the link is normal
|
|
Compatible with slot
|
PCI-E 16X/PCI-E 8X/PCI-E 4X/PCI-E 1X
|
|
Support system
|
Windows 7/Windows 8/Windows 8.1/Windows 10 Linux
|
|
Network environment
|
10M/100M/1G/2.5G/5Gbps
|
|
Application
|
Desktop computer
|
|
PXE
|
Yes
|
|
WOL
|
Yes
|
|
Standard
|
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3az IEEE IEEE 802.3bz 2.5GBASE-T IEEE 802.3bz 5GBASE-T IEEE 802.3x Full Duplex and flow control |
|
Environmental
|
Operating Temperature: 0~40℃ Operating Humidity: 5~85%RH (Non-Condensing)
Storage Temperature: -20~70℃ Storage Humidity: 5~95%RH (Non-Condensing)
|
|
Mechanical
|
Dimension: 120(D)x67(W) x 44.5(H)mm Weight: 0.15kg
|
Company Introduction
PDnet has over 20 years of history in Shenzhen, China. We are a professional one-stop-solution manufacturer and supplier of various Telecommunication Networking products. Our vision is to build innovative, easy-to-use, fast and reliable Network switches. From the network core to the periphery, PDnet's Telecommunication Networking solutions enable users to share broadband access, multimedia content, and network peripherals for true anywhere connectivity. PDnet's diverse product includes Desktop Switch, PoE Switch, non PoE Switch, Enterprise Switches, Ethernet network, especially the top-leading technology in the ODM/OEM. We can also produce the goods according to clients' requirements. Our products are popular in Korea, Japan, Southeast Asia, USA, and Europe. Don't hesitate to contact us if you are interested, thanks!
Product Capacity
Quality Control
Package
Shipment
FAQ
1. Business Type
-- Manufacturer located in ShenZhen, China
-- Factory is 3000 square
-- Employees: over 70 in office & workshops
2. Can you make the network switch with ODM/OEM?
-- YES. We have strong R&D capability, also a great term of technical engineers, each of them have many work years experience.
3. Do you provide the samples?
-- YES. We can offer sample to you.
4. Quality Control
-- 100% inspection before package
-- Spot inspection before shipment
5. What is your after-sales services?
1. Free maintenance within 12 months guarantee, lifetime consultant.
2. Professional solutions in installation and maintence.
6. Why choose us?
-- Competitive Price & 7*24 after-sale services.
-- From mold customization to material processing and welding, from fine components to finished assembly, 72 processes, 24 control points, strict aging, finished product inspection.
-- Over 20years experience in the Telecommunication Networking field.
-- Manufacturer located in ShenZhen, China
-- Factory is 3000 square
-- Employees: over 70 in office & workshops
2. Can you make the network switch with ODM/OEM?
-- YES. We have strong R&D capability, also a great term of technical engineers, each of them have many work years experience.
3. Do you provide the samples?
-- YES. We can offer sample to you.
4. Quality Control
-- 100% inspection before package
-- Spot inspection before shipment
5. What is your after-sales services?
1. Free maintenance within 12 months guarantee, lifetime consultant.
2. Professional solutions in installation and maintence.
6. Why choose us?
-- Competitive Price & 7*24 after-sale services.
-- From mold customization to material processing and welding, from fine components to finished assembly, 72 processes, 24 control points, strict aging, finished product inspection.
-- Over 20years experience in the Telecommunication Networking field.
