RTD2555V3.0 FFC 30pin VGA+HDMI
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BOE
-
LCD Type:
-
without touch
-
Size:
-
10.1 inch
-
Resolution:
-
1920*1200
-
Interface:
-
EDP
-
Brightness:
-
1000cd/m2
-
Outline Dimension:
-
228.2(W)*149(H)*4.3mm
-
Active Area:
-
216.576(W)*135.36(H) mm
-
Viewing Angle:
-
80/80/80/80
-
Operating Temperature:
-
-20 ~ 70
-
Warranty:
-
12 Months
Quick Details
-
Type:
-
TFT
-
Display Size:
-
10.1nch
-
Supplier Type:
-
Agent and distributor
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BOE
-
LCD Type:
-
without touch
-
Size:
-
10.1 inch
-
Resolution:
-
1920*1200
-
Interface:
-
EDP
-
Brightness:
-
1000cd/m2
-
Outline Dimension:
-
228.2(W)*149(H)*4.3mm
-
Active Area:
-
216.576(W)*135.36(H) mm
-
Viewing Angle:
-
80/80/80/80
-
Operating Temperature:
-
-20 ~ 70
-
Warranty:
-
12 Months
|
Tems
|
|
Unit
|
Specifications
|
|
||
|
LCD Type
|
|
|
without touch
|
|
||
|
Size
|
|
inch
|
10.1
|
|
||
|
Model
|
|
|
GV101WUM-N40
|
|
||
|
Resolution
|
|
|
1920(RGB)×1200, WUXGA, 225PPI
|
|
||
|
Brightness
|
|
cd/m²
|
1000
|
|
||
|
Interface
|
|
|
eDP (2 Lanes) , eDP1.4 , HBR1 (2.7G/lane) , 30 pins
|
|
||
|
Active Area
|
|
mm
|
216.576(W)×135.36(H)
|
|
||
|
Outline Dimension
|
|
mm
|
228.2(W)×149(H)×4.3(D)
|
|
||
|
Viewing Angle
|
|
|
80/80/80/80
|
|
||
|
Contrast Ratio
|
|
|
1000:1
|
|
||
|
Operating Temperature
|
|
℃
|
-20~70
|
|
||
|
Storage Temperature
|
|
℃
|
-30~80
|
|
||
|
Brand
|
|
|
BOE
|
|
||
|
RoHS Compliance
|
|
|
RoHS Compliance
|
|
||
Lighting effect
RTD2555V3.0
FFC 30 pin
VGA+HDMI
RTD2556V2.2
FFC 30pin Flexible flat cable
DP+HDMI
Q1. What are the advantages of Yuewei display？
A1.
The original brand agent, the products are in stock,
Fast delivery time
, can be supplied at any time, 24 hours online service, the products have passed strict testing and certification, and the seller is guaranteed.
Q2:
Can we get some screen drivers and wires?
A2:
Sure.
It can also be customized according to your needs
Q3.how can we guarantee quality?
Q3.
All of our screens are all new with original packaging, passed the international inspection standards, well guaranteed.If there is any quality issue, we will surely solve it within 1-2 working days.
Warranty 12 months.
Q4. How long will it be delivered?
A4.
We will ship the goods within 1-2 days after your payment. And we will send you the tracking number the next day after the goods are shipped.
Q5. what can you buy from Yuewei?
A5.
TFT L
CD module, LCD panel, LCD screen, capacitive touch, resistive touch, display, all-in-one, driver board, wire.
