Quick Details
-
WARRANTY:
-
WITHIN ONE YEAR
Quick Details
-
Engine Capacity:
-
> 6L
-
Dimensions (L x W x H) (mm):
-
1150*680*390
-
CERTIFICATE:
-
CE APPROVIED
-
WARRANTY:
-
WITHIN ONE YEAR
|
Model |
Unit |
T15BML |
T15BMS |
|
Overall length |
mm(in.) |
680(26.8) |
|
|
Overall Width |
mm(in.) |
390(15.4) |
|
|
Overall Height |
mm(in.) |
1280(50.4) |
1150(45.3) |
|
Transom Height |
mm(in.) |
567(22.3) |
444(17.3) |
|
Weight |
Kg |
40 |
38.5 |
|
Full throttle Operating Range |
r/min |
4500~5500 |
|
|
Maximun Output |
Kw(hp)@r/min |
11(15)@5000 |
|
|
Idling Speed(neutral) |
r/min |
700~800 |
|
|
Engine Type |
|
2-STROKE |
|
|
Cylinders |
|
L2 |
|
|
Displacement |
cm3 |
246 |
|
|
Bore*Stroke |
mm(in.) |
56*50(2.20*1.97) |
|
|
Ignition System |
|
CDI |
|
|
Control System |
|
Tiller Control |
|
|
Starting System |
|
Manual Start |
|
|
Gear Positions |
|
Forward-Neutral-Reverse |
|
|
Gear Ratio |
|
2.08(27/13) |
|
|
Trim and tilt system |
|
Manual tilt |
|
|
Fuel tank Capacity |
L |
24 |
|
|
Engine oil capacity (without oil filter) |
|
(Fuel:oil ration:50:1) |
|
|
Gear oil Capacity |
cm3 |
250 |
|
|
Propeller Spec. |
In |
3-9 1/4"×11" |
|
|
Packing |
L*W*H |
1280*680*390 |
1150*680*390 |
|
20GP |
PCS |
82 |
102 |
|
40HQ |
PCS |
202 |
236 |
|
Packed with soild foam, good strong carton, pallet for sample order B=BACK CONTROL,M=MANUAL START,S=SHORT SHAFT,L=LONG SHAFT |
|||
|
Our Marine Engine Rang Two stroke: 2.5HP ,4HP, 5HP, 8HP, 9.9HP, 15HP and 40HP motors Four stroke, 2.5HP, 4HP, 5HP, 9.9HP, 15HP |
|||
