Product Parameters
|
|
|
|
|
||||
|
Cmos Sensor
|
|
H62
|
|
|
||||
|
Lens Size
|
|
1/4 inch
|
|
|
||||
|
Warranty
|
|
1 Years
|
|
|
||||
|
USB Cable
|
|
1m (2/3m optional)
|
|
|
||||
|
Photosensitive
|
|
TBD
|
|
|
||||
|
USB Type
|
|
USB 2.0
|
|
|
||||
|
|
|
1280*720/30fps;MJPG
|
|
|
||||
|
|
|
800*600/30fps;MJPG
|
|
|
||||
|
|
|
640*480/30fps;MJPG
|
|
|
||||
|
|
|
320*240/30fps;MJPG
|
|
|
||||
|
View Angle
|
|
140° No Distortion(Or As per your request)
|
|
|
||||
|
Working Voltage&Current
|
|
5V*110mA-190mA
|
|
|
||||
|
Working temperature
|
|
0～60℃
|
|
|
||||
|
Storage temperature
|
|
-30℃～80℃
|
|
|
||||
|
|
|
Microsoft windows 2000 sp2
|
|
|
||||
|
|
|
XP/Vista/Windows7/Windows8/Windows10
|
|
|
||||
|
|
|
MAC-OS X 10.4.8 or later
|
|
|
||||
|
|
|
Linux with UVC（above linux-2.6.26）
|
|
|
||||
|
|
|
Android 4.0 or above with UVC
|
|
|
||||
|
|
|
Express post station face recognition, Code scanner, High-speed camera, cell phone OTG, access control attendance, advertising machine,face recognition, conference video, industrial vision, visual inspection, USB microscope, USB telescope, intelligent selling camera,
electronic scale item recognition, food recognition, USB raspberry pi, etc. |
|
|
||||
|
Support Drive Free
|
|
USB Video Class(UVC)
|
|
|
||||
|
Support OTG
|
|
USB 2.0 OTG
|
|
|
||||
|
PCB Size
|
|
38*38MM(or 32*32MM)
|
|
|
||||
|
The power supply model
|
|
USB BUS POWER 4P-2.0mm
|
|
|
||||
|
Diagonal angle of lens
|
|
As buyer requirment of 30~220°
|
|
|
||||
