Quick Details
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
OV Laser
-
Marking Head Brand:
-
Sino Galvo
-
Weight (KG):
-
45 KG
-
Core Components:
-
Laser source
-
Product name:
-
glass gobo printing machine 20w 30w fiber laser gobo logo maker
-
Marking machine source:
-
Raycus
-
Marking machine head:
-
SG2206
-
Marking machine speed:
-
7000mm/s
-
Marking depth:
-
0.01-2mm
-
Marking machine accuracy:
-
0.001mm
-
Fiber laser source lifespan:
-
100,000 hours
-
Marking area:
-
50mm*50mm--- 300mm*300mm
-
Lead time:
-
5 days
-
Payment term:
-
TT, Visa
Quick Details
-
Working Accuracy:
-
0.001mm
-
Graphic Format Supported:
-
AI, PLT, DXF, BMP, Dst, JPG
-
Laser Type:
-
Fiber Laser
-
Cooling Mode:
-
Air Cooling
-
Control Software:
-
EZCAD
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
OV Laser
-
Marking Head Brand:
-
Sino Galvo
-
Weight (KG):
-
45 KG
-
Core Components:
-
Laser source
-
Product name:
-
glass gobo printing machine 20w 30w fiber laser gobo logo maker
-
Marking machine source:
-
Raycus
-
Marking machine head:
-
SG2206
-
Marking machine speed:
-
7000mm/s
-
Marking depth:
-
0.01-2mm
-
Marking machine accuracy:
-
0.001mm
-
Fiber laser source lifespan:
-
100,000 hours
-
Marking area:
-
50mm*50mm--- 300mm*300mm
-
Lead time:
-
5 days
-
Payment term:
-
TT, Visa
Contact OV Laser
Welcome to contact Jully.
Mobile/ WhatsApp/Skype / WeChat: +86 13707153812
Mobile/ WhatsApp/Skype / WeChat: +86 13707153812
Product Description
About OV Laser
OV Laser Factory Since 2006
Specialized in Laser Marking Solution
Free Samples Testing !
Free Lifelong After-sale Service !
Free Software Upgrade !
Customize the Machine to meet your special requirements !
Specialized in Laser Marking Solution
Free Samples Testing !
Free Lifelong After-sale Service !
Free Software Upgrade !
Customize the Machine to meet your special requirements !
Main Features
1. Marking Area: 110*110 mm, 175*175 mm, 200*200 mm, 300*300 mm.
2. Best Marking Effect: Owning to the original Raycus laser source technology, the laser beam is fine and thin to ensure best marking effect. Together with the stable precision slider, the fiber laser marker is especially good for large size seamless splicing image marking.
3. Higher Accuracy: The fiber laser marking machines can reach up to 0.001 mm precision.
4. Long lifetime: the lifetime can reach 80,000 - 100,000 hours.
5. No consumption except electricity.
6. Free Maintenance.
7. Easy operation: Machine is installed well.We will supply the installation training video for our dear customers to install
laser marking machine.
2. Best Marking Effect: Owning to the original Raycus laser source technology, the laser beam is fine and thin to ensure best marking effect. Together with the stable precision slider, the fiber laser marker is especially good for large size seamless splicing image marking.
3. Higher Accuracy: The fiber laser marking machines can reach up to 0.001 mm precision.
4. Long lifetime: the lifetime can reach 80,000 - 100,000 hours.
5. No consumption except electricity.
6. Free Maintenance.
7. Easy operation: Machine is installed well.We will supply the installation training video for our dear customers to install
laser marking machine.
Specification
Optional Accessories
|
Product Parameters
|
|
|
|
|||
|
Model
|
OV SF-20/30
|
Laser source
|
Raycus
|
|||
|
Laser Type
|
Fiber laser
|
Positioning Way
|
Red light
|
|||
|
Laser power
|
20W/30W
|
Laser Module Life
|
100000 hours
|
|||
|
Weave length
|
1064 nm
|
Cooling Style
|
Air cooling
|
|||
|
Marking area
|
110mm*110mm--300mm*300mm
|
Total power
|
≤500W
|
|||
|
Marking speed
|
7000 mm/s
|
Operating Voltage
|
220v /110v 50hz/60hz
|
|||
|
Marking depth
|
0.01-2mm
|
Supported Windows
|
Windows XP,7,8,10
|
|||
|
Repetition Precison
|
0.001mm
|
Certificate
|
ISO, CE
|
|||
|
Minimum Character
|
0.2 mm
|
Control software
|
EZCAD 2.14.11
|
|||
|
Minimum Line Width
|
0.01mm
|
Supported Format
|
PLT, DXF, DST, AI, SDT, BMP, etc.
|
|||
|
Packaging Dimension
|
77*43*54cm
|
Gross weight
|
58kg
|
|||
Application & Samples
Fiber laser marking machine can work perfectly for most metal and some nonmetal materials, such as
Gold Silver Brass Stainless Steel Jewelry
, Aluminium, Carbon Steel, Iron, Pen, Credit Cards, Plastic ,Tags etc.
Gobo Glass Printing Samples
Metal Pen Plastic Marking Samples
