2024 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

2024 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

FOB Reference Price: Get Latest Price

≥1 Sets

US $18999

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: QI'E oil making machinery

Voltage:: 380V/440V

Dimension(L*W*H):: 1200*2800*1200mm

Weight:: 15000 KG

Marketing Type:: New Product 2024

Used for:: coconut oil making

oil clolor:: yellow

advantage:: save energy

bleaching earth consumption:: 5-50kg/t oil

decolor function:: remove the bad color

deodor function:: remove the bad smell

Price:: China cheap price

Package:: Plywood Case

Capacity:: 5-2000TPD

Quick Details

Max Capacity:: 2000tpd

Production Capacity:: 98%-100%

Place of Origin:: Henan, China

Brand Name:: QI'E oil making machinery

Voltage:: 380V/440V

Dimension(L*W*H):: 1200*2800*1200mm

Weight:: 15000 KG

Marketing Type:: New Product 2024

Used for:: coconut oil making

oil clolor:: yellow

advantage:: save energy

bleaching earth consumption:: 5-50kg/t oil

decolor function:: remove the bad color

deodor function:: remove the bad smell

Price:: China cheap price

Package:: Plywood Case

Capacity:: 5-2000TPD

Product Description

2020 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

Capacity: 3T-5000T/D
Oilseeds scope: Soybean, rice bran, peanut, sesame, sunflower seed, rapeseed, cottonseed, corn germ, copra, castor bean and so on.

Alkali	Oil acid valuex1-3kg/T oil
Refining rate	1-refining consumption
Water (soften water)	150Kg/T oil
Phosphoric acid	2~3 kg/T oil
Steam consumption	700KG/T oil
Circulating water cooling water yield	150M3/H
Bleaching earth consumption	3-5Kg/T oil
Waste bleaching earth oil content	≤25~35%
Refining losses	Acid valuex1.2 (chemical refining) Acid valuex 0.6 (physics refining)
Bleaching losses	The quantity of bleaching earth×0.25%
Electric consumption	28Kwh/T oil
Deodorization loss consumption	≤0.5%

The Pretreatment

2020 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

Cleaning: Remove most impurities from the material, such as stones, dirt, etc., to prepare for the next crushing process, improve crushing efficiency and extend machine life.

Crushing: After the crushing process, the material is broken into small pieces, which improves the efficiency of the material being pressed.
Softening process: Increase the moisture content and temperature of the material, and ultimately increase the final oil output of the material.
Flaking process: The material is pressed into pieces in this process to increase the amount of oil discharged from the material.
Extruder: The treated oil enters the squeegee from the hopper. Under the condition of high pressure, the embryo is continuously pushed inward by the screw press, and is pressed to finally produce oil.

Cleaning sieve

Crushing

Softening process

Flaking process

Extruder

The Extraction Process

2020 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

Extraction: It usually adopt an organic solvent that can dissolve the oil, through the material spray, soak, so that the oil will be extracted from the oil-bearing seeds.

DTDC: By continuously the multi-layered steam heating, the heat obtained by the solvent in the wet mash is vaporized, thereby separating the solvent from the wet meal, and removing the solvent remaining in the wet meal as much as possible.

Evaporation: The difference between the boiling point of the oil and the solvent is used to separate the solvent and the oil.

Stripper: The separated solvent can be dissolved in the selected paraffin or solvent and recovered.

The refining Process

2020 New design Coconut oil press processing machine for edible oil expeller making machine plant in Sri lanka

A general term for a series of processes for removing solid impurities, free fatty acids, phospholipids, gums, waxes, pigments, odors, etc. contained in vegetable oils. Enhancing the nutritional value of edible oils has great benefits for human health.

Deacidification and Degumming: This step is mainly to remove the excess acid in the grease.

Decolorization: The decolorization process greatly enhances the oxidation stability of the oil, and this process also has a great influence on the subsequent deodorization process of the oil.

Deodorization: Deodorization of oil and fat not only removes odor substances in oil, but also improves the safety of oils and fats.

Filteration: Miscella mixed by oil and clay from bleaching tower is pumped into decolorizing filter.

Dewaxing process: Bleached oil enter into crystallizing tank through heat exchanger and begin the cooling crystallization process.

Company

Zhengzhou Qi'E Grain&Oil Machine Co.,Ltd is a large-sized joint-equity enterprise which specialize in producting edible oil mechanical equipment, corn oil making machine and it is aslo a group enterprise integrating scientific research, manufacturing,sales as one.Our oil making machine are exported to more than 30 countries,and regions such as Russia, India, South Africa, Ukraine, Nepal, Indonesia and so on.

1. More than 30 years of experience

2.Top production team

3.High quality products

Our Customers

The production and comprehensive economic indicators lie in forefront of the same industry, with products selling all over the county and exporting to over 40 countires, such as Russia, South Africa, Ukraine, Nepal, Indonesia, Kazakhstan, Korea, Vietnamese, Pakistan, Romania, and Serbia, etc.

Regards Quality As The Company Life, Regard Customer As The God, Mutual Bnenfit And Win-Win Situation With Integrity Tenet.

Honest, Dedicated And Sincere Copperation!

Our service

Pre-sale services

1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.

After-sale services

Improve the added value of our products, and let the clients free from the using troubles:

1) Assisting the clients preparing for the first construction scheme;

2) Installing and testing the equipment;

3) Training the first-line operators on site;

4)Supplying spare parts with cost.

FAQ

Q:Are you a manufacturer or a foreign trade company?
A:We are a manufacturer.

Q:What if I could not operate this product?
A:Our machine operation video and manual are for your reference. If necessary, we will send engineers to train for you personally.

Q:Can you provide more information about production and quote the best price?
A:Of course, but first we have to confirm your needs. According to your needs, we will choose the right product for your reference. When we determine one or several products, we will quote you the best price.

Q:How to place an order?
A:First send us the enquiry below, including the device name, daily production, work hours, main processing materials, etc., then our sales manager will send you the information for your reference.

Q:How long does it take to receive my product?
A:It is not yet possible to determine the time because the shipping distance and production cycle are uncertain.our business manager will recommend the appropriate transportation route for you to ensure safe and fast delivery of the goods.

Q:How is the quality of your products guaranteed?
A:After the completion of production, our quality inspection can not test the product. If you need it, we can provide third-party testing service to ensure the stable production of the equipment.
