Quick Details
-
Model Number:
-
48V 200AH
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
Lithium battery
-
Type:
-
LiFePo4
-
Voltage:
-
48v
-
Current:
-
50/100/200AH
-
Cycle:
-
>6000 times
-
Warranty:
-
10 years
-
BMS:
-
Yes
-
Suggested DOD:
-
90%
-
Monitoring:
-
CAN/RS485/WIFI/4G
Quick Details
-
Anode Material:
-
LCO
-
Application:
-
Consumer Electronics, SUBMARINES, Electric Bicycles/Scooters, Electric Power Systems, Uninterruptible Power Supplies
-
Brand Name:
-
Sunwe
-
Model Number:
-
48V 200AH
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
Lithium battery
-
Type:
-
LiFePo4
-
Voltage:
-
48v
-
Current:
-
50/100/200AH
-
Cycle:
-
>6000 times
-
Warranty:
-
10 years
-
BMS:
-
Yes
-
Suggested DOD:
-
90%
-
Monitoring:
-
CAN/RS485/WIFI/4G
Specification
|
Model
|
48v 50ah
|
48v 100ah
|
48v 200ah
|
||
|
Capacity
|
2.4KWH
|
4.8KWH
|
9.6KWH
|
||
|
Nominal discharge current
|
50A
|
100A
|
200A
|
||
|
Max discharge current
|
50A
|
100A
|
200A
|
||
|
Working Voltage
|
40.5-53.25V
|
40.5-53.25VDC
|
40.5-53.25VDC
|
||
|
Standard Voltage
|
48V
|
48V
|
48V
|
||
|
Max Charging Current
|
50A
|
100A
|
200A
|
||
|
Max Charging Voltage
|
53.25V
|
53.25V
|
53.25V
|
||
|
Circle Times
|
>6000 times
|
>6000 times
|
>6000 times
|
||
|
Size(mm)
|
484*410*88.5
|
484*410*178
|
484*590*178
|
||
|
Weight
|
24.5kg
|
49kg
|
77kg
|
||
|
Working Temperature
|
-20ºC-60ºC
|
|
|
||
|
Installation
|
Cabinet or wall installation
|
484*410*178
|
484*590*178
|
||
|
Communication
|
CAN/RS485/WIFI/4G/Blue/tooth/communication
|
|
|
||
|
Battery Protection
|
Over-current/over voltage/short circuit/low voltage/high temperature
|
|
|
||
|
Max Number Of Parrallel
|
15 pieces
|
|
|
||
|
Warranty
|
10 years
|
|
|
||
|
Suggested DOD
|
90%
|
|
|
||
|
BMS
|
YES
|
|
|
||
