- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Zoomlion
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support
-
Max. Concrete Output:
-
170/120 m3/h
-
Max. Reach Vertical:
-
49m
-
Color:
-
White and Green
-
Certification:
-
ISO CE
Quick Details
-
Power Type:
-
Diesel
-
Productivity:
-
6M³/H
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Zoomlion
-
After-sales Service Provided:
-
Engineers available to service machinery overseas, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Free spare parts, Online support
-
Max. Concrete Output:
-
170/120 m3/h
-
Max. Reach Vertical:
-
49m
-
Color:
-
White and Green
-
Certification:
-
ISO CE
Zoomlion 49m mobile stationary Concrete Truck Mounted Pumps 49X-6RZ in Malaysia
Product Description
• Compact in design, 49m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, itmonitors the pump intelligently on working data agement,real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual -machine interface system.
• PWM+CAN dual communication mode remote control
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, itmonitors the pump intelligently on working data agement,real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual -machine interface system.
• PWM+CAN dual communication mode remote control
Main Parameters
| Distribution valve | S-valve | |
|---|---|---|
| Max. Concrete Output | m 3 /h | 170/120 |
| Max. Concrete Pressure | MPa | 8.3/12 |
| Delivery Cylinder | mm | 260 |
| Stroke Length | mm | 2100 |
| Strokes | 1/min | 25/18.5 |
| Hopper Capacity | L | 600 |
| Filling height | mm | 1540 |
| Hydraulic System | Open | |
| Hydraulic oil cooling | Double fans | |
| High/Low Press. Switch | Automatic | |
| Lubrication on pump | Automatic | |
| Lubrication on hopper | Automatic | |
| GPS Data age | Optional | |
| Boom Control Valve | Proportional | |
| Number of Arms | 6 | |
| Folding System | RZ | |
| Max. Reach Vertical | m | 49 |
| Max. Reach Horizontal | m | 45 |
| Max. Reach Depth | m | 34.1 |
| Min. Unfolding Height | m | 9.5 |
| End Hose Length | m | 3 |
| Pipeline | DN125/5.5 | |
| Slewing Range | ±270° | |
| Slewing Motor | 2 Motor | |
| Remote Control System | Radio | |
| Water Pump | 20L/min, 60bar | |
| Tool kits with box | Standard | |
